2009 NISSAN SENTRA glove box

1. Rear seat (P. 1-3)
2. Moonroof (if so equipped) (P. 2-35)
3. Interior lights, illuminated entry,
moonroof switch (if so equipped)
(P. 2-37, P. 2-20, P. 2-35)
4. Sun visors (P. 3-26)
5. Rearview mirror (P. 3-27)
6. Glove box (P. 2-28)
7. Cup holders (P. 2-27)
8. Parking brake, parking on hills
(P. 5-19, P. 5-22)
9. Front seat (P. 1-2)
10. Front console (P. 2-29)
11. Rear armrest, cup holders
(if so equipped) (P. 1-7, P 2-27)
See the page number indicated in paren-
theses for operating details.
LII0091
PASSENGER COMPARTMENT
Illustrated table of contents0-5
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


1. Headlight/fog light (if so equipped)/
turn signal switch (P. 2-20); Manual
shift paddles (if so equipped) (P.5-14 )
2. Steering wheel switch for audio control
and BluetoothHands-Free Phone
System (if so equipped) (P. 4-37, 4-39)3. Driver’s supplemental air bag/Horn
(P. 1-40, 2-23)
4. Meters and gauges (P. 2-3)
5. Instrument brightness control (P. 2-21)
6. Cruise control main/set switches
(if so equipped) (P. 5-19)7.
Windshield wiper/washer switch (P. 2-18)8. Storage bin (if so equipped) (P. 2-25)
9. Audio system (P. 4-16)
10. Center ventilator (P. 4-7)
11. Passenger’s supplemental air bag
(P. 1-40)
12. Side ventilator (P. 4-7)
13. Control panel display (if so equipped)
(P. 4-2)
14. Engine oil pressure gauge
(if so equipped) (P. 2-6)
15. g (gravity) -force gauge (if so equipped)
(P. 2-5)
16. Hazard warning flasher switch
(if so equipped) (P. 2-22)
17. Hazard warning flasher switch
(if so equipped) (P. 2-22); Manual shift
mode switch (if so equipped) (P.5-14 )
18. Glove box (P. 2-28)
19. Front passenger air bag status light
(P. 1-40)
20. Climate control (P. 4-7)
21. Shift selector (P. 5-12)
22. Power outlet (P. 2-24)
23. Ignition switch (P. 5-7)
24. Tilt steering (P.3-26)
25. Storage bin (P. 2-25)
26. Hood release lever (P. 3-22)
See the page number indicated in paren-
theses for operating details.
WIC1486
INSTRUMENT PANEL
0-6Illustrated table of contents
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


1. Roof-mounted curtain side-impact
supplemental air bag inflators
2. Front seat-mounted side-impact
supplemental air bag modules
3. Supplemental front-impact air bag
modules
4. Crash zone sensor
5. Air Bag Control Unit (ACU)
6. Occupant classification sensor
(pressure sensor)
7. Pretensioner
8. Side satellite sensor
NISSAN Advanced Air Bag System
(front seats)
This vehicle is equipped with the NISSAN Ad-
vanced Air Bag System for the driver and front
passenger seats. This system is designed to
meet certification requirements under U.S. regu-
lations. It is also permitted in Canada.However,
all of the information, cautions and warn-
ings in this manual still apply and must be
followed.
The driver supplemental front-impact air bag is
located in the center of the steering wheel. The
passenger supplemental front-impact air bag is
mounted in the dashboard above the glove box.
The front air bags are designed to inflate in higher
severity frontal collisions, although they may in-
LRS0725
Safety—Seats, seat belts and supplemental restraint system1-47
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/23/08—debbie


2 Instruments and controls
Instrument panel...................................2-2
Meters and gauges................................2-3
Speedometer and odometer.....................2-3
Tachometer....................................2-4
g (gravity) -force gauge (if so equipped)...........2-5
Fuel gauge . ...................................2-5
Engine coolant temperature gauge...............2-6
Engine oil pressure gauge (if so equipped) . .......2-6
Warning/indicator lights and audible reminders.......2-8
Checking bulbs................................2-9
Warning lights.................................2-9
Indicator lights................................2-13
Audible reminders.............................2-15
Security systems.................................2-16
Vehicle security system (if so equipped)..........2-16
NISSAN vehicle immobilizer system.............2-17
Windshield wiper and washer switch...............2-18
Switch operation..............................2-18
Rear window and outside mirror (if so equipped)
defroster switch..................................2-19
Headlight and turn signal switch....................2-20
Headlight control switch........................2-20
Daytime running light system (Canada only)......2-21Instrument brightness control...................2-21
Turn signal switch.............................2-22
Fog light switch (if so equipped)................2-22
Hazard warning flasher switch.....................2-22
Horn............................................2-23
Heated seat (if so equipped).......................2-23
Power outlet.....................................2-24
Storage.........................................2-25
Map pockets..................................2-25
Storage bin...................................2-25
Storage trays.................................2-26
Instrument panel storage (if so equipped)........2-26
Seatback pockets (if so equipped)..............2-27
Cup holders..................................2-27
Glove box....................................2-28
Console box..................................2-29
Compact disc holder (if so equipped)............2-29
Trunk divider (if so equipped)...................2-29
Cargo net (if so equipped)......................2-30
Grocery hooks (if so equipped).................2-31
Windows........................................2-32
Power windows (if so equipped)................2-32
Manual windows (if so equipped)................2-35
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


