2009 SKODA YETI technical data

Starting-off and Driving
113
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Releasing the handbrake– Pull the handbrake lever up slightly and
at the same time
press in the locking
button
⇒fig. 116
.
– Hold the button pressed and push the handbrake lever down fully
⇒
.
The handbrake warning light
 lights up when the handbrak
e is applied, provided the
ignition is on. A warning signal sounds and the following text
appears in the display* if you have inad-
vertently driven off with the handbrake applied:
Handbrake on
The handbrake warning is acti
vated if you drive at a speed of more than 6 km/h for
more than 3 seconds.
WARNING
•
Please note that the handbrake must be fully released. A handbrake which
is only partially released can result in the rear brakes overheating which will have a negative effect on the operation of
the brake system - risk of accident! In
addition this can result in premature wear of the rear brake pads.•
Never leave children unattended in the vehicle. The children might, for
example, release the handbrake or take
the vehicle out of gear. The vehicle
might then move off - risk of accident!
Caution
After the car has come to a stop, always firs
t of all apply the handbrake firmly before
then additionally engaging a gear (manual gearbox) or moving the selector lever into position
P (automatic gearbox).
Rear parking aid*The parking aid provides a warning
of obstacles behind the vehicle.
The audible parking aid determines the di
stance between the rear bumper and an
obstacle located behind the ve
hicle with the aid of ultras
ound sensors. The tones of
the parking aid can be adapted in th
e menu of the information display*
⇒page 27.
The sensors are integrated in the rear bumper. Range of sensors The clearance warning begins at a distance
of about 160 cm from the obstacle (area
⇒ fig. 117
). The interval between the warning signals becomes shorter as the clear-
ance is reduced. A continuous tone sounds from
a distance of approx. 30
cm (area ) - danger area.
You should not reverse any further after this signal sounds!
If the vehicle is
equipped with a factory-fitted
towing device*, the border of the danger area starts,
continuous tone, 5 cm furt
her behind the vehicle. Th
e vehicle can be extended
through an installed deta
chable towing device.
On vehicles equipped with a factory-fitted
radio* or navigation system*, the distance
to the obstruction is shown graphically in the display. On vehicles with a factory-fitted towing device, the sensors are deactivated when towing a trailer. The driver is informed about this by a graphic display (vehicle towing
a trailer) in the radio* or the navigation*
display. The radio* or navigation system*, which is factory-fitted, can be set so that the play function volume decreases when acti
vating the parking ai
d, see Owner's Manual
radio* or navigation system*. This impr
oves the audibility of the parking aid.
Fig. 117 Parking aid: Detection range of rear sensors
AA
AB
sgg.6.book Page 113 Thursday, September 24, 2009 2:32 PM

Starting-off and Driving
115
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
set so that the play function volume decr
eases when activating the parking aid, see
Owner's Manual radio* or na
vigation system*. This impr
oves the audibility of the
parking aid. Activating The parking aid is activated when the
reverse gear
is engaged and the ignition is
turned on or by pressing the button
⇒page 114, fig. 118
- the symbol lights up in
the button. The activation is confirme
d by a brief acknowledgement signal.
Deactivating The parking aid is deactivated after pressing the button°
⇒page 114, fig. 118
or at
a speed of more than 10 km/h - the symbol
 in the button is no longer illuminated.
WARNING
•
The parking aid is not a substitute for the driver paying proper attention and
it is always the driver's responsibility to
take care when reversing the vehicle or
carrying out similar manoeuvres.•
You should therefore satisfy yourself, befo
re reversing, that there is no small
obstacle, such as a rock, thin post, trailer drawbar etc., in front or behind your vehicle. Such an obstacle might not be
within the range dete
cted by the sensors.
•
Under certain circumstances, surfaces
of certain objects and types of
clothing cannot reflect the signal of th
e parking aid. Thus, these objects or
people who wear such clothing are not re
cognised by the sensors of the parking
aid.
Note
•
Only the front parking aid operates if yo
u are towing a trailer (applies only to
models which feature a factory-fitted towing device*).•
If a warning signal sounds for about 3 seco
nds after activating the system and there
is no obstacle close to your
vehicle, this indicates a system fault. The fault is confirmed
additionally when the symbol flashes in the button
⇒page 114, fig. 118
. Have the
fault rectified by a specialist workshop.•
The sensors must be kept clean and free of ice to enable the parking aid to operate
properly.
•
If the parking aid is activated and the sele
ctor lever of the automatic gearbox is in
the position , warning signal indicates inte
rruption (vehicle can no longer move).
Park Assist*Description and important informationThe park assist assists you when parking in a suitable parallel parking space between two vehicles or
behind a vehicle.
The park assist automatically searches for
suitable parking spaces
after switching on
the ignition and when driving up to 30 km/h. During the parking procedure the park assist only takes over the steering movements, the pedals continue to be operated by the driver. Function of the system is based on:•
Length and depth measurement of the parking spaces when driving
•
Evaluation of the size of the parking space
•
Definition of the correct position of the vehicle for parking
•
Calculating the line on which the vehicle drives backwards into the parking space
•
Actuation of the steering force assistance, automatic spinning of the wheels of the
front axle when parking.
WARNING
The park assist does not take away the responsability from the driver when parking.•
Pay particular attention to small children and animals as they would not be
recognised by the sensors of the parking aid.•
Under certain circumstances, surfaces of certain objects and types of
clothing cannot reflect the signal of the park assist or the parking aid. Thus, these objects or people who wear such clothing are not recognised by the sensors of the parking aid.



