2009 NISSAN VERSA HATCHBACK License plate light

To defrost the rear window glass and outside
mirrors (if so equipped) , start the engine and
push the rear window defroster switch on. The
rear window defroster indicator light on the
switch comes on. Push the switch again to turn
the defroster off.
The rear window defroster automatically turns off
after approximately 15 minutes.
CAUTION
When cleaning the inner side of the rear
window, be careful not to scratch or dam-
age the rear window defroster.
HEADLIGHT CONTROL SWITCH
Lighting
1When turning the switch to theposi-
tion, the front parking, tail, license plate and
instrument panel lights come on.
2When turning the switch to theposi-
tion, the headlights come on and all the other
lights remain on.
CAUTION
Use the headlights with the engine run-
ning to avoid discharging the vehicle
battery.
LIC0388
Type A
SIC2745
Type B
SIC3019
REAR WINDOW AND OUTSIDE
MIRROR (if so equipped)
DEFROSTER SWITCHHEADLIGHT AND TURN SIGNAL
SWITCH
Instruments and controls2-19
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


●High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
●Use the same number and wattage as
shown in the chart.
Fog may temporarily form inside the lens of the
exterior lights in the rain or in a car wash. A
temperature difference between the inside and
the outside of the lens causes the fog. This is not
a malfunction. If large drops of water collect
inside the lens, contact a NISSAN dealer.EXTERIOR AND INTERIOR LIGHTS
Item Wattage (W) Bulb No.*1
Headlight assembly*2
High/low (Halogen) 60/55 H4
Park/Turn 21 7507 LF
Front clearance light 5 WY5W
Front fog light*2 (if so equipped) 35 H8
Interior map lights (if so equipped) 8 AL54
Interior light 8 AL54
Glove box light*2 (if so equipped) 1.4 —
Luggage compartment light (hatchback) / Trunk
light (sedan) (if so equipped)5—
High-mounted stop light
Inside 18 921
Spoiler*2 (if so equipped) LED —
Hatchback*2 (if so equipped) LED —
Rear combination light*2
Turn signal light 21 7507 LF
Stop/Tail 21/5 12499
Backup (reversing) 21 7506 LF
License plate light*2 5 2J8
*1 Always check with the Parts Department at a NISSAN dealer for the latest parts information.
*2 If replacement is required contact a NISSAN dealer.
8-30Maintenance and do-it-yourself
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


1Front view
1. Interior map lights (if so equipped)
2. Interior light
3. Front fog light (if so equipped)
4. Headlight assembly
2Rear view (hatchback)
3Rear view (sedan)
5. Luggage compartment light (hatchback)
Trunk light (sedan)
6. High-mounted stop light
7. License plate light
8. Rear combination light
WDI0575
Maintenance and do-it-yourself8-31
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Use the following steps to mount the front license
plate:
Before mounting the license plate, confirm that
the following parts are enclosed in the plastic
bag:
●License plate bracket
●License plate bracket screws x 2
●License plate screws x 2
●Screw grommets x 2
1. Hold the license plate bracket
1and make
a shallow hole in the bumper fascia using a
0.39 in (10 mm) drill. To avoid damaging the
area behind the fascia, apply only light pres-
sure to the drill.
2. Insert the grommets
2into the holes in the
bumper fascia.
3. Insert a small flat-bladed screwdriver into
the grommet hole to turn the threaded part of
the grommet 90°.
4. Mount the license plate bracket using the
two longer screws
3.
5. Use the two shorter hex head screws to
mount the license plate to the license plate
bracket using the two M6-14 mm bolts.
WARNING
●It is extremely dangerous to ride
in a cargo area inside a vehicle. In
a collision, people riding in these
areas are more likely to be seri-
ously injured or killed.
●Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat
belts.
●Be sure everyone in your vehicle
is in a seat and using a seat belt
properly.
TERMS
It is important to familiarize yourself with
the following terms before loading your
vehicle:
●Curb Weight (actual weight of your
vehicle) - vehicle weight including:
standard and optional equipment, flu-
ids, emergency tools, and spare tire
assembly. This weightdoes notin-
clude passengers and cargo.●GVW (Gross Vehicle Weight) - curb
weight plus the combined weight of
passengers and cargo.
●GVWR (Gross Vehicle Weight Rat-
ing) - maximum total combined
weight of the unloaded vehicle, pas-
sengers, luggage, hitch, trailer
tongue load and any other optional
equipment. This information is lo-
cated on the F.M.V.S.S./C.M.V.S.S.
certification label.
●GAWR (Gross Axle Weight Rating) -
maximum weight (load) limit specified
for the front or rear axle. This informa-
tion is located on the
F.M.V.S.S./C.M.V.S.S. certification
label.
●GCWR (Gross Combined Weight
rating) - The maximum total weight
rating of the vehicle, passengers,
cargo, and trailer.
VEHICLE LOADING INFORMATION
Technical and consumer information9-13
REVIEW COPY—2009 Versa(vrs)
Owners Manual—USA_English(nna)
09/10/08—debbie


