2009 PONTIAC G6 Owners Manual

{CAUTION:
Fuel can spray out on you if you open the fuel cap
too quickly. If you spill fuel and then something
ignites it, you could be badly burned. This spray
can happen if the tank is nearly full, and is more
likely in hot weather. Open the fuel cap slowly and
wait for any hiss noise to stop. Then unscrew the
cap all the way.
Be careful not to spill fuel. Do not top off or overll the
tank, and wait a few seconds after you have nished
pumping before removing the nozzle. Clean fuel
from painted surfaces as soon as possible. See
Washing Your Vehicle on page 5-105.
When replacing the fuel cap, turn it clockwise until it
clicks. Make sure the cap is fully installed. The diagnostic
system can determine if the fuel cap has been left off or
improperly installed. This would let fuel evaporate into
the atmosphere. SeeMalfunction Indicator Lamp on
page 3-38.The CHECK GAS CAP message displays on the Driver
Information Center (DIC) if the fuel cap is not properly
installed. SeeDIC Warnings and Messages on
page 3-46for more information.
{CAUTION:
If a re starts while you are refueling, do not
remove the nozzle. Shut off the ow of fuel by
shutting off the pump or by notifying the station
attendant. Leave the area immediately.
Notice:If you need a new fuel cap, be sure to get
the right type. Your dealer/retailer can get one
for you. If you get the wrong type, it may not t
properly. This may cause the malfunction indicator
lamp to light and may damage the fuel tank and
emissions system. SeeMalfunction Indicator Lamp
on page 3-38.
5-11

Filling a Portable Fuel Container
{CAUTION:
Never ll a portable fuel container while it is in the
vehicle. Static electricity discharge from the
container can ignite the fuel vapor. You can be
badly burned and the vehicle damaged if this
occurs. To help avoid injury to you and others:
Dispense fuel only into approved containers.
Do not ll a container while it is inside a
vehicle, in a vehicle’s trunk, pickup bed, or on
any surface other than the ground.
Bring the ll nozzle in contact with the inside
of the ll opening before operating the nozzle.
Contact should be maintained until the lling
is complete.
Do not smoke while pumping fuel.
Do not use a cellular phone while
pumping fuel.
Checking Things Under
the Hood
{CAUTION:
An electric fan under the hood can start up and
injure you even when the engine is not running.
Keep hands, clothing, and tools away from any
underhood electric fan.
{CAUTION:
Things that burn can get on hot engine parts and
start a re. These include liquids like fuel, oil,
coolant, brake uid, windshield washer and other
uids, and plastic or rubber. You or others could
be burned. Be careful not to drop or spill things
that will burn onto a hot engine.
5-12

Hood Release
To open the hood:
1. Pull the handle with
this symbol on it. It is
located under the
instrument panel on
the driver side of
the vehicle.
2. Then go to the front of the vehicle and push the
secondary hood release lever to the right.
3. Lift the hood, release the hood prop rod from its
retainer, and put the hood prop into the slot in the
hood marked with an arrow.
Before closing the hood, be sure all the ller caps are
on properly. Then lift the hood to relieve pressure on the
hood prop. Remove the hood prop from the slot in the
hood and return the prop to its retainer. Then let
the hood down and close it rmly.
5-13

Engine Compartment Overview
When you open the hood on the 2.4L L4 engine, this is what you see:
5-14

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B. Engine Cooling Fan. SeeCooling System on
page 5-32.
C. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
D. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” underEngine Oil on page 5-21.
E. Engine Coolant Surge Tank. SeeEngine Coolant
on page 5-33.F. Pressure Cap. SeeCooling System on page 5-32.
G. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 5-42.
H.Battery on page 5-45.
I. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
J.Engine Compartment Fuse Block on page 5-112.
5-15

When you open the hood on the 3.5L V6 engine, this is what you see:
5-16

A.Engine Air Cleaner/Filter (3.5 L V6 Engine) on
page 5-26orEngine Air Cleaner/Filter (All Other
Engines) on page 5-27.
B.Power Steering Fluid on page 5-39.
C. Engine Cooling Fan. SeeCooling System on
page 5-32.
D. Engine Oil Fill Cap. See “When to Add Engine Oil”
underEngine Oil on page 5-21.
E. Engine Oil Dipstick. See “Checking Engine Oil”
underEngine Oil on page 5-21.
F. Engine Coolant Surge Tank. SeeEngine Coolant
on page 5-33.G. Pressure Cap. SeeCooling System on page 5-32.
H. Brake Master Cylinder Reservoir. See “Brake
Fluid” underBrakes on page 5-42.
I.Battery on page 5-45.
J. SeeEngine Compartment Fuse Block on
page 5-112.
K. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” underWindshield Washer Fluid
on page 5-40.
5-17

When you open the hood on the 3.6L V6 engine, this is what you see:
5-18