AP
sgg.6.book Page 115 Thursday, September 24, 2009 2:32 PM

Starting-off and Driving
117
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Note
•
If the park assist is switched on, a yell
ow warning light lights up in the button.
•
The search for suitable parking spaces is
automatic after switching on the ignition
at speeds of more than 30 km/h. Searching for a parking space is performed at the same time on the driver and front passenger side.•
If the sensors find a suitable parking space, they store its parameters until another
suitable parking space has been found or until
a distance of 10 m had been driven after
finding the parking space. This is why it is
possible to switch on the park assist after
driving past the parking space, the information on whether this parking space is suit- able for parking appears in the information display*.Parking with the help of the park assist and concluding the parking procedureFig. 120 Information display: the determined pa
rking space with the information to drive on
and for engaging the reverse gear
Fig. 121 Information display: Information for
engaging the forward gear or the reverse
gear The time limit for the parking procedure with the help of the park assist lasts 180 seconds. – If the park assist has recognised a suitable parking space, it is shown in the infor-
mation display*
⇒fig. 120
.
– Drive on further until the display
⇒fig. 120
appears.
– Bring the vehicle to a stop for at least 1 second.– Engage the reverse gear or set the selector lever* in the position
R.
– As soon as the following message is shown in the information display*:
Steering
interv. active. Monitor area around veh.!
, let go of the steering wheel, the
steering will be taken over by the system.
– Observe the surroundings and drive backwards with a speed of maximum 7 km/h,
at the same time operate the pedal.
– In the event that the parking procedure cannot be carried out in one go, proceed
to parking in further stages. If the forward arrow flashes in the information display* ⇒ fig. 121
, engage the forward gear.
– Observe the surroundings and drive forw
ards with a speed of maximum 7 km/h.
–If the backward arrow
⇒fig. 121
flashes in the information display*, once again
engage the reverse gear or move the selector lever* into the position
R and care-
fully drive backwards. You can repeat these steps several times.
AA
AB
AC
AD
AA
AB
AC
AD
sgg.6.book Page 117 Thursday, September 24, 2009 2:32 PM

Starting-off and Driving
119
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Park Assist: Speed too low. After the ignition is switched on, the vehicle must exceed the speed of 10 km/h at least once.Cruise control system (CCS)*IntroductionThe cruise control system (CCS) maintains
a constant speed, more than 30 km/h (20
mph), once it has been set, without you havi
ng to depress the accelerator pedal. This
is only possible within the range which is permitted by the power output and braking power of the engine. The cruise control system
makes it possible - particularly on long
journeys - for you to rest your “accelerator foot”.
WARNING
•
The cruise control system must not, for safety reasons, be used in dense
traffic or on unfavourable road surfaces
(such as icy roads, slippery roads or
loose chippings) - risk of accident!•
In order to prevent unintentional use of the cruise control system, always
switch off the system after use.
Note
•
Models fitted with a manual gearbox: Always
depress the clutch pedal if you switch
on the cruise control system when the gearbox is in Neutral. Otherwise the engine can rev up unintentionally.•
The cruise control system is not able to
maintain a constant speed when driving on
steep downhill sections. The weight of the vehicle increases the speed at which it travels. One should shift down in good time
to a lower gear or slow the vehicle down
by applying the foot brake.•
It is not possible on vehicl
es fitted with an automati
c gearbox to switch on the
cruise control system if the selector lever is in the position
P, N or R.
Storing a speedThe cruise control system is operated by means of the switch and rocker button in the left lever of the multi-functional switch. – Press the switch
⇒fig. 122
into the position
ON
.
– After the desired speed has been reached, press the rocker button into the
SET

