CD/AUX BUTTON
Press the CD/AUX button to play a CD loaded into the CD changer.
Press the CD/AUX button again to play a compatible device such as an MP3 player
when it is plugged into the auxiliary jack (cable not included) .
NOTE: Youmay need toadjust thevolume onany compatible deviceplugged intothe
auxiliary jack to find the most desired sound level of the audio system.
EJECT BUTTON
EJECT ASINGLE DISC-Press
the
button forless than 1.5
seconds. Selecttheeject slotby
pressing one of the CD insert se-
lect buttons (1-6 ) . The CDwill
then eject.
EJECT ALL DISCS - Press and hold the
button for more than 1.5 seconds. The
CDs will be ejected one after another.
CD SELECT/LOAD BUTTONS
LOAD A SINGLE DISC - Press one of the CD insert select buttons (1 -6 ) for less
than 1.5 seconds, wait for the CD slot door to open, then insert the CD.
LOAD UP TO 6 DISCS - Press and hold one of the CD insert select buttons ( 1-6)
for more than 1.5 seconds. Wait for the CD slot door to open before loading each
disc. The slot numbers (1-6) will illuminate on the display when CDs are loaded into
the changer
*XM Satellite Radioisonly available onvehicles equipped withoptional XMsatellite
subscription service.
CLOCK SET/ADJUSTMENT
NAVIGATION SYSTEM ONLY (if so equipped)
Press theSETUP button,thentouch the
“Clock” keytoaccess thefollowing clock
settings:
On-screen Clock–When thisitem is
turned toON, aclock isalways dis-
played inthe upper rightcorner ofthe
screen. Theclock isautomatically ad-
justed by the GPS system.
Clock Format – Choose either the 12-hour clock display or the 24-hour clock display.
Offset Adjust – Adjust the time by increasing or decreasing per minute.
Daylight Saving Time – Turn this item to ON for daylight savings time application.
Time Zone – Choose the time zone.
9
