2009 SUBARU LEGACY trunk release

3-22Instruments and controls
Warning messages Details
Door open warning
When any of the doors, the rear gate (Station wagon) or the trunk lid
(Sedan) is not fully closed, it is indicated by the corresponding part of the
door light.
Always make sure this warning message is out before you start to drive.
The display shows the interruptive warning message for 3 seconds.
Parking brake warning
This warning message illuminates with the parking brake applied while the
ignition switch is in the“ON ”position. It goes out when the parking brake is
fully released.
The display shows the interruptive warning message for 3 seconds and
then returns to its original display. The interruptive warning message will be
displayed again after 20 seconds.
Run mode change system warning
This warning message indicates a malfunction of the “SI-DRIVE mode ”
change. If this warning message is shown on the display, contact your
nearest SUBARU dealer and have the SI-DRIVE mode system inspected.
The display shows the interruptive warning message for 3 seconds.
Engine coolant temperature warning
When the engine coolant temperature reaches 248 8F (120 8C), this warning
message is indicated. If this warning message is displayed, refer to the “ Engine overheating
”section in chapter 9 for details the necessary measures.
The display shows the interruptive warning message for 3 seconds.

3-36Instruments and controls
what harder to control.
If the brake system warning light and ABS
warning light illuminate simultaneously,
take the following steps:
1. Stop the vehicle in the nearest safe,
flat place.
2. Shut down the engine, then restart it.
3. Release the parking brake. If both
warning lights go out, the EBD system
may be faulty.
Drive carefully to the nearest SUBARU
dealer and have the system inspected.
4. If both warning lights illuminate again
and stay illuminated after the engine has
been restarted, shut down the engine
again, apply the parking brake, and check
the brake fluid level.
5. If the brake fluid level is not below the “MIN ”mark, the EBD system may be
faulty. Drive carefully to the nearest
SUBARU dealer and have the systeminspected.
6. If the brake fluid level is below the “ MIN ”mark, DO NOT drive the vehicle.
Instead, have the vehicle towed to the
nearest SUBARU dealer for repair.
& Low fuel warning light
The low fuel warning light illuminates
when the tank is nearly empty approxi- mately 2.6 US gal (10.0 liters, or 2.2 Imp
gal). It only operates when the ignition
switch is in the
“ON ”position.
NOTE
This light does not go out unless the
tank is replenished up to an internal
fuel quantity of approximately 3.7 US
gal (14 liters, 3.1 Imp gal).
CAUTION
Promptly put fuel in the tank when-
ever the low fuel warning light
illuminates. Engine misfires as a
result of an empty tank could cause
damage to the engine.
& Door open warning light
When any of the doors, the rear gate
(Station wagon) or the trunk lid (Sedan) is
not fully closed, the door open warning
light illuminates.
For a vehicle without SI-DRIVE, the
open door is indicated by the correspond-
ing part of the door open warning light.
For a vehicle with SI-DRIVE, the opening
door is indicated on the multi-information
display. Always make sure this light is out before
you start to drive. &
All-Wheel Drive
warning light
(AT models)
WARNING
Continued driving with the AWD
warning light flashing can lead to
powertrain damage. If the AWD
warning light flashes, promptly park
in a safe place then check whether
all four tires are the same diameter
and whether any of the tires has a
puncture or has lost air pressure for
some other reason.
The All-Wheel Drive warning light illumi-
nates when the ignition switch is turned tothe “ON ”position and goes out after the
engine has started. ! For 5-speed automatic transmis-
sion vehicles
This light flashes if the vehicle is driven
with tires of different diameters fitted on its
wheels or with the air pressure exces-
sively low in any of its tires.

