2009 NISSAN SENTRA key

CAUTION
Be careful not to allow children to swallow
the battery or removed parts.
KEYFOB
Replace the battery in the keyfob as follows:
1Open the lid using a coinA.
2Remove the batteryB.
3Install a new batteryCwith the “+” facing
down.
●Hold the battery by the edges. Holding the
battery across the contact points will seri-
ously deplete the storage capacity.
LDI0484
BATTERY REPLACEMENT
Maintenance and do-it-yourself8-25
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


●Do not touch the internal circuit and electric
terminals as it could cause a malfunction.
Recommended battery: CR2025 or equivalent.
4Close the lid securely.
5. Press the
button, then thebutton two or three times to check the key-
fob operation.
If the battery is removed for any reason
other than replacement, perform step 5.
●An improperly disposed battery can
hurt the environment. Always confirm
local regulations for battery disposal.
●The keyfob is water-resistant; how-
ever, if it does get wet, immediately
wipe completely dry.
●The operational range of the keyfob
extends to approximately 33 ft (10 m)
from the vehicle. This range may vary
with conditions.
FCC Notice:
Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to op-
erate the equipment.This device complies with Part 15 of the
FCC Rules and RSS-210 of Industry
Canada.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received, in-
cluding interference that may cause undes-
ired operation of the device.
SDI1867
8-26Maintenance and do-it-yourself
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


NISSAN INTELLIGENT KEY™
Replace the battery in the Intelligent Key as fol-
lows:
1. Remove the mechanical key from the Intelli-
gent Key.
2. Insert a small screwdriver
Ainto the slitB
of the corner and twist it to separate the
upper part from the lower part. Use a cloth to
protect the casing.
3. Replace the battery with a new one.
Recommended battery: CR2025 or equiva-
lent.
●Do not touch the internal circuit and elec-
tric terminals as doing so could cause a
malfunction.
●Hold the battery by the edges. Holding
the battery across the contact points will
seriously deplete the storage capacity.
●Make sure that the + side faces the bot-
tom of the case.4. Close the lid securely as illustrated
CD.
5. Operate the buttons to check the operation.
See a NISSAN dealer if you need assistance for
replacement.
FCC Notice:
Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to op-
erate the equipment.
This device complies with Part 15 of the
FCC Rules and RSS-210 of Industry
Canada.Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received, in-
cluding interference that may cause undes-
ired operation of the device.
WDI0535
Maintenance and do-it-yourself8-27
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


Foglightswitch.................2-22
Foldingrearseat............1-3,1-4,1-5
Front air bag system
(See supplemental restraint system).....1-47
Frontseats....................1-2
Fuel
Capacities and recommended
fuel/lubricants.................9-2
Fuel economy................5-21
Fuelgauge..................2-5
Fuel octane rating..............9-5
Fuel recommendation............9-4
Fuel-filler door and cap...........3-24
Fuel-filler door lock opener lever......3-24
Fuel economy setting..............4-4
Fuses ......................8-22
Fusible links...................8-23
G
Gascap.....................3-24
Gauge
Engine coolant temperature gauge.....2-6
Engine oil pressure gauge..........2-6
Fuelgauge..................2-5
g-forcegauge.................2-5
Odometer...................2-4
Speedometer.................2-3
Tachometer..................2-4
Trip odometer.................2-4
Generalmaintenance ..............8-2
g-forcegauge...................2-5
Glovebox....................2-28
Gloveboxlock .................2-28
Grocery hooks.................2-31H
Hands-free phone system, Bluetooth....4-39
Hazard warning flasher switch.........2-22
Head restraints..................1-8
Active Head Restraint............1-7
Headlight and turn signal switch........2-20
Headlight control switch............2-20
Headlights....................8-28
Heatedseats..................2-23
Heater
Heater and air conditioner controls.....4-7
Heater operation..............4-10
Hood release..................3-22
Horn.......................2-23
I
Ignition switch..................5-7
Immobilizer system.........2-17,3-2,5-10
Important vehicle information label.......9-12
In-cabin microfilter...............8-19
Increasing fuel economy............5-21
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders).....................2-8
Inside mirror...................3-27
Instrument brightness control.........2-21
Instrument panel..............0-6,2-2
Instrument panel dimmer switch........2-21
Intelligent Key system
Key operating range............3-12
Key operation................3-13
Mechanical key................3-3Remote keyless entry operation......3-16
Troubleshooting guide...........3-21
Warning signals...............3-21
Interiorlight...................2-37
Interior trunk lid release.............3-23
ISOFIX child restraints.............1-22
J
Jump starting...................6-8
K
Keyfob battery replacement..........8-25
Keyless entry
With Intelligent Key system
(See Intelligent Key system)........3-16
Keys, Except Intelligent Key...........3-2
L
Labels
Air conditioner specification label.....9-13
C.M.V.S.S. certification label........9-12
Emission control information label.....9-13
Engine serial number............9-12
F.M.V.S.S. certification label........9-12
Tire and Loading Information label.....9-13
Vehicle identification number (VIN)
plate.....................9-11
Warning labels (for SRS)..........1-55
Language setting.................4-6
10-3
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks


