POWER WINDOW LOCK SWITCHPWC-43
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
POWER WINDOW LOCK SWITCH
DescriptionINFOID:0000000003776019
Ground circuit of main power window and door lock/unlock switch shuts off if power window lock switch of
main power window and door lock/unlock switch is operated. This inhibits all operation, except for the main
switch.
Component Function CheckINFOID:0000000003776020
1. CHECK POWER WINDOW LOCK SIGNAL
Exchanges for a normal main power window and door lock/unlock switch, and operation is checked.
Does power window lock operate?
YES >> Replace main power window and door lock/unlock switch. Refer to PWC-117, "Removal and
Installation".
NO >> Check condition of harness and connector.
Revision: December 20092009 QX56

PWC-44
< COMPONENT DIAGNOSIS >
REAR POWER VENT WINDOW SWITCH CIRCUIT CHECK
REAR POWER VENT WINDOW SWITCH CIRCUIT CHECK
DescriptionINFOID:0000000005864657
Rear power vent window motor LH and RH will be operated if rear power vent window switch is operated.
Diagnosis Procedure - (Early Production)INFOID:0000000005864658
1. CHECK REAR POWER VENT WINDOW SWITCH OPERATION
1. Turn ignition switch OFF.
2. Disconnect rear power vent window switch.
3. Check continuity between rear power vent window switch termi- nals 1, 3 and 4.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace rear power vent window switch. Refer to PWC-120, "Removal and Installation"
.
2. CHECK REAR POWER VENT WINDOW SWITCH CIRCUIT HARNESS CONTINUITY
Check continuity between rear pow er vent window switch connector
M95 terminal 1 and ground.
Is the inspection result normal?
YES >> Rear power vent window switch circuit harness OK.
NO >> Repair or replace harness.
Diagnosis Procedure - (Late Production)INFOID:0000000005864659
1. CHECK REAR POWER VENT WINDOW SWITCH OPERATION
1. Turn ignition switch OFF.
2. Disconnect rear power vent window switch.
3. Check continuity between rear power vent window switch termi- nals 1, 3 and 4.
Is the inspection result normal?
YES >> GO TO 2
NO >> Replace rear power vent window switch. Refer to PWC-120, "Removal and Installation"
.
2. CHECK REAR POWER VENT WINDOW SWITCH CIRCUIT HARNESS CONTINUITY
Terminals Condition Continuity
31 Rear power vent window
switch is pressed OPEN. Ye s
41 Rear power vent window
switch is pressed CLOSE.
Ye s
LIIA0956E
1 - Ground : Continuity should exist.
ALKIA1035ZZ
Terminals Condition Continuity
41 Rear power vent window
switch is pressed OPEN. Ye s
31 Rear power vent window
switch is pressed CLOSE. Ye s
LIIA0956E
Revision: December 20092009 QX56

REAR POWER VENT WINDOW SWITCH CIRCUIT CHECKPWC-45
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
Check continuity between rear power vent window switch connector
M95 terminal 1 and ground.
Is the inspection result normal?
YES >> Rear power vent window switch circuit harness OK.
NO >> Repair or replace harness. 1 - Ground : Continuity should exist.
ALKIA1035ZZ
Revision: December 20092009 QX56

PWC-46
< COMPONENT DIAGNOSIS >
REAR POWER VENT WINDOW MOTOR LH CIRCUIT CHECK
REAR POWER VENT WINDOW MOTOR LH CIRCUIT CHECK
DescriptionINFOID:0000000005864660
Rear power vent windows OPEN/CLOSE by receiving t he signal from rear power vent window relays which
are controlled by the rear power vent window switch.
Diagnosis ProcedureINFOID:0000000005864661
1. CHECK REAR POWER VENT WINDOW LH SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear power vent window motor LH.
3. Turn ignition switch ON.
4. Check voltage between rear power vent window motor LH con- nector B52 terminals 1, 2 and ground.
Is the inspection result normal?
YES >> Replace rear power vent window motor LH. Refer to GW-22, "Removal and Installation".
NO >> Repair or replace harness.
Connector Terminals Rear power
vent window
switch condition Voltage (V)
(Approx.)
(+) (-)
B52 1
Ground Open 0
Close Battery voltage
2 Open Battery voltage
Close 0
ALKIA1037GB
Revision: December 20092009 QX56

