In brief15
Activate horn j:
Press either side of the
steering wheel
The horn will sound regardless of ignition
switch position.
6 Airbag systems - see page 52,
remote control on steering wheel -
see page 101.
Windscreen wipers:
Move lever upwards
Press lever down from position J:
Single swipe.
6 Windscreen wipers - see page 92,
adjustable wiper interval - see page 92,
further information - see pages 198, 202,
205.
Automatic wiping with rain
sensor 3:
Move lever to automatic wiping
with rain sensor position $
The rain sensor detects the amount of
water on the windscreen and automatically
regulates the windscreen wipers.
6Windscreen wipers - see page 92,
further information - see pages 198, 202,
205.
J =Off
$ =Timed interval wipe
% =Slow
& =Fast

Locks, doors, windows32
Automatic anti-dazzle interior mirror 3
Dazzle is automatically reduced.
With the ignition off, the mirror does not
dim.
Press button on mirror housing to turn
function on. Button will illuminate.
Press button again to turn off.
There are two light sensors in the mirror
housing. To avoid interference and loss of
function, do not cover the sensors or hang
anything on the mirror.
Electric windows
Operational with key in ignition switch
positions ACC or ON. If key is in LOCK
position or removed, windows can be
operated for 10 minutes or until driver’s
door is opened.
Operated via four switches located in the
driver’s door.
For incremental operation, briefly pull or
press the switch.
For automatic 3 opening or closing, pull or
press the switch longer. Pull or press the
switch again to stop the movement.
9 Warning
Care must be taken when operating the
electrically operated door windows.
There is a risk of injury, particularly for
children, and a danger that articles could
become trapped. Vehicle passengers
must be informed accordingly.
If there are children on the rear seats,
press the switch in the driver’s door to
lock rear window operation. Rear
windows can then only be operated via
the driver’s door switches.
Keep a close watch on the windows when
closing them. Ensu re that nothing
becomes trapped in them as they move.
Before leaving the vehicle, remove the
ignition key in order to prevent
unauthorized operation.

Seats, interior52
Mounting brackets for ISOFIX child
restraint systems
The brackets located between the backrest
and seat cushion are used for mounting
ISOFIX child restraint systems.
The instructions accompanying the ISOFIX
child restraint system are to be expressly
followed.
Only ISOFIX child restraint systems
approved for the vehicle may be used.Anchors for Top-Tether child restraint
systems
The top tether anchors located on the rear
of the backrests are designed to hold child
restraints which come equipped with top
tether anchor attachments only.
Please be sure to follow the instructions
provided with the Top-Tether child
restraint system.
For use of ISOFIX and Top-Tether fixings,
universal ISOFIX child restraint systems
may be used.Airbag systems
Front airbags
The front airbag system
is identified by the
word “Airbag” on the steering wheel and
above the glove compartment.
The front airbag system comprises:
z an airbag with an inflator in the steering
wheel, and a second one behind a trim
panel above the glove compartment,
z the control electronics,
z the front impact sensor,
z the airbag system control indicator v in
the instrument panel.

Seats, interior54
Side airbags 3
The side airbags are identified by the word
"Airbag" on the outboard sides of the front
seat backrests, and protect front seat
occupants in the event of a severe side
impact.
The side airbag system comprises:
z an airbag with inflator in the outboard
sides of the driver's and front
passenger's seat backrests,
z the control electronics,
z the side impact sensors,
z the airbag systems control indicator v in
the instrument panel. The side airbag system will be triggered:
z
depending on the severity of the
accident,
z depending on the type of impact,
z within the range show n in the illustration,
z independently of the front airbag
system. When triggered, the side
airbag inflates in
milliseconds and forms a safety cushion for
the driver and/or front passenger in the
respective door area. The risk of injury to
the upper body and pelvis in the event of a
side impact is thereby substantially
reduced.
9 Warning
There must be no objects in the area in
which the airbag inflates or in the area
between the seat backrests and the
vehicle body.
Do not place hands, arms or other body
parts on the covers of the airbag systems.
Important information - see page 57.
The three-point seat belt must always be
correctly fitted - see page 43.