Shopping bag hook
CAUTION
Do not hang items on the shopping
bag hook that weigh 11 lbs (5 kg) ormore.
& For Sedan models
A shopping bag hook is attached to each
inner side wall of the trunk near the trunk
lid opening. &
For Station wagon models
A shopping bag hook is attached to each
side of the cargo area.
To use the hook, push the upper portion
and the shopping bag hook will appear. Floor matA retaining pin is located on the driver
’s
side of the vehicle next to the fuel filler
door release. Fit the grommet in the carpet
onto the pin to prevent the carpet frommoving. Interior equipment
6-13
– CONTINUED –

9-18In case of emergency
Rear gate (Station wagon) –if
the rear gate cannot be un- locked
In the event that you cannot unlock the
rear gate by operating the power door
locking switches or the remote keyless
entry system, you can unlock it from inside
the cargo area.
1. Remove the access cover at the
bottom-center of the rear gate trim using
flat-head screwdriver.
2. Locate the rear gate lock release lever
behind the rear gate trim panel.
3. Unlock the rear gate by pressing the
lever inside the trim downward.
4. Open the rear gate from outside by
raising the rear gate handle. Maintenance tools &
Jack
A jack and other maintenance tools are
stored in the tool bucket in the center of
the spare tire located in the trunk or in the
cargo area.
Sedan: To take out the jack and main-
tenance tools, open the floor cover and
remove the bucket from the center of the
spare tire. Then, take the jack out of thebucket.

Front turn signal/Parking and front side marker ............. 11-53
Fuel ........................................................................... 7-3
Economy hints ......................................................... 8-2
Filler lid and cap ...................................................... 7-5
Gauge ............................................................ 3-6, 3-26
Requirements .......................................................... 7-3
Fuses ...................................................................... 11-47
Fuses and circuits ...................................................... 12-6
G
GAWR (Gross Axle Weight Rating) .............................. 8-15
Gear position indicator ................................................ 3-39
Glove box ................................................................... 6-5
GVWR (Gross Vehicle Weight Rating) .......................... 8-15
H
Hazard warning flasher ........................................... 3-5, 9-2
Head restraint adjustment Front seat ............................................................... 1-7
Rearseat ............................................................... 1-10
Headlight Flasher ................................................................. 3-47
Indicator light ......................................................... 3-40
Headlights ........................................................ 3-46, 11-51
Heater operation (manual climate control system) ............ 4-5
High beam indicator light ............................................ 3-40
High mount stop light ................................................. 11-59
High/low beam change (dimmer) .................................. 3-46
Horn ......................................................................... 3-59
Hose and connections ............................................... 11-14 I
Ignition switch
............................................................. 3-3
Light ...................................................................... 3-5
Illumination brightness control ...................................... 3-48
Immobilizer ................................................................. 2-3
Indicator light (security indicator light) ................. 2-4, 3-38
Indicator light
Cruise control ................................................ 3-40, 7-49
Cruise control set ........................................... 3-40, 7-50
Front fog light ......................................................... 3-40
Headlight ............................................................... 3-40
High beam ............................................................. 3-40
Immobilizer ............................................................. 2-4
S# PREP .............................................................. 3-39
Security .......................................................... 2-4, 3-38
Selector lever position ............................................. 3-39
Selector lever/Gear position ..................................... 3-40
Shift-up ................................................................. 3-38
SPORT mode ........................................................ 3-38
Traction control system OFF .................................... 3-37
Turn signal ............................................................ 3-40
Vehicle Dynamics Control OFF ......................... 3-38, 7-40
Vehicle Dynamics Control operation .................. 3-37, 7-40
Information display ...................................................... 3-41
Inside mirror .............................................................. 3-56
Interior lights ............................................................... 6-2
Internal trunk lid release handle .................................... 2-25
JJack. ......................................................................... 9-18
Jack handle ............................................................... 9-19 Index
14-5