REAR POWER VENT WINDOW MOTOR RH CIRCUIT CHECK
PWC-47
< COMPONENT DIAGNOSIS >
C
D E
F
G H
I
J
L
M A
B
PWC
N
O P
REAR POWER VENT WINDOW MOTOR RH CIRCUIT CHECK
DescriptionINFOID:0000000005864662
Rear power vent windows OPEN/CLOSE by receiving t he signal from rear power vent window relays which
are controlled by the rear power vent window switch.
Diagnosis ProcedureINFOID:0000000005864663
1.CHECK REAR POWER VENT WINDOW SWITCH RH SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear power vent window motor RH.
3. Turn ignition switch ON.
4. Check voltage between rear power vent window motor RH con- nector B150 terminals 1, 2 and ground.
Is the inspection result normal?
YES >> Replace rear power vent window motor RH. Refer to GW-22, "Removal and Installation".
NO >> Repair or replace harness.
Connector Terminals Rear power
vent window
switch condition Voltage (V)
(Approx.)
(+) (-)
B150 1
Ground Open 0
Close Battery voltage
2 Open Battery voltage
Close 0
ALKIA1037GB
Revision: December 20092009 QX56

PWC-48
< COMPONENT DIAGNOSIS >
REAR POWER VENT WINDOW RELAY (OPEN) CHECK
REAR POWER VENT WINDOW RELAY (OPEN) CHECK
DescriptionINFOID:0000000005864664
Rear power vent windows OPEN/CLOSE by receiving the signal from rear power vent window switch.
Diagnosis Procedure - (Early Production)INFOID:0000000005864665
1.CHECK REAR POWER VENT WINDOW RELAY (OPEN) POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power vent window relay (OPEN).
3. Turn ignition switch ON.
4. Check voltage between rear power vent window relay (OPEN) connector and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace harness.
2.CHECK REAR POWER VENT WINDOW RELAY (OPEN)
Check continuity between rear power vent window relay (OPEN) ter-
minals 3 and 4, 3 and 5.
Is the inspection result normal?
YES >> GO TO 3
NO >> Replace rear power vent window relay (OPEN).
3.CHECK REAR POWER VENT WINDO W RELAY (OPEN) GROUND CIRCUIT
Check continuity between rear power vent window relay (OPEN)
connector M87 terminal 4 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness.
4.CHECK REAR POWER VENT WI NDOW RELAY (OPEN) CIRCUIT
ConnectorTe r m i n a l s
Voltage (V)
(Approx.)
(+) (-)
M87 1
Ground Battery voltage
5
LIIA1565E
Terminals Condition Continuity
34 12V direct current supply
between terminals 1 and 2
No
No current supply Yes
35 12V direct current supply
between terminals 1 and 2
Ye s
No current supply No
WIIA0291E
4 - Ground : Continuity should exist.
LIIA1567E
Revision: December 20092009 QX56

REAR POWER VENT WINDOW RELAY (OPEN) CHECKPWC-49
< COMPONENT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
PWC
N
O P
1. Disconnect rear power vent window switch.
2. Check continuity between rear power vent window relay (OPEN) connector M87 terminal 2 and rear power vent window switch
connector M95 terminal 3.
Is the inspection result normal?
YES >> Refer to PWC-44, "Diagnosis Procedure - (Early Pro-
duction)".
NO >> Repair or replace harness.
Diagnosis Procedure - (Late Production)INFOID:0000000005864666
1.CHECK REAR POWER VENT WINDOW RE LAY (OPEN) POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear power vent window relay (OPEN).
3. Turn ignition switch ON.
4. Check voltage between rear power vent window relay (OPEN) connector and ground.
Is the inspection result normal?
YES >> GO TO 2
NO >> Repair or replace harness.
2.CHECK REAR POWER VENT WINDOW RELAY (OPEN)
Check continuity between rear power vent window relay (OPEN) ter-
minals 3 and 4, 3 and 5.
Is the inspection result normal?
YES >> GO TO 3
NO >> Replace rear power vent window relay (OPEN).
3.CHECK REAR POWER VENT WINDO W RELAY (OPEN) GROUND CIRCUIT
Check continuity between rear power vent window relay (OPEN)
connector M87 terminal 4 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair or replace harness. 2 - 3 : Continuity should exist.
LIIA1568E
Connector
Te r m i n a l s
Voltage (V)
(Approx.)
(+) (-)
M87 1
Ground Battery voltage
5
LIIA1565E
Terminals Condition Continuity
34 12V direct current supply
between terminals 1 and 2
No
No current supply Yes
35 12V direct current supply
between terminals 1 and 2
Ye s
No current supply No
WIIA0291E
4 - Ground : Continuity should exist.
LIIA1567E
Revision: December 20092009 QX56

PWC-50
< COMPONENT DIAGNOSIS >
REAR POWER VENT WINDOW RELAY (OPEN) CHECK
4.CHECK REAR POWER VENT WI NDOW RELAY (OPEN) CIRCUIT
1. Disconnect rear power vent window switch.
2. Check continuity between rear power vent window relay (OPEN) connector M87 (A) terminal 2 and rear power vent window
switch connector M95 (B) terminal 4.
Is the inspection result normal?
YES >> Refer to PWC-44, "Diagnosis Procedure - (Late Produc-
tion)".
NO >> Repair or replace harness. 2 - 4 : Continuity should exist.
ALKIA1890GB
