Five things that do not indicate a
problem with the fuel gage:
At the gas station, the fuel pump
shuts off before the gage reads
F or full.
It takes a little more or less fuel
to ll up than the gage indicated.
For example, the gage may
have indicated the tank was half
full, but it actually took more
or less than half the tank’s
capacity to ll it.
It takes the gage several minutes
to read F or full after lling the
vehicle with fuel.
The gage moves a little when
you turn, stop or speed up.
The gage does not go back to
E or empty when you turn off
the ignition.
Low Fuel Warning Light
This light, on the fuel gage, comes
on when the fuel tank is low on
fuel. To turn if off, add fuel to the
fuel tank.
OnStar®System
OnStar uses several innovative
technologies and live advisors to
provide a wide range of safety,
security, information, and
convenience services. If the airbags
deploy, the system is designed to
make an automatic call to OnStar
Emergency advisors who can
request emergency services be
sent to your location. If the keys are
locked in the vehicle, call OnStar at
1-888-4-ONSTAR to have a signal
sent to unlock the doors. OnStar
Hands-Free Calling, including
30 trial minutes good for 60 days, is
available on most vehicles. Press the
OnStar button to have an OnStar
advisor contact Roadside Service. United States
Canada
Instruments and Controls 4-25
2009 - Pontiac Vibe Owner Manual

Lighting
Lighting
Exterior Lamps Controls.....5-1
Daytime Running
Lamps (DRL)....................5-2
Automatic Headlamp
System.............................5-2
Fog Lamps.........................5-2
Instrument Panel
Brightness.........................5-3
Dome Lamp(s)....................5-3
Entry Lighting.....................5-3
Reading Lamps..................5-4
Battery Run-Down
Protection.........................5-4
Lighting
Exterior Lamps Controls
The lever on the left side of the
steering column operates the
exterior lamps.
P/;(Exterior Lamps):Turn the
outside band of the lever to operate
the lamps. For vehicles sold in the
U.S.,
Pappears on the instrument
panel cluster when the exterior
lamps are on. For vehicles rst
sold in Canada,
;appears in the
instrument panel cluster. SeeLights
On Reminder on page 4-23.The exterior lamp switch has three
positions:
((Off):Turns off all lamps, except
the Daytime Running Lamps (DRL).
;(Parking Lamps):Turns on
the parking lamps together with the
following:
Sidemarker Lamps
Taillamps
License Plate Lamp
Instrument Panel Lights
5(Headlamps):Turns on the
headlamps, together with the
previously listed lamps and lights.
Headlamps on Reminder
A tone sounds when the ignition is
turned to LOCK/OFF, the driver
door is opened and the key
is removed from the ignition while
the lamps are on.
Lighting 5-1
2009 - Pontiac Vibe Owner Manual

Instrument Panel
Brightness
Use the trip odometer knob located
on the right side of the instrument
panel cluster to adjust the
instrument panel brightness.
Turn the knob clockwise or
counterclockwise to brighten
or dim the instrument panel.
The brightness of the instrument
panel lights decreases when
the headlamps are on.
Dome Lamp(s)
The interior lamps control is located
on the overhead lamp. To change
the interior lamps setting, slide
the switch to one of the following
positions:
OFF:Turns the lamp off.
ON:Keeps the lamp on all
the time.
Door:Turns the lamp on when
any door or the liftgate is opened.
The lamp goes off when all the side
doors and the liftgate are closed.
If the lamp switch is in the door
position and a door is left open,
the lamps will go off automatically
after 20 minutes.
Entry Lighting
After all the doors and liftgate
are closed, and the key is out of
the ignition, in LOCK/OFF or
ACC/ACCESSORY, the light
remains on for about 15 seconds
and then goes out, except under
the following conditions:
The ignition is turned to
ACC/ACCESSORY or ON/RUN
after all the doors and liftgate
are closed.
All the doors and the liftgate are
locked and the light is still on.
When any door is unlocked with the
key or Remote Keyless Entry (RKE)
system transmitter, the light comes
on for 15 seconds, even if the door is
not opened.
Lighting 5-3
2009 - Pontiac Vibe Owner Manual