LATCH (Lower Anchors and Tethers for CHildren)
System......................1-22
License plate
Installing the license plate.........9-14
Light
Airbagwarninglight.........1-55,2-13
Brake light (See stop light).........8-29
Bulb check/instrument panel........2-9
Bulb replacement..............8-29
Chargewarninglight............2-10
Foglightswitch...............2-22
Headlight and turn signal switch......2-20
Headlightcontrolswitch..........2-20
Headlights..................8-28
Interiorlight.................2-37
Lightbulbs..................8-28
Low tire pressure warning light......2-11
Lowwasherfluidwarninglight.......2-12
Passenger air bag and status light.....1-49
Security indicator light...........2-14
Spotlights(Seemaplight).........2-38
Trunklight..................2-39
Warning/indicator lights and audible
reminders...................2-8
Lights
Maplights..................2-38
Lock
Child safety rear door lock..........3-6
Door locks..................3-4
Fuel-filler door lock opener lever......3-24
Gloveboxlock ...............2-28
Power door locks...............3-5
Trunk lid lock opener lever.........3-23
Lowfuelwarninglight .............2-10
Low tire pressure warning light........2-11
Low washer fluid warning light.........2-12Luggage
(See vehicle loading information).......9-14
M
Maintenance
General maintenance............8-2
Insidethevehicle...............8-3
Maintenance precautions..........8-5
Outside the vehicle..............8-2
Seat belt maintenance...........1-19
Under the hood and vehicle.........8-4
Malfunction indicator light...........2-14
Manual front seat adjustment..........1-2
Manual windows................2-35
Maplights....................2-38
Map pocket...................2-25
Metersandgauges................2-3
Instrumentbrightnesscontrol.......2-21
Mirror
Inside mirror.................3-27
Outside mirror control...........3-27
Vanity mirror.................3-26
Moonroof....................2-35
N
NISSAN Intelligent Key™.........3-3,3-10
NISSAN vehicle immobilizer
system................2-17,3-2,5-10O
Octane rating (See fuel octane rating).....9-5
Odometer.....................2-4
Oil
Capacities and recommended
fuel/lubricants.................9-2
Changingengineoil ............8-11
Changing engine oil filter..........8-12
Checking engine oil level..........8-9
Engine oil...................8-9
Engine oil and oil filter
recommendation...............9-6
Engine oil viscosity..............9-6
Outside mirror control.............3-27
Overheat
If your vehicle overheats
..........6-10
Owner’s manual order form..........9-29
Owner’s manual/service manual order
information....................9-29
P
Parking
Parking brake operation..........5-19
Parking/parking on hills...........5-22
Phone, Bluetoothhands-free system....4-39
Power
Power door locks...............3-5
Power outlet.................2-24
Power rear windows............2-33
Power steering system...........5-23
Power windows...............2-32
Rear power windows............2-33
10-4
REVIEW COPY—2009 Sentra(sen)
Owners Manual—USA_English(nna)
10/27/08—tbrooks