position.
After you have released the rocker button out of the position
SET
, the speed you
have just stored is maintained at a consta
nt speed without having to depress the accel-
erator. You can
increase
the speed by depressing the accelerator. Releasing the accelerator
will cause the speed to
drop
again to the set speed.
This does not apply, however, if you drive at a speed which is more than 10 km/h higher than the set speed for a period of longer than 5 minutes. The stored speed will be cancelled in the memory. You then have to re-store the desired speed. One can
reduce
the speed in the usual manner. The system is switched off temporarily
by actuating the brake or clutch pedal
⇒page 120.
WARNING
First ensure that it is not too high for the traffic conditions which exist at that moment before resuming the stored speed.
Fig. 122 Operating lever: Rocker button and switch of cruise control system
AA
AB
AA
AB
AB
sgg.6.book Page 119 Thursday, September 24, 2009 2:32 PM

Automatic gearbox DSG*
121
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Automatic gearbox DSG*Automatic gearbox DSG*IntroductionYour car is equipped with an automatic
gearbox DSG. The abbreviation DSG means
Direct shift gearbox (Direct shift gearbox). Two independent clutches are needed for the power transmission between the engine and the gearbox. These replace the torque converter of the conventional automatic gearbox. Their shifting is matched in such a
way that there are no jerks when shifting
the gear and the power transmission of the engine to the front wheels is not interrupted.Information for driving with the automatic gearbox DSG Shifting up and down through the gears is performed automatically.You can also, however, switch the gearbox over into the
Tiptronic mode
. This mode
makes it possible for you to also shift gears manually
⇒page 124.
Starting-off and Driving– Depress the brake pedal fully and keep it depressed. – Press the Shiftlock button (button in ha
ndle of the selector lever), move the
selector lever into the
desired position, e.g.
D ⇒page 122, and then release the
Shiftlock button.
– Release the brake pedal and depress the accelerator
⇒
.
Stopping for a short time– The selector lever position
N does not have to be selected when stopping just for
a short time, such as at a cross roads. It
is sufficient to hold
the vehicle stationary
using the foot brake. The engine can, however, be allowed just to idle.
Parking– Depress the brake pedal and hold it depressed.
– Apply the handbrake firmly. – Press and Shiftlock button in the selector lever, move the selector lever to
P and
then release the Shiftlock button.
The engine can only be
started
when the selector lever is in position
P or N
⇒ page 110. At temperatures below -10 °C the engine can only be started in the selector lever position
P.
It is sufficient to engage selector lever position
P when parking on a flat surface. When
parking on a slope you should first apply
the handbrake firmly and then move the
selector lever into position
P. This is to ensure that there is no excessive pressure acting
on the lock mechanism and that it is easier to subsequently move the selector lever out of position
P.
If the selector lever position
N is selected by accident while driving it is first necessary
to release pressure on the accelerator pedal and wait for idling speed of the engine to be reached before engaging a driv
e position in the selector lever.
WARNING
•
Do not depress the accelerator when changing the position of the selector
lever if the car is stationary and the engine is running - risk of accident!•
Never move the selector lever into position R or P when driving - risk of an
accident!•
If you are stopping at a hill (downhill section), never try to hold the car
stationary with the gear engaged by mean
s of the “accelerator”, this means by
letting the clutch slip. This can lead to ov
erheating of the clutch
. If there is a risk
of overheating of the clutch due to overlo
ad, the clutch is op
ened automatically
and the vehicle rolls backward - risk of accident!•
If yo u m us t s to p a t a sl ope , d e pre s s a nd ho ld t he b ra ke pe d a l , s o t ha t y ou c a n
prevent the vehicle from rolling back.
sgg.6.book Page 121 Thursday, September 24, 2009 2:32 PM