Fuses ......................8-23
Fusible links...................8-24
G
Gascap.....................3-26
Gauge
Fuelgauge..................2-5
Odometer...................2-4
Speedometer.................2-3
Tachometer..................2-4
Trip odometer.................2-4
Generalmaintenance ..............8-2
Glovebox....................2-26
H
Hands-free phone system, Bluetooth....4-29
Hazard warning flasher switch.........2-22
Head restraints..................1-6
Active Head Restraint............1-6
Headlight and turn signal switch........2-19
Headlightcontrolswitch............2-19
Headlights....................8-29
Heater
Heater and air conditioner controls.....4-3
Heater operation...............4-4
Hood release..................3-22
Horn.......................2-22
I
Ignition switch..................5-7Immobilizer system.........2-15,3-2,5-12
Important vehicle information label.......9-11
In-cabin microfilter...............8-20
Increasing fuel economy............5-26
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders).....................2-6
Inside mirror...................3-29
Instrument brightness control.........2-21
Instrument panel..............0-7,2-2
Instrument panel dimmer switch........2-21
Intelligent Key system
Key operating range............3-11
Mechanical key................3-3
Remote keyless entry operation......3-16
Troubleshooting guide...........3-21
Warningsignals...............3-21
Interiorlight...................2-34
Interior trunk lid release.............3-26
ISOFIX child restraints.............1-17
J
Jump starting...................6-7
K
Keyfob battery replacement..........8-26
Keyless entry
With Intelligent Key system
(See Intelligent Key system)........3-16
Keys, Except Intelligent Key...........3-2
Keys, For Intelligent Key system.........3-3L
Labels
Air conditioner specification label.....9-12
C.M.V.S.S. certification label........9-11
Emission control information label.....9-11
Engine serial number............9-11
F.M.V.S.S. certification label........9-11
Tire and Loading Information label.....9-12
Vehicle identification number (VIN)
plate.....................9-10
Warning labels (for SRS)..........1-50
LATCH (Lower Anchors and Tethers
for CHildren) System..............1-17
License plate
Installing the license plate.........9-12
Light
Airbagwarninglight.........1-50,2-11
Brake light (See stop light).........8-30
Bulb check/instrument panel........2-7
Bulbreplacement..............8-30
Charge warning light.............2-8
Fog light switch...............2-21
Headlightandturnsignalswitch......2-19
Headlight control switch..........2-19
Headlights..................8-29
Interior light.................2-34
Lightbulbs..................8-29
Low tire pressure warning light.......2-9
Low washer fluid warning light.......2-10
Passenger air bag and status light.....1-44
Security indicator light...........2-13
Trunklight..................2-35
Warning/indicator lights and audible
reminders...................2-6
