●Make sure the jumper cables do not
touch moving parts in the engine com-
partment and that the cable clamps do
not contact any other metal.
5. Start the engine of the booster vehicle and
let it run for a few minutes.
For Intelligent Key system equipped models,
use the mechanical key to start the engine.
6. Keep the engine speed of the booster ve-
hicle at about 2,000 rpm, and start the en-
gine of the vehicle being jump started.
CAUTION
Do not keep the starter motor engaged for
more than 10 seconds. If the engine does
not start right away, turn the key off and
wait 3 to 4 seconds before trying again.
7. After starting the engine, carefully discon-
nect the negative cable and then the positive
cable.
8. Replace the vent caps (if so equipped) . Be
sure to dispose of the cloth used to cover
the vent holes as it may be contaminated
with corrosive acid.
CAUTION
●Do not push start this vehicle. The
three-way catalyst may be damaged.
●Automatic Transmission (AT) or Con-
tinuously Variable Transmission (CVT)
models cannot be push-started or tow-
started. Attempting to do so may cause
transmission damage.
●For manual transmission models, never
try to start the vehicle by towing it.
When the engine starts, the forward
surge could cause the vehicle to collide
with the tow vehicle.If your vehicle is overheating (indicated by a red
high temperature warning light) , or if you
feel a lack of engine power, detect abnormal
noise, etc. take the following steps.
WARNING
●Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
●To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator
cap is removed, pressurized hot water
will spurt out, possibly causing serious
injury.
●Do not open the hood if steam is com-
ing out.
1. Move the vehicle safely off the road, apply
the parking brake and move the shift lever to
N (Neutral) (manual transmission) or to P
(Park) (AT or CVT) .
Do not stop the engine.
2. Turn off the air conditioner (if so equipped) .
Open all the windows, move the heater or air
conditioner temperature control to maximum
hot and fan control to high speed.
PUSH STARTING IF YOUR VEHICLE OVERHEATS
In case of emergency6-9
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


3. Get out of the vehicle. Look and listen for
steam or coolant escaping from the radiator
before opening the hood. (If steam or cool-
ant is escaping, turn off the engine.) Do not
open the hood further until no steam or
coolant can be seen.
4. Open the engine hood.
WARNING
If steam or water is coming from the en-
gine, stand clear to prevent getting
burned.
5. Visually check drive belts for damage or
looseness. Also check if the cooling fan is
running. The radiator hoses and radiator
should not leak water. If coolant is leaking,
the water pump belt is missing or loose, or
the cooling fan does not run, stop the en-
gine.
WARNING
Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or get caught in, engine belts or the
engine cooling fan. The engine cooling
fan can start at any time.6. After the engine cools down, check the cool-
ant level in the engine coolant reservoir tank
with the engine running. Add coolant to the
engine coolant reservoir tank if necessary.
Have your vehicle repaired at a NISSAN
dealer.When towing your vehicle, all State (Provincial in
Canada) and local regulations for towing must be
followed. Incorrect towing equipment could dam-
age your vehicle. Towing instructions are avail-
able from a NISSAN dealer. Local service opera-
tors are generally familiar with the applicable laws
and procedures for towing. To assure proper
towing and to prevent accidental damage to your
vehicle, NISSAN recommends having a service
operator tow your vehicle. It is advisable to have
the service operator carefully read the following
precautions:
WARNING
●Never ride in a vehicle that is being
towed.
●Never get under your vehicle after it has
been lifted by a tow truck.
CAUTION
●When towing, make sure that the trans-
mission, axles, steering system and
powertrain are in working condition. If
any of these conditions apply, dollies or
a flatbed tow truck must be used.
●Always attach safety chains before
towing.
TOWING YOUR VEHICLE
6-10In case of emergency
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


The air cleaner filter should not be cleaned and
reused. Replace it according to the maintenance
log shown in the “NISSAN Service and Mainte-
nance Guide.” When replacing the filter, wipe the
inside of the air cleaner filter housing and the
cover with a damp cloth.
To remove the air cleaner filter, push the tabs
1
and pull the unit upward2.
WARNING
●Operating the engine with the air
cleaner removed can cause you or oth-
ers to be burned. The air cleaner not
only cleans the air, it stops the flame if
the engine backfires. If it isn’t there, and
the engine backfires, you could be
burned. Do not drive with the air cleaner
removed, and be careful when working
on the engine with the air cleaner
removed.
●Never pour fuel into the throttle body or
attempt to start the engine with the air
cleaner removed. Doing so could result
in serious injury.
IN-CABIN MICROFILTER (if so
equipped)
The in-cabin microfilter restricts the entry of air-
borne dust and pollen particles and reduces
some objectionable outside odors. The filter is
located behind the glove box. Refer to the
“NISSAN Service and Maintenance Guide” for
change intervals.
