Contents of voice command list
1Navigation:
Displays commonly used voice commands
for navigation.
●Dest list:
Displays commonly used voice commands
for setting destinations.
●Search list:
Displays commonly used voice commands
for searching for a location.●Map list:
Displays commonly used voice commands
for changing the map views.
●Route list:
Displays commonly used voice commands
for changing route properties, while route
guidance is on.
●Other list:
Displays commonly used voice commands
for certain navigation settings.
2Phone:
Displays commonly used voice commands
for phone.
3Other:
Displays what to say to view the Voice
Command List.
INFO:
●Touch the
scroll up key orscroll
down key to view the other lists.
●Touching the scroll keys repeatedly will bring
you through all of the lists available.
WNV0555
7-6Viewing technical information
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


XMNavTraffic™ information is a subscription
service offered by XMSatellite Radio.
This service provides real time information re-
garding traffic flow, accidents, road construction
and other incidents, where available.
XMNavTraffic™ combines information from
commercial and public traffic data providers in-
cluding government departments of
transportation, police, emergency services, road
sensors, cameras, and aircraft reports. The traf-
fic information is broadcast to the vehicle by the
XMsatellites. Available traffic information on
the route the driver selected is shown on the
navigation screen so traffic conditions between
you and the destination are known. Three types
of real-time traffic information for major road-
ways are shown on the navigation system:
●Unscheduled traffic data for example, acci-
dents and disabled vehicles.
●Scheduled traffic data, for example road con-
struction and road closures.
●Traffic flow information (rate of speed data) .
WARNING
XMNavTraffic™ information is not a
substitute for attentive driving. Traffic
conditions change constantly and
emergency situations can arise without
warning. Relying only on XMNavTraf-
fic™ information may lead to a collision
and could result in serious personal
injury.
NOTE:
Flow information is provided for only
roads equipped with traffic sensors and is
not available in all markets covered by the
service. Flow data may not be available on
portions of a road that is under
construction.
The XMNavTraffic™ service covers many major
metropolitan markets. For the most current list of
markets covered, please refer to
www.xmnavtraffic.com or call XMRadio cus-
tomer support at 1–800–XM-RADIO
(1–800–967–2346) .
BASIC OPERATION
1. Press the INFO button.
2. Touch the “Traffic Info.” key.
3. Touch the “Back” key to return to the previ-
ous screen. Press the MAP button to return
to the current location map screen.
VIEWING TRAFFIC INFORMATION (if
so equipped)
Viewing technical information7-7
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


Contents of available real time traffic
information
1Info. on Route:
Displays the list of traffic information found
on the recommended route from the current
vehicle location to the destination.
2Nearby Traffic Info.:
Displays the list of traffic information around
the current vehicle location.
3User Locations:
Allows you to check the traffic information
around the stored location.
4Traffic Info. Settings:
Allows you to perform the setting to display
the traffic information or to search the route
taking the traffic information into
consideration.
Info. on route
The list of traffic information found on the recom-
mended route from the current vehicle location
to the destination is displayed. Also, you can
check the detailed information about the dis-
played events.1. Touch the “Info. on Route” key. A list screen
is displayed.LNV0510
LNV0479
7-8Viewing technical information
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


2. Touch one of the preferred traffic location
keys.
Detailed information is shown about the se-
lected traffic location key. A preview map is
also shown.
INFO:
●While in the detailed information screen touch
the scroll keys to view additional information.
●Colored road meanings:
– Green: Light traffic.
– Yellow: Heavy traffic and moving at ap-
proximately 21 MPH (34 km) to 44 MPH
(71 km) .
– Red: Traffic jam or accident and moving
at approximately 20 MPH (30 km) to 0
MPH (0 km) .
– Purple: Road closed.●Road symbol meanings:
: Accident
: Closed Road
: Information
: Road Work
: Slippery Road
: Weather
: Incident
●Touch the “ZOOM OUT” key or the “ZOOM
IN” key to change the map scale.
Nearby traffic info.
The list of available traffic information around a
radius of 30 miles (50 km) centered at the cur-
rent vehicle location is displayed. A maximum of
400 events can be displayed.1. Touch the “Nearby Traffic Info.” key. A list
screen is displayed.LNV0480LNV0484
Viewing technical information7-9
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


