2009 HYUNDAI TUCSON power steering fluid

9
VEHICLE SPECIFICATIONS4
Oil & Grease Standard
SAE 5W-20, 5W-30
API SJ, SL or ABOVE,
ILSAC GF-3 or ABOVE
SAE 10W-30 [ABOVE 0°F (-18°C)]
HYUNDAI GENUINE PARTS SAE MTF SAE 75W/85 (API GL-4)
HYUNDAI GENUINE ATF SP III, DIAMOND ATF SP III, SK ATF SP III or other
brands meeting the SP III specification approved by Hyundai Motor Co.API GL-5, SAE 80W/90 (SHELL SPIRAX AX Equivalent)
API GL-5, SAE 80W/90 (SHELL SPIRAX AX Equivalent)
Ethylene glycol base for aluminum radiator
PSF-3 TYPE FLUID
DOT 3, DOT 4 or Equivalent Item
Engine Oil
Recommends
TransaxleManual
Automatic
Transfer case
Rear Axle
Coolant
Power steering gear
Brakes and clutch fluid
LUBRICATION CHARTJ080A03JM-AAT
Q'ty u.s.qts. (liter)
Drain and refill with oil filter
2.0 L : 4.23 (4.0)
2.7 L : 4.76 (4.5)
2.2 (2.1)
8.2 (7.8)
0.8 (0.8)
0.8 (0.75)
7.4 (7.0)
0.95 (0.9)
As required

10
INDEX
4
K
Keys................................................................................................... 1-3
If you lose your keys ...................................................................3-19
Positions......................................................................................... 2-5
L
Light Bulbs Replacement ..................................................................6-27
Luggage Net ......................................................................................1-82
M
Maintenance Intervals
Explanation of scheduled maintenance items ............................... 5-7
Maintenance under severe usage conditions............................... 5-6
Scheduled maintenance................................................................ 5-4
Service requirements.................................................................... 5-2
Mirrors
Automatic Dimming Rear View Mirror With Compass ................1-76
Day-night inside rearview mirror .................................................1-76
Outside rearview mirror ...............................................................1-74
Outside rearview mirror Heater ..................................................1-75
O
Odometer / Trip Odometer ...............................................................1-56
Occupant Classification System ......................................................1-39
P
Parking Brake....................................................................................1-78
Power Outlet......................................................................................1-67
Power Steering Fluid Level ...............................................................6-25R
Rear Seat
Adjusting seatback angle .............................................................1-17
Folding rear seatback ..................................................................1-17
Rear Window Defroster Switch ........................................................1-65
Reporting Safety Defects (U.S.A Only)...........................................8-17
Risk of Rollover................................................................................... 2-3
Roof Rack.........................................................................................1-82
S
Seat
Front.............................................................................................1-13
Rear..............................................................................................1-17
Seat warmer .................................................................................1-16
Seat Belts
3-point system.............................................................................1-22
Pretensioner seat belt ..................................................................1-32
Adjusting your seat belt ...............................................................1-23
Care of seat belts .........................................................................1-20
Precautions..................................................................................1-19
Shop Manual ......................................................................................
8-14
Shopping Bag Holders......................................................................1-79
Sound
Brake pad warning sound ............................................................1-54
Spectacle Case.................................................................................1-71
Speedometer.....................................................................................1-55
Starting Procedure.............................................................................. 2-6
Steering Wheel Free play .................................................................6-19
Steering Wheel Tilt Lever ..................................................................1-87
Stereo Sound System ....................................................................1-109
Sunroof..............................................................................................1-68
Sun Visor...........................................................................................1-86