Seats, interior55
The side airbags will not be triggered in the
event of:
zthe ignition being switched off,
z frontal collisions,
z accidents in which the vehicle overturns,
if lateral impact is insufficient for side
airbag deployment,
z collisions involving a rear impact,
z collisions involving a side impact outside
the passenger cell.
Curtain airbags
The curtain airbag system is identified by
the word "Airbag" on the roof frame, and
protects front seat and rear outboard seat
occupants in the event of a severe side
impact.
The curtain airbag system comprises:
zan airbag with inflator in the roof frame
above the doors on the driver’s and
passenger’s side respectively,
z the control electronics,
z the side impact sensors,
z the airbag systems control indicator v in
the instrument panel. The curtain airbag system will be triggered:
z
depending on the severity of the
accident,
z depending on the type of impact,
z within the range shown in the illustration,
z together with the side airbag system,
z independently of the front airbag
system.

Instruments, controls93
Automatic wiping with rain sensor3
To activate, move lever upwards to
automatic wiping with rain sensor
position $.
The rain sensor detects the amount of
water on the windscreen and automatically
regulates the windscreen wipers.
The wipers operate for one cycle to check
the system when the ignition switch is
turned to ACC.
To turn wipers off, move lever to position J.
Keep the rain sensor area clean by
activating the windsc reen washer system.
Further information - see pages 198, 202,
205. Windscreen and headlamp washer
systems
3
To activate, pull lever towards steering
wheel. Washer fluid is sprayed onto the
windscreen. If the lever is held longer, the
wipers operate for two cycles after the lever
has been released and once more after a
3 second delay 3.
The headlamp washer system 3 can only
be operated when the headlamps are on.
Washer fluid is sprayed onto the
headlamps. The headlamp washer system
can only be operated again after a short
delay. If washer fluid level is low then this
delay is increased.
On vehicles fitted with rain sensor 3, keep
the sensor area clean by activating the
windscreen washer system.
Further information - see pages 199, 202,
205. Tailgate wiper and washer systems
Activate wipers and washer as follows:
Washer fluid is sprayed on to tailgate
window when the button on the end of the
lever is pressed. When the button is
released, the washer will stop, but the
wipers will continue to swipe for approx.
3cycles.
Further information - see pages 198, 199,
202, 205.
Wipers on = Push lever forwards
Wipers off = Pull lever back towards
steering wheel
Wash = Press and hold button

Lighting95
Main beam, headlamp flash
To switch from dipped beam to main
beam, push lever forwards.
To switch back to dipped beam, pull lever
back towards steering wheel.
To activate the headlamp flash, pull lever
towards steering wheel. Main beam is
engaged for the duration of activation.
The blue control indicator P is illuminated
when main beam or headlamp flash is on.
Automatic dipped beam
activation 3
Light switch to AUTO; dipped beam comes
on automatically when the engine is
running, depending on outside light
conditions.
For reasons of safety, the light switch
should always remain in the AUTO
position.
To ensure automatic dipped beam
activation functions properly, do not cover
the light sensor on top of the instrument
panel.
Turn signal lamps
To activate, press lever up or down lightly.
When the steering wheel is turned back, the
lever automatically returns to its rest
position. This will not happen when making
a minor steering manoeuvre such as lane
changing.
Tap signal: briefly move lever to resistance
point. The turn signal then flashes three
times when changing lanes or the like.
Hold the lever if you want the turn signals
to flash for longer. When released, the lever
will spring back to rest position.
The volume of the turn signal lamps’
audible warning is dependent upon vehicle
speed.
Lever up = Right turn
Lever down = Left turn

Climate control112
Automatic air recirculation
The automatic air recirculation system has
an air quality sensor to detect harmful
ambient gases, in which case it will switch
automatically to air recirculation mode.
Press automatic air recirculation button t;
the system provides the optimum settings
for almost all conditions. Control indicator
in the button illuminates when automatic
air recirculation is enabled.
Press button t again to turn automatic air
recirculation system off; control indicator in
the button extinguishes and outside air is
drawn into the vehicle.
The system is only operational when the
engine is running. Automatic mode
Basic setting for maximum comfort:
z
Press AUTO button.
z Open all air vents.
z Set temperature using central rotary
knob.
All air vents are actuated automatically in
automatic mode. The air vents should
therefore always be open - see page 104.
The control indicator in the AUTO button
illuminates when automatic mode has
been selected.
To switch the system off, set fan to x .Temperature preset
The central rotary knob can be used to set
the temperature; 22 °C, 24 °C and 26 °C
appear on the rotary
knob. Intermediate
settings are possible.
The selected temperature is maintained.
At the lowest or highest temperature
setting, the system works at maximum
cooling or heating.