2. Touch one of the preferred traffic location
keys.
Detailed information is shown about the se-
lected traffic location key. A preview map is
also shown.
INFO:
●While in the detailed information screen touch
the scroll keys to view additional information.
●Colored road meanings:
– Green: Light traffic.
– Yellow: Heavy traffic and moving at ap-
proximately 21 MPH (34 km) to 44 MPH
(71 km) .
– Red: Traffic jam or accident and moving
at approximately 20 MPH (30 km) to 0
MPH (0 km) .
– Purple: Road closed.●Road symbol meanings:
: Accident
: Closed Road
: Information
: Road Work
: Slippery Road
: Weather
: Incident
●Touch the “ZOOM OUT” key or the “ZOOM
IN” key to change the map scale.
User locations
You can check the traffic information around the
stored location. The method of how to store the
location is the same as for the operation with Ad-
dress Book.1. Touch the “User Location” key. A list screen
is displayed.LNV0485LNV0489
7-10Viewing technical information
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


2. Touch the “None (Add New)” key.
Use one of the appropriate methods for set-
ting a location.
“4. Setting a destination”
Available setting items
●Rename: Changes the name.
●Alter Location: Adjusts the location of the
stored location.
●Delete: Deletes the stored location.
●OK: Applies the settings.
Display emergency information
When an event related to emergency information
occurs around the current vehicle location, a
message pops up and a voice announcement is
made.The message includes the icon, event type,
event information and the direct distance from
the current location to the event.
●Emergency information is displayed regard-
less of whether the traffic information system
is ON or OFF.
●When there are multiple emergency informa-
tion events, the event with the shortest direct
distance from the current location is
displayed.
●When emergency information is about a de-
tour route, the detour route notification screen
is displayed when the vehicle approaches the
detour point.Traffic info. settings
1. Touch the “Traffic Info. Settings” key. Then
touch one of the traffic information settings
by touching the “ON” key. The indicator will
turn off or illuminate.
Available setting items
●Use Traffic Info.:
Enables all of the traffic information.
●Show Traffic Flow on Map.:
Displays the traffic flow with an arrow on the
map screen.
– Purple: Road closed
– Red: Traffic jam or accident
– Yellow: Heavy traffic
– Green: Light traffic
LNV0490LNV0543
Viewing technical information7-11
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
06/12/08—tbrooks


●Show Incidents on Map:
Displays the accidents or traffic restrictions
on the map screen.
●Blink Red Traffic Flow:
Blinks the road that is displayed as having a
traffic jam.
●Use Traffic for Travel Time:
Allows you to display on the map screen the
travel time to the destination with which the
traffic information is taken into
consideration.
●Use Traffic for Route Calc.:
Allows you to perform the route search with
the traffic information taken into
consideration. When “Auto Reroute” key is
set, the detour route search can be per-
formed automatically.●Traffic Announcements:
This can provide you with the announce-
ment of the traffic information event on the
route.
INFO:
●If the route is not already set, all of the event
icons on the map screen are displayed in red.
When the route is already set, the icons on
the route are displayed in red, and the icons
outside the route are displayed in gray.
●Even when “Show Traffic Flow On Map” and
“Show Incidents on Map” key are set to off,
the list display of “Info On Route” and “Nearby
Traffic Info” key will not be affected.
●Even when “Traffic Announcements” key is set
to off, the route guidance will not be affected.
Also, the announcement of emergency infor-
mation will not be turned off.
LNV0544
7-12Viewing technical information
REVIEW COPY—2009 Altima(alt)
Navigation System OM—USA_English(nna)
05/22/08—debbie


8 Other settings
Setup screen . . ...................................8-2
Basic operation................................8-2
Display settings................................8-3
Volume adjustment.............................8-4
Clock settings..................................8-6Language and units settings.....................8-7
Map color settings................................8-10
Adjusting the current vehicle location...............8-11
Reset all navigation settings to default..............8-13