Setting the Clock
The radio has a CLOCK button for
adjusting the time and date.
The date does not automatically
display. To see the date press
CLOCK while the radio is on.
The date with display times out after
a few seconds and goes back to
the normal radio and time display.
To adjust the time and date:
1. Turn the ignition key to
ACC/ACCESSORY or ON/RUN.
2. Press the PWR VOL
(Power/Volume) knob to
turn on the radio.
3. Press the CLOCK button, and
the HR, MIN, MM, DD, YYYY
(hour, minute, month, day,
and year) categories display.
4. Press the button under the
category to be adjusted.5. To increase the time or date,
do one of the following: turn
the TUNE ADJ (Tune/Adjust)
knob clockwise, press
SEEK/TRACK
y, press
FWD
((Forward), or continue
to press the button under the
category to be adjusted.
6. To decrease the time or date,
do one of the following:
turn the TUNE ADJ knob
counterclockwise, press
SEEK/TRACK
z, or press
REV
)(Reverse).
7. To save the settings, press
the CLOCK button, or let
the display time out.To change the time default setting
from 12 hour to 24 hour, and to
change the date default setting from
month/day/year to day/month/year:
1. Press the CLOCK button
and then the button below the
forward arrow label on the
display. The 12H and 24H, and
the date MMDD (month and
day) and DDMM (day and month)
categories will display.
2. Press the button below the
12H or 24H label, and the
date MMDD (month and day) or
DDMM (day and month) label
to choose how the radio displays
the time and date.
3. To save the settings, press
the CLOCK button, or let
the screen time out.
6-2 Infotainment
2009 - Pontiac Vibe Owner Manual

Starting and
Operating Your
Vehicle
New Vehicle Break-In
Notice:The vehicle does
not need an elaborate break-in.
But it will perform better in
the long run if you follow
these guidelines:
Do not drive at any one
constant speed, fast or slow,
for the rst 500 miles (805 km).
Do not make full-throttle
starts. Avoid downshifting
to brake or slow the vehicle.
Avoid making hard stops for
the rst 200 miles (322 km) or
so. During this time the new
brake linings are not yet broken
in. Hard stops with new linings
can mean premature wear and
earlier replacement. Follow this
breaking-in guideline every
time you get new brake linings.
Do not tow a trailer during
break-in. SeeTowing a Trailer
on page 9-77for the trailer
towing capabilities of your
vehicle and more information.
Following break-in, engine speed
and load can be gradually
increased.
Ignition Positions
The ignition switch has four different
positions.
To shift out of P (Park), turn the
ignition to ON/RUN and apply
the brake pedal.
Notice:Using a tool to force the
key to turn in the ignition could
cause damage to the switch or
break the key. Use the correct key,
make sure it is all the way in, and
turn it only with your hand. If the
key cannot be turned by hand,
see your dealer/retailer.
8-2 Driving and Operating
2009 - Pontiac Vibe Owner Manual

LOCK/OFF:This is the only position
from which you can remove the key.
This locks the steering wheel,
ignition and automatic transmission.
Push in the ignition switch as you
turn the key toward you.
On vehicles with an automatic
transmission, the shift lever must be
in P (Park) to turn the ignition switch
to the LOCK/OFF position.
A warning tone will sound if the driver
door is opened with the key in the
ignition.
The ignition switch can bind in the
LOCK/OFF position with your wheels
turned off center. If this happens,
move the steering wheel from right
to left while turning the key to
ACC/ACCESSORY. If this doesn’t
work, then the vehicle needs service.{CAUTION
On manual transmission vehicles,
turning the key to LOCK/OFF and
removing it will lock the steering
column and result in a loss of
ability to steer the vehicle.
This could cause a collision.
If you need to turn the engine
off while the vehicle is moving,
turn the key only to ACC/
ACCESSORY. Do not push the
key in while the vehicle is moving.
ACC/ACCESSORY:This position
provides power to some of the
electrical accessories. It unlocks the
steering wheel and ignition. To move
the key from ACC/ACCESSORY to
LOCK/OFF, push in the key and then
turn it to LOCK/OFF.
A warning tone will sound when
the driver door is opened when the
ignition is still in ACC/ACCESSORY
or LOCK/OFF and the key is in the
ignition.ON/RUN:The ignition switch stays
in this position when the engine is
running. This position can be used to
operate the electrical accessories,
including the ventilation fan and
115 volt power outlet, as well as to
display some warning and indicator
lights. The transmission is also
unlocked in this position on
automatic transmission vehicles.
The battery could be drained
if you leave the key in the ACC/
ACCESSORY or ON/RUN position
with the engine off. You may not be
able to start the vehicle if the battery
is allowed to drain for an extended
period of time.
START:This position starts the
engine. When the engine starts,
release the key. The ignition switch
will return to ON/RUN for normal
driving.
Driving and Operating 8-3
2009 - Pontiac Vibe Owner Manual