14-8Index
Refueling .................................................................... 7-5
Remote engine start system ........................................ 7-11
Remote keyless entry system ........................................ 2-8
Replacement Brake pad and lining ............................................. 11-32
Wiper blades ........................................................ 11-42
Replacing Air cleaner element ............................................... 11-18
Battery (remote keyless entry system) ...................... 2-11
Lost transmitters (remote keyless entry system) . ........ 2-13
Replacing bulbs ........................................................ 11-50
Back-up light (Sedan) ............................................ 11-53
Back-up light (Station wagon) ................................. 11-56
Brake/Tail and rear side marker light (Sedan) ........... 11-53
Brake/Tail light (Station wagon) ............................... 11-54
Cargo area light .................................................... 11-59
Dome light ........................................................... 11-57
Door step light ...................................................... 11-58
Front fog light ....................................................... 11-53
Headlight ............................................................. 11-51
High mount stop light ............................................. 11-59
License plate light ................................................. 11-56
Map light .............................................................. 11-57
Rear combination light ........................................... 11-53
Rear side marker light (Station wagon) .................... 11-54
Trunk light ............................................................ 11-59
Vanity mirror light .................................................. 11-58
Rocking the vehicle .................................................... 8-13
Roof rail and crossbar ................................................ 8-15 S
S# PREP indicator light
............................................... 3-39
Safety
Precautions when driving ............................................. 4
Symbol ...................................................................... 2
Warnings ................................................................... 2
Seat Fabric ................................................................... 10-5
Heater .................................................................... 1-8
Memory function ...................................................... 1-5
Seat height adjustment ................................................. 1-4
Seatbelt. ........................................................................ 4
Maintenance .......................................................... 1-23
Pretensioners ......................................................... 1-24
Safety tips ............................................................. 1-13
Warning light and chime .................................. 1-15, 3-29
Seatbelts ................................................................... 1-13
Security ID plate .......................................................... 2-3
Security indicator light .......................................... 2-4, 3-38
Selector lever ..................................................... 7-19, 7-25
Position indicator ............................................ 3-39, 3-40
Shift lock release ................................................ 7-24, 7-30
Shift-up indicator light .................................................. 3-38
Shock sensors ........................................................... 2-20
Shopping bag hook ..................................................... 6-13
SI-DRIVE mode. ......................................................... 7-31
Snow tires ....................................................... 8-11, 11-34
Snowy and icy roads ................................................... 8-9
Sounding a panic alarm .............................................. 2-11
Spark plugs ............................................................. 11-20
Specifications ............................................................. 12-2

Speedometer....................................................... 3-6, 3-24
SPORT mode indicator light ........................................ 3-38
SRS
Curtain airbag ........................................................ 1-56
Frontal airbag ........................................................ 1-45
Side airbag ........................................................... 1-56
SRS airbag (Supplemental Restraint System airbag) ... 4, 1-40
SRS airbag system Monitors. ............................................................... 1-63
Servicing ............................................................... 1-65
Warning light ......................................................... 3-30
Starting the engine ....................................................... 7-9
State emission testing (U.S. only) .................................. 7-7
Steering wheel Power ................................................................... 7-34
Tilt/telescopic ......................................................... 3-59
Stopping the engine ................................................... 7-11
Storage compartment ................................................... 6-5
Stowage boxes .......................................................... 6-17
Sun shade ........................................................ 2-30, 2-31
Sun visors ................................................................... 6-4
Supplemental Restraint System airbag (SRS) ... ............. 1-40
Synthetic leather upholstery ........................................ 10-5
T
Tachometer ......................................................... 3-6, 3-26
Temperature gauge ...................................... 3-7, 3-12, 3-27
Temperature warning light AT OIL TEMP ........................................................ 3-33
Temporary spare tire .................................................... 9-2
Tether (child restraint system) .............................. 1-35, 1-38 Tie-down hooks
.......................................................... 9-14
Tire
Chains .................................................................. 8-13
Inspection ............................................................ 11-35
Pressures and wear .............................................. 11-36
Replacement. ....................................................... 11-39
Rotation .............................................................. 11-39
Types .................................................................. 11-33
Tire pressure monitoring system (TPMS) ......................................... 3-33, 7-43, 9-9, 11-34
Tires ......................................................................... 12-5
Tires and wheels ...................................................... 11-33
Top tether anchorages ........................................ 1-35, 1-38
Towing ...................................................................... 9-13
All wheels on the ground ......................................... 9-17
Flat-bed truck ......................................................... 9-16
Tie-down hooks ...................................................... 9-14
Weight .................................................................. 8-22
Traction Control system OFF indicator light .................................................. 3-37
Trailer Connecting ............................................................ 8-20
Hitch ..................................................................... 8-19
Hitches .................................................................. 8-25
Towing .................................................................. 8-21
Towing tips ............................................................ 8-27
Trip meter .................................................................. 3-25
Trunk lid .................................................................... 2-24
Release handle ...................................................... 2-25
Trunk light ............................................................... 11-59 Index
14-9