If replacement is required, see your NISSAN
dealer.
CLEANING
If your windshield is not clear after using the
windshield washer or if a wiper blade chatters
when running, wax or other material may be on
the blade or windshield.
Clean the outside of the windshield with a washer
solution or a mild detergent. Your windshield is
clean if beads do not form when rinsing with clear
water.
Clean each blade by wiping it with a cloth soaked
in a washer solution or a mild detergent. Then
rinse the blades with clear water. If your wind-
shield is still not clear after cleaning the blades
and using the wiper, replace the blades.
CAUTION
Worn windshield wiper blades can dam-
age the windshield and impair driver
vision.
SDI1864
AIR CLEANERWINDSHIELD WIPER BLADES
8-20Maintenance and do-it-yourself
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Do not tow a trailer with your vehicle.
FLAT TOWING
Towing your vehicle with all four wheels on the
ground is sometimes called flat towing. This
method is sometimes used when towing a vehicle
behind a recreational vehicle, such as a motor
home.
CAUTION
●Failure to follow these guidelines can
result in severe transmission damage.
●Whenever flat towing your vehicle, al-
ways tow forward, never backward.
●DO NOT tow any continuously variable
transmission vehicle with all four
wheels on the ground (flat towing) . Do-
ing so WILL DAMAGE internal transmis-
sion parts due to lack of transmission
lubrication.
●For emergency towing procedures refer
to “Towing recommended by NISSAN”
in the “In case of emergency” section of
this manual.
Automatic Transmission
To tow a vehicle equipped with an automatic
transmission, an appropriate vehicle dollyMUST
be placed under the towed vehicle’s drive
wheels.Alwaysfollow the dolly manufacturer’s
recommendations when using their product.
Continuously Variable Transmission
To tow a vehicle equipped with a continuously
variable transmission, an appropriate vehicle
dollyMUSTbe placed under the towed vehicle’s
drive wheels.Alwaysfollow the dolly manufac-
turer’s recommendations when using their prod-
uct.
Manual Transmission
●Always tow with the manual transmission in
Neutral.
●After towing 500 miles (805 km) , start and
idle the engine with the transmission in Neu-
tral for two minutes. Failure to idle the engine
after every 500 miles (805 km) of towing
may cause damage to internal transmission
parts.DOT (Department of Transportation) Quality
Grades: All passenger car tires must conform to
federal safety requirements in addition to these
grades.
Quality grades can be found where applicable on
the tire sidewall between tread shoulder and
maximum section width. For example:
Treadwear 200 Traction AA Temperature A
Treadwear
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one-half (1 1/2) times
as well on the government course as a tire graded
100. The relative performance of tires depends
upon the actual conditions of their use, however,
and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction AA, A, B and C
The traction grades, from highest to lowest, are
AA, A, B, and C. Those grades represent the
tire’s ability to stop on wet pavement as mea-
sured under controlled conditions on specified
government test surfaces of asphalt and con-
crete. A tire marked C may have poor traction
performance.
TOWING A TRAILER UNIFORM TIRE QUALITY GRADING
Technical and consumer information9-17
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


If you believe that your vehicle has a de-
fect which could cause a crash or could
cause injury or death, you should immedi-
ately inform the National Highway Traffic
Safety Administration (NHTSA) in addi-
tion to notifying NISSAN.
If NHTSA receives similar complaints, it
may open an investigation, and if it finds
that a safety defect exists in a group of
vehicles, it may order a recall and remedy
campaign. However, NHTSA cannot be-
come involved in individual problems be-
tween you, your dealer, or NISSAN.
To contact NHTSA, you may call the Ve-
hicle Safety Hotline toll-free at 1-888-
327-4236 (TTY: 1-800-424-9153); go
to http://www.safercar.gov; or write to:
Administrator, NHTSA, 400 Seventh
Street, SW., Washington, D.C. 20590.
You can also obtain other information
about motor vehicle safety from
http://www.safercar.gov.
You may notify NISSAN by contacting our
Consumer Affairs Department, toll-free, at
1-800-NISSAN-1.Due to legal requirements in some states and
Canadian Provinces, your vehicle may be re-
quired to be in what is called the “ready condi-
tion” for an Inspection/Maintenance (I/M) test of
the emission control system.
The vehicle is set to the “ready condition” when it
is driven through certain driving patterns. Usually,
the ready condition can be obtained by ordinary
usage of the vehicle.
If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a “not ready” condition. Before taking the
I/M test, check the vehicle’s
inspection/maintenance test readiness condi-
tion. Turn the ignition switch ON without starting
the engine. If the Malfunction Indicator Light
(MIL) comes on steady for 20 seconds and then
blinks for 10 seconds , the I/M test condition is
“not ready”. If the MIL does not blink after 20
seconds, the I/M test condition is “ready”. If the
MIL indicates the vehicle is in a “not ready” con-
dition, drive the vehicle through the following
pattern to set the vehicle to the ready condition. If
you cannot or do not want to perform the driving
pattern, a NISSAN dealer can conduct it for you.WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic con-
ditions and obey all traffic laws.
