OIL PUMP
OIL PUMP
Exploded ViewINFOID:0000000004115484
Removal and InstallationINFOID:0000000003771274
REMOVAL
1. Remove oil pan (upper). Refer to EM-33, "Removal and Installation".
2. Remove front cover. Refer to EM-44, "
Exploded View".
3. Remove the oil pump drive spacer.
4. Remove the oil pump.
INSTALLATION
Installation is in the reverse order of removal, paying attention of the following:
• When inserting the oil pump drive spacer, align the crankshaft key and the flat face of the inner rotor.
• If they are not aligned, rotate the oil pump inner rotor by hand.
• Make sure that each part is aligned and tap lightly until it reaches
the end.
1. Oil pump body 2. Outer rotor 3. Inner rotor
4. Oil pump cover 5. Oil pump drive spacer 6. Regulator valve
7. Regulator spring 8. Regulator plug
WBIA0415E
KBIA2512E
KBIA2490E