Automatic gearbox DSG*
123
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
WARNING
•
Never move the selector lever into position R or P when driving - risk of an
accident!•
When the engine is running and the vehicle is stationary, it is necessary to
hold the car with the brake pedal in all the positions of the selector lever (except P and N) since the power transmission is never completely interrupted, also not when the engine is idling - the vehicle creeps. •
You must on no account unintentionally operate the throttle (e.g. by hand
from the engine compartment) if a driv
e position is engaged when the car is
stationary. The vehicle would otherwise
immediately start of
f - also when the
handbrake is firmly applied - risk of an accident!•
You must move the selector lever into position P and firmly apply the hand-
brake first before you or any other person opens the bonnet and starts working on the engine when it is running - risk of
accident! It is also essential to observe
all warnings
⇒page 204, “Working in the engine compartment”.
Selector lever lockAutomatic selector lever lock

With the ignition on, the selector lever is locked when it is in the positions
P and
N. You
must first of all depress the brake pedal in or
der to move the selector lever out of this
position. The warning light
 ⇒page 35 lights up in the instrument cluster as a
reminder for the driver when the selector lever is in position
P and
N.
A time delay element ensures that the selector lever is not blocked when rapidly switching over the position
N (e.g. from
R to D). This does, for example, allow one to
seesaw out a stuck vehicle. The selector lever lo
ck will click into place if the lever is in
the
N position for more than 2 seconds without the brake pedal being pressed.
The selector lever lock is only active if the
vehicle is stationary or
moving at speed of
less than 5 km/hour. The lock is swit
ched off automatically into position
N when the
car is travelling at a higher speed. Shiftlock button The Shiftlock button in the hand
le of selector lever prevents certain selector lever posi-
tions being engaged inadvertently. The selector lever lock is cancelled when you press the Shiftlock button.
Keylock - Ignition key withdrawal lock You can only withdraw the ignition key after
switching off the ignition if the selector
lever is in position
P. If the ignition key is withdrawn,
the selector lever is blocked in
position
P.
Kickdown function The kickdown function provides you with maximum acceleration power.Fully depressing the a
ccelerator pedal allows the kickdown function to be activated in
the desired driving program. This function has precedence over the driving programme and serves for maximum accelerati
on of the vehicle when exploiting the
maximum power potential of the engine wi
thout taking into account the current
selector lever position (
D, S or Tiptronic
). The gearbox shifts down to one or several
gears in line with the driving state and the vehicle accelerates. The gearbox does not shift up into the highest gear until the en
gine has reached its maximum revolutions for
this gear range.
WARNING
Please note that using the kickdown f
unction can result in the driven wheels
spinning on a smooth or slippery road surface - risk of skidding!Dynamic shift programmeThe automatic gearbox of your vehicle is
controlled electronically. Shifting up and
down through the gears is performed automatically on the basis of pre-defined driving programmes. Adopting a
moderate style of driving
will cause the gearbox to select the most
economical driving programme. Shifting up into a higher gear as soon as possible and shifting down as late as po
ssible will have a favourable effect on your fuel consump-
tion. Adopting a
sporty style of driving
with rapid movements of the accelerator pedal
combined with sharp acceleration and freque
nt changes in speed, exploiting the top
speed of the car or depressing the accele
rator pedal (kickdown function), will cause
sgg.6.book Page 123 Thursday, September 24, 2009 2:32 PM

Automatic gearbox DSG*
125
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Selector lever-emergency unlockingIn case of interruption of the power supply (e
.g. flat vehicle battery, defective fuse) or
defect of the selector lever lock, the select
or lever can no longer be shifted from the
position
P in the normal way and the vehicle ca
n no longer be moved. The selector
lever must be unlocked in case of emergency. – Apply the handbrake firmly.– Carefully pull up the front left and right cover. – Pull up rear cover. – Use the finger to press the yellow plastic part downwards
⇒fig. 125
.
– Simultaneously press the shiftlock button in
the handle of the selector lever in the
position
N10).
Tow-starting and towing vehicle Tow-starting a vehicle It is not possible to tow-start vehicles fitted with automatic gearbox
⇒page 230.
You can use jump-start cables connected to
the battery of another vehicle for starting
your car if the vehicle battery is flat
⇒page 229.
Towing a vehicle Please pay attention to the following information if it comes necessary to tow-in your car
⇒page 230.
10)If the selector lever is moved again into the position
P, it is once again blocked.Fig. 125 Selector lever-emergency unlocking
sgg.6.book Page 125 Thursday, September 24, 2009 2:32 PM

Communication
127
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
sgg.6.book Page 127 Thursday, September 24, 2009 2:32 PM