1. Start the engine, the low temperature indi-
cator light
illuminates in blue. Allow
the engine to idle until the low temperature
indicator light
goes out, indicating
normal operating temperature.
2. Accelerate the vehicle to 55 MPH (88
km/h) , then quickly release the accelerator
pedal completely and keep it released for at
least 10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 - 60 MPH (86 - 96 km/h) for at least 9
minutes.
4. Stop the vehicle.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 through 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 min-
utes.
REPORTING SAFETY DEFECTS (US
only)READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST
Technical and consumer information9-19
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


10 Index
A
Active Head Restraint..............1-6
Air bag (See supplemental restraint
system) .....................1-36
Air bag system
Front (See supplemental front impact air bag
system) ...................1-43
Side and curtain (See supplemental
side air bag and curtain side-impact
air bag system)...............1-47
Airbagwarninglabels.............1-50
Airbagwarninglight...........1-50,2-11
Air cleaner housing filter............8-20
Air conditioner
Air conditioner operation...........4-5
Air conditioner service............4-9
Air conditioner specification label.....9-12
Air conditioner system refrigerant and
oil recommendations.............9-7
Heater and air conditioner controls.....4-3
Servicing air conditioner...........4-9
Airflowcharts ..................4-6
Alarm system
(See vehicle security system).........2-14
Anchorpointlocations.............1-20
Antenna.....................4-28
Anti-lock brake warning light..........2-7
Anti-lock Braking System (ABS)........5-29
Armrests .....................1-5
Audible reminders................2-13Audio system..................4-10
Compact Disc (CD) changer.......4-24
Compact disc (CD) player.........4-18
FM-AM radio with compact disc (CD)
player ....................4-16
FM/AM/SAT radio with compact disc (CD)
changer...................4-21
Radio ....................4-10
Steering wheel audio control switch....4-27
Automatic
Automatic power window switch.....2-30
Automatic transmission fluid (ATF)....8-13
Driving with automatic transmission....5-14
Transmission selector lever lock
release................5-16,5-20
Automatic door locks...............3-6
B
Battery......................8-16
Chargewarninglight.............2-8
Before starting the engine...........5-12
Belt (See drive belt)..............8-18
Block heater
Engine....................5-32
Bluetoothhands-free phone system.....4-29
Booster seats..................1-31
Brake
Anti-lock Braking System (ABS)......5-29
Brake fluid..................8-15
Brake light (See stop light).........8-30Brake system................5-28
Brake warning light..............2-7
Brake wear indicators........2-13,8-22
Parking brake operation..........5-23
Self-adjusting brakes............8-22
Brakes......................8-22
Break-in schedule................5-25
Brightness control
Instrument panel..............2-21
Bulb check/instrument panel..........2-7
Bulb replacement................8-30
C
Capacities and recommended
fuel/lubricants...................9-2
CarphoneorCBradio.............4-28
Cargocover...................2-27
Cargo (See vehicle loading information) . . .9-13
CD care and cleaning.............4-26
CD changer (See audio system)........4-24
CD player (See audio system).........4-18
Child restraint with top tether strap......1-19
Child restraints..........1-10,1-15,1-17
Precautions on child
restraints............1-15,1-25,1-31
Top tether strap anchor point locations . .1-20
Child safety rear door lock............3-6
Chimes,audiblereminders...........2-13
Cleaning exterior and interior..........7-2
Clock...................4-17,4-21
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Fuses ......................8-23
Fusible links...................8-24
G
Gascap.....................3-26
Gauge
Fuelgauge..................2-5
Odometer...................2-4
Speedometer.................2-3
Tachometer..................2-4
Trip odometer.................2-4
Generalmaintenance ..............8-2
Glovebox....................2-26
H
Hands-free phone system, Bluetooth....4-29
Hazard warning flasher switch.........2-22
Head restraints..................1-6
Active Head Restraint............1-6
Headlight and turn signal switch........2-19
Headlightcontrolswitch............2-19
Headlights....................8-29
Heater
Heater and air conditioner controls.....4-3
Heater operation...............4-4
Hood release..................3-22
Horn.......................2-22
I
Ignition switch..................5-7Immobilizer system.........2-15,3-2,5-12
Important vehicle information label.......9-11
In-cabin microfilter...............8-20
Increasing fuel economy............5-26
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders).....................2-6
Inside mirror...................3-29
Instrument brightness control.........2-21
Instrument panel..............0-7,2-2
Instrument panel dimmer switch........2-21
Intelligent Key system
Key operating range............3-11
Mechanical key................3-3
Remote keyless entry operation......3-16