Retained Accessory
Power (RAP)
These vehicle accessories may be
used for less than a minute after
the engine is turned off.
Power Windows, if equipped
Sunroof, if equipped
The power windows and sunroof
will continue to work for less than a
minute or until either front door is
opened. The radio will work when
the key is in ON/RUN or ACC/
ACCESSORY.
Starting the Engine
Automatic Transmission
Move the shift lever to P (Park) or
N (Neutral). The engine will not start
in any other position. To restart
when you are already moving,
use N (Neutral) only.
Notice:Shifting into P (Park)
with the vehicle moving could
damage the transmission.
Shift into P (Park) only when
your vehicle is stopped.
Manual Transmission
The shift lever should be in
NEUTRAL and the parking brake
engaged. Hold the clutch pedal
to the oor and start the engine.
The vehicle will not start if the clutch
pedal is not all the way down.
Starting Procedure
1. With your foot off the accelerator
pedal, turn the ignition to START.
When the engine starts, let go of
the key. The idle speed will go
down as the engine gets warm.
Vehicles equipped with
the 1.8L engine have a
Computer-Controlled Cranking
System. This feature assists in
starting the engine and protects
components. If the ignition key is
turned to the START position,
and then released when the
engine begins cranking, the
engine will continue cranking for
a about 30 seconds or until the
vehicle starts. If the engine doesnot start and the key is held in
START for many seconds,
cranking will be stopped after
25 seconds to prevent cranking
motor damage. To prevent gear
damage, this system also
prevents cranking if the engine is
already running. Engine cranking
can be stopped by turning
the ignition switch to ACC/
ACCESSORY or LOCK/OFF.
Vehicles equipped with the
2.4L engine should not be
cranked for more than
30 seconds at a time.
This may overheat the
starter and wiring systems.
Notice:Holding the key in
START for longer than 15 seconds
at a time will cause the battery to
be drained much sooner. And
the excessive heat can damage
the starter motor. Wait about
15 seconds between each try to
help avoid draining the battery
or damaging the starter.
8-4 Driving and Operating
2009 - Pontiac Vibe Owner Manual

2. If the engine does not start, wait
about 15 seconds and try again
to start the engine by turning
the ignition to START. Wait about
15 seconds between each try.
When the engine has run
about 10 seconds to warm up,
the vehicle is ready to be driven.
Do not run the engine at high
speed when it is cold.
If the weather is below freezing
(32°F or 0°C), let the engine run
for a few minutes to warm up.
3. If the engine still will not start, or
starts but then stops, it could be
ooded with too much gasoline.
Try pushing the accelerator pedal
all the way to the oor and holding
it there as you hold the key in
START for about three seconds.
If the vehicle starts briey but then
stops again, do the same thing,
but this time keep the pedal down
for ve or six seconds. This clears
the extra gasoline from the
engine.Notice:The engine is designed
to work with the electronics in
the vehicle. If electrical parts or
accessories are added, you could
change the way the engine
operates. Before adding electrical
equipment, check with your
dealer/retailer. If you do not,
the engine might not perform
properly. Any resulting damage
would not be covered by the
vehicle warranty.
Engine Coolant Heater
The engine coolant heater, if
available, can help in cold weather
conditions at or below 0°F (−18°C)
for easier starting and better fuel
economy during engine warm-up.
Plug in the coolant heater at least
four hours before starting the vehicle.
To Use the Engine Coolant
Heater
1. Turn off the engine.
2. Open the hood and unwrap the
electrical cord. The electrical
cord is located on the driver side
of the engine compartment.
3. Plug it into a normal, grounded
110-volt AC outlet.
{CAUTION
Plugging the cord into an
ungrounded outlet could cause
an electrical shock. Also, the
wrong kind of extension cord could
overheat and cause a re. You
could be seriously injured. Plug the
cord into a properly grounded
three-prong 110-volt AC outlet.
If the cord will not reach, use a
heavy-duty three-prong extension
cord rated for at least 15 amps.
Driving and Operating 8-5
2009 - Pontiac Vibe Owner Manual