1. Headlight/fog light (if so equipped)
/turn signal switch (P. 2-20); Manual
shift paddles (if so equipped) (P.5-14 )
2. Steering wheel switch for audio control
and BluetoothHands-Free Phone
System (if so equipped) (P. 4-37, 4-39)3. Driver’s supplemental air bag/Horn
(P. 1-40, 2-23)
4. Meters and gauges (P. 2-3)
5. Instrument brightness control (P. 2-21)
6. Cruise control main/set switches
(if so equipped) (P. 5-19)7.
Windshield wiper/washer switch (P. 2-18)8. Storage bin (if so equipped) (P. 2-25)
9. Audio system (P. 4-16)
10. Center ventilator (P. 4-7)
11. Passenger’s supplemental air bag
(P. 1-40)
12. Side ventilator (P. 4-7)
13. Control panel display (if so equipped)
(P. 4-2)
14. Engine oil pressure gauge
(if so equipped) (P. 2-6)
15. g (gravity) -force gauge (if so equipped)
(P. 2-5)
16. Hazard warning flasher switch
(if so equipped) (P. 2-22)
17. Hazard warning flasher switch
(if so equipped) (P. 2-22); Manual shift
mode switch (if so equipped) (P.5-14 )
18. Glove box (P. 2-28)
19. Front passenger air bag status light
(P. 1-40)
20. Climate control (P. 4-7)
21. Shift selector (P. 5-12)
22. Power outlet (P. 2-24)
23. Ignition switch (P. 5-7)
24. Tilt steering (P.3-26)
25. Storage bin (P. 2-25)
26. Hood release lever (P. 3-22)
See the page number indicated in paren-
theses for operating details.
WIC1486
INSTRUMENT PANEL
2-2Instruments and controls
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


CAUTION
●Avoid abrupt starting and braking when
the cup holder is being used to prevent
spilling the drink. If the liquid is hot, it
can scald you or your passenger.
●Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
Lower the rear center armrest to access the cup
holders.
GLOVE BOX
Open the glove box by pulling the handle.
WARNING
Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.
Rear (if so equipped)
WIC1097WIC1487
2-28Instruments and controls
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/23/08—debbie


inside the vehicle and all the doors are closed;
the lock will automatically unlock and the door
buzzer sounds.
NOTE:
The doors may not lock when the Intelli-
gent Key is in the same hand that is oper-
ating the request switch to lock the door.
Put the Intelligent Key in a purse, pocket or
your other hand.
CAUTION
The lockout protection may not function
under the following conditions:
●When the Intelligent Key is placed on
top of the instrument panel.
●When the Intelligent Key is placed on
top of the rear parcel shelf.
●When the Intelligent Key is placed in-
side the glove box or a storage bin.
●When the Intelligent Key is placed in-
side the door pockets.
●When the Intelligent Key is placed on or
under the spare tire area.
●When the Intelligent Key is placed in-
side or near metallic materials.
Unlocking doors
1. Carry the Intelligent Key.
2. Push the door handle request switch
1.
3. The hazard warning lights flash once and the
outside buzzer sounds once.
4. Push the door handle request switch
1
again within 60 seconds to unlock all doors.
If a door handle is pulled while unlocking the
doors, that door may not be unlocked. Returning
the door handle to its original position will unlock
the door. If the door does not unlock after return-
ing the door handle, push the door handle re-
quest switch to unlock the door.All doors will be locked automatically unless one
of the following operations is performed within 60
seconds after pushing the request switch.
●Opening any door.
●Pushing the ignition switch.
●Inserting the mechanical key into the ignition
switch.
The interior light timer illuminates for a maximum
of 30 seconds when a door is unlocked and the
room light switch is in the DOOR position.
The interior light can be turned off without waiting
for 30 seconds by performing one of the follow-
ing operations.
WPD0377WPD0369
Pre-driving checks and adjustments3-15
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/23/08—debbie


EXTERIOR AND INTERIOR LIGHTS
Item Wattage (W) Bulb No.*
Headlight assembly
Low/High (Halogen) 55/65 H13
Park 4 194
Turn 27 3457AK
Side marker 4 194
Front fog light* (if so equipped) 55 H11
Front map lights* (if so equipped) 8 168
Room light 8 AL57
Glove box light* (if so equipped) 1.4 158
Trunk light 5 158
High-mounted stop light*
Inside (if so equipped) 16 921
Spoiler (if so equipped) — LED
Rear combination light
Turn signal light 27/7 3057K
Stop/Tail 27/7 3057K
Backup (reversing) 16 921
Rear side marker 4 194
License plate light* 5 W5W
* Always check with the Parts Department at a NISSAN dealer for the latest parts information.
Maintenance and do-it-yourself8-29