Troubleshooting guide...........3-21
Warningsignals...............3-21
Interiorlight...................2-34
Interior trunk lid release.............3-26
ISOFIX child restraints.............1-17
J
Jump starting...................6-7
K
Keyfob battery replacement..........8-26
Keyless entry
With Intelligent Key system
(See Intelligent Key system)........3-16
Keys, Except Intelligent Key...........3-2
Keys, For Intelligent Key system.........3-3L
Labels
Air conditioner specification label.....9-12
C.M.V.S.S. certification label........9-11
Emission control information label.....9-11
Engine serial number............9-11
F.M.V.S.S. certification label........9-11
Tire and Loading Information label.....9-12
Vehicle identification number (VIN)
plate.....................9-10
Warning labels (for SRS)..........1-50
LATCH (Lower Anchors and Tethers
for CHildren) System..............1-17
License plate
Installing the license plate.........9-12
Light
Airbagwarninglight.........1-50,2-11
Brake light (See stop light).........8-30
Bulb check/instrument panel........2-7
Bulbreplacement..............8-30
Charge warning light.............2-8
Fog light switch...............2-21
Headlightandturnsignalswitch......2-19
Headlight control switch..........2-19
Headlights..................8-29
Interior light.................2-34
Lightbulbs..................8-29
Low tire pressure warning light.......2-9
Low washer fluid warning light.......2-10
Passenger air bag and status light.....1-44
Security indicator light...........2-13
Trunklight..................2-35
Warning/indicator lights and audible
reminders...................2-6
10-3
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Recorders
Eventdata..................9-20
Refrigerant recommendation..........9-7
Registering your vehicle in another country . .9-10
Reporting safety defects (US only)......9-19
S
Safety
Child safety rear door lock..........3-6
Childseatbelts........1-15,1-25,1-31
Reporting safety defects (US only)....9-19
Seat adjustment
Front manual seat adjustment........1-2
Rear seat adjustment.............1-4
Seat belt
Child safety.................1-10
Infantsandsmallchildren .........1-10
InjuredPerson................1-11
Largerchildren ...............1-10
Precautions on seat belt usage.......1-7
Pregnant women..............1-11
Seat belt extenders.............1-14
Seatbeltmaintenance...........1-15
Seatbelts...................1-7
Shoulder belt height adjustment......1-14
Three-point type with retractor.......1-11
Seatbeltwarninglight.............2-11
Seats
Adjustment..................1-2
Frontseats..................1-2
Manual front seat adjustment........1-2
Rearseat...................1-4
Security indicator light.............2-13Security system (NISSAN vehicle immobilizer
system) , engine start........2-15,3-2,5-12
Self-adjusting brakes..............8-22
Service manual order form...........9-21
Servicing air conditioner.............4-9
Shiftlockrelease.............5-16,5-20
Shifting
Automatic transmission...........5-15
Continuously Variable Transmission
(CVT)....................5-18
Manual transmission............5-22
Shoulder belt height adjustment........1-14
Side air bag system (See supplemental side
air bag and curtain side-impact air
bag system)...................1-47
Spark plug replacement............8-19
Speedometer...................2-3
SRSwarninglabel...............1-50
Starting
Before starting the engine.........5-12
Jump starting.................6-7
Precautions when starting and driving . . .5-2
Push starting.................6-9
Starting the engine.............5-13
Steering
Power steering system...........5-28
Tilting steering wheel............3-28
Steering wheel audio control switch......4-27
Stoplight ....................8-30
Storage.....................2-23
Storage tray...................2-24
Sunglasses case................2-25
Sunglasses holder...............2-25
Sunroof (see Moonroof)............2-32
Supplemental air bag warning labels.....1-50
Supplemental air bag warning light . . .1-50, 2-11Supplemental front impact air bag system . .1-43
Supplemental restraint system
Information and warning labels.......1-50
Precautions on supplemental restraint
system....................1-36
Supplemental restraint system
(Supplemental air bag system).........1-36
Supplemental side and curtain side-impact
air bag system..................1-47
Switch
Automatic power window switch
.....2-30
Fog light switch...............2-21
Hazard warning flasher switch.......2-22
Headlightandturnsignalswitch......2-19
Headlight control switch..........2-19
Ignition switch................5-7
Overdrive switch..............5-17
Power door lock switch...........3-5
Rear window and outside mirror defroster
switch....................2-19
Rear window wiper and washer
switches...................2-18
Turnsignalswitch..............2-21
Windshield wiper and washer switch . . .2-17
T
Tachometer....................2-4
Theft (NISSAN vehicle immobilizer system) ,
engine start.............2-15,3-2,5-12
Three-way catalyst................5-2
Tilting steering wheel..............3-28
Tire
Flat tire....................6-2
Spare tire................6-3, 8-44
10-5
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie
