2009 Peugeot Bipper Dag Owner's Manual

4 PRESENTATION
The handbook is designed to familiarise you with your new
vehicle from the moment you get behind the wheel an d to
describe the operating features.
Reading the handbook is made easy by a Familiarisa tion
chapter, followed by 8 identified chapters which ca n be located
by means of a colour code specific to each one. Its sections
cover, by theme, all of the functions of the vehicl e in its most
complete specification.
Chapter 2 indicates all of the technical data rela ting to your
vehicle. At the end of the handbook, diagrams of th e outside
and inside of the vehicle will assist you in locati ng equipment
or functions and page numbers refer you to the rele vant
section of the handbook. Within the chapters symbols draw your attention to
specific
information:
directs you to the chapter and section which conta ins
detailed information concerning a function,
indicates important information relating to use of the
equipment,
alerts you to the safety of individuals and equipm ent on
board.
PEUGEOT
The technical data, equipment and accessories may change
during the year. To obtain this new data, refer to the "Latest
Information" section on the SERVICE BOX Internet si te, free
of charge.
http://public.servicebox.peugeot.com , select:
- your model,
- the body type: saloon, CC, SW, estate, van…,
- the period corresponding to the date of fi rst registratio n,
- the "Latest Information" section.
COMMUNICATION PUTS AN INTERNET SITE AT YOUR DISPOSAL

5
FAMILIARISATION
Familiarisation
EXTERIOR
Roof rack and roof bars
Fixing points are provided on each side of the
roof for securing the roof rack or the transverse
roof bars.

 109
Opening the hinged rear doors to 180°
Once the vehicle has been unlocked, the
hinged rear doors can be opened to 180° to
make unloading/loading operations easier.

 34
Rear parking assistance
This equipment warns you, by means of an
audible signal, if an obstacle is detected behind
the vehicle when reverse gear is engaged.

 68
Guide-me-home lighting
After switching off the ignition, when you leave
your vehicle, the front lamps remain on briefl y.

 39

6
Familiarisation
OPEN
Remote control key

A. Unfolding/Folding of the key.

B. Unlocking of the front doors only (Light
van) or of all of the doors (Combi)
(two fl ashes of the direction indicators).

C. Central locking of the vehicle
(one press; one fl ash of the direction indicators).
or
Deadlocking of the vehicle
(two consecutive presses; one fl ash of the direction indicators).

D. Unlocking of the load space (Light van) or
of the hinged rear doors or tailgate only
(Combi).
If a door is open or has not been closed
properly, the failed locking is indicated by three
fl ashes of the direction indicators.
Fuel tank

1. Opening of the fuel fi ller fl ap.

2. Opening and hooking of the fuel tank cap.
Capacity of the tank: approximately 45 litres.

 29
 129
Opening to 180°

 34
Press the catch while opening the door.

7
FAMILIARISATION
Familiarisation
INTERIOR
Trip computer
By means of the MENU button, this system
permits management or consultation of the
various vehicle confi gurations/information such
as the disarming of the passenger air bag, the
automatic locking of the doors, the language,
etc.

 64
Retractable multifunction passenger
seat
This equipment enables you to confi gure your
passenger seat in three positions:
- seat for the transportation of a passenger,
- table to accommodate your various
documents... ,
- retracted for the transportation of long objects.

 76
Audio system
This equipment benefi ts from the latest
technology: MP3 compatible audio equipment
and Bluetooth ®
hands-free kit.

 69
Cruise control/speed limiter
These two systems maintain the speed of the
vehicle at the programmed value.

 41, 44
Electronic gearbox system
This equipment guarantees perfect driving
by combining a fully automatic mode and a
manual mode.

 50

8
Familiarisation INSTRUMENTS AND CONTROLS

1. Steering wheel adjustment control.

2. Lights and direction indicators controls.

3. Instrument panel.

4. Driver's air bag.
Horn.

5. Cruise control/speed limiter switches.

6. Gear lever.

7. Handbrake.

8. Bonnet release.

9. Exterior mirror controls.

10. Fuse box.

11. Manual headlamp height adjustment.

12. Side adjustable and closing vent.

13. Front side window demisting vent.

14. Windscreen demisting vent.

15. Steering lock and ignition.

16. Wipers/wash-wipe/trip computer controls.

17. Central adjustable and closing vents.

18. Passenger air bag.

19. MENU button.

20. Glove box.

21. Lighter.

22. Ashtray.

23. Heating/air conditioning controls.

24. Audio equipment.

25. Electric window controls.

26. 12 V accessories socket.

9
FAMILIARISATION
Familiarisation
LOAD SPACE (LIGHT VAN)

1. Stowing rings.

2. Storage tray.

3. Torch.

4. Partition.

5. Modular vertical grille.

6. Spare wheel.

 87 It is advisable to immobilise the load by
fi xing it securely using the stowing rings

1 on the fl oor.

10
Familiarisation
REAR LAYOUT (COMBI)

 89
With hinged rear doors

1. Stowing rings.

2. Luggage retaining net.

3. Tool kit.

4. Rear shelf.
With tailgate

1. Stowing rings.

2. Luggage retaining net.

3. Rear shelf.

4. Retaining straps/Tool kit.

5. Torch/Boot light.

11
FAMILIARISATION
Familiarisation
SIT COMFORTABLY
Driver's seat adjustment
Forwards-backwards Height Seat back angle (A)
Lumbar support (B)

 74
