2009 HONDA S2000 dashboard

2009 S2000 Online Reference Owner's Manual

Contents

Owner's Identification Form

Introduction .............................................................................................................................\
............................. i

A Few Words About Safety ......................................................................\
........................................................ iii
Your Vehicle at a Glance (main controls) ....................................................\
................................................ 3
Driver and Passenger Safety (seat belts, SRS, and child protection) ......................\
.............................. 5
Instruments and Controls (indicators, gauges, dashboard and steering column) .................................... 43
Features (heating and cooling ,audio,steering wheel, and cruise control) ...................................................... 95
Before Driving (fuel, vehicle break-in, and cargo loading) ...........................................\
........................... 127
Driving (engine and transmission operation) .........................................\
....................................................... 143
Maintenance (minder, fluid checking, minor services, and vehicle storage)........................................... 159
Taking Care of the Unexpected (flat tire, dead battery, overheating, fuses) ..................................... 199
Technical Information (vehicle specifications, tires, and emissions controls) ....................................... 231
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ... 247
Authorized Manuals (U. S. only) (how to order) ..............................................\
........................................... 251
Index ......................................................................\
......................................................... ........................................ I

Service Information Summary ( fluid capacities and tire pressures)
\
\
1 00X31-S2A-6900

A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.
How to operate the heating and air
conditioning system, the audio
system, and other convenience
f eatures.What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
The proper way to start the engine,
shif t the transmission, and park.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
ID numbers, dimensions, capacities,
and technical information.
This section covers several problems
motorists sometimes experience,
and details how to handle them. A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features Bef ore Driving
Driving
Maintenance
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T echnical Inf ormation
T aking Care of the Unexpected
Overview of Contents
2
2009 S2000

Your vehicle has a supplemental
restraint system (SRS) with f ront
airbags to help protect the heads and
chests of the driver and a passenger
during a moderate to severe frontal
collision (see page f or more
information on how your airbags
work).The most important things you need
to know about your airbags are:
They are designed to supplement
the seat belts. Always wear
your seat belt properly, and sit
upright and as f ar back f rom the
steering wheel as possible while
allowing f ull control of the vehicle. A
passenger should move the seat as
f ar back f rom the dashboard as
possible.
The rest of this section gives more
detailed inf ormation about how you
can maximize your saf ety.
Remember, however, that no saf ety
system can prevent all injuries or
deaths that can occur in a severe
crash, even when seat belts are
properly worn and the airbags deploy.
To do their job, airbags must
inf late with tremendous f orce. So
while airbags help save lives, they
can cause minor injuries or more
serious or even fatal injuries if
occupants are not properly
restrained or sitting properly.
22
Your Vehicle’s Saf ety Features
Airbags
Airbags do not replace seat belts. What you should do:
Airbags of f er no protection in side impact s, rear impact s, rollovers,or minor f ront al collisions.
Airbags can pose serious hazards.Driver and Passenger Saf ety
9
2009 S2000

µAdjust the driver’s seat as far to the
rear as possible while allowing you to
maintain f ull control of the vehicle.
Have a passenger adjust his or her
seat as far to the rear as possible.
Locking the doors reduces the
chance of someone being thrown out
of the vehicle during a crash, and it
helps prevent a passenger f rom
accidentally opening a door and
f alling out.
Locking the doors also helps prevent
an outsider f rom unexpectedly
opening a door when you come to a
stop.
See page f or how to lock the
doors, and page f or how the door-
open indicator works.
If you sit too close to the steering
wheel or dashboard, you can be
seriously injured by an inf lating f ront
airbag, or by striking the steering
wheel or dashboard.
The f ollowing pages provide
instructions on how to properly
protect the driver, an adult
passenger or teenage child large
enough and mature enough to drive
or ride in your vehicle. See pages
f or important guidelines on
how to properly protect a child in a
forward-facing child seat or a larger
child passenger.
Your vehicle has door and trunk
open indicators on the instrument
panel to indicate when either door or
the trunk is not tightly closed.
After everyone has entered the
vehicle, be sure the doors are closed
and locked. 40
47
29
65
Protecting A dults and Teens
Adjust the Seats
Introduction
Close and L ock the Doors
1. 2.
10
2009 S2000

Emergency backup power in case
your vehicle’s electrical system is
disconnected in a crash.
Your airbag system includes: An indicator on the dashboard that
alerts you that the passenger’s
airbag has been turned of f (see
page ).
A sophisticated electronic system
that continually monitors and
records inf ormation about the
sensors, the control unit, the
airbag activators, the seat belt
tensioners, and driver and
passenger seat belt use when the
ignition switch is in the ON (II)
position.
An indicator on the instrument
panel that alerts you to a possible
problem with your airbags,
sensors, or seat belt tensioners
(see page ). Weight sensors that monitor the
weight on the passenger’s seat. If
the weight is about 65 lbs (29 kg)
or less (the weight of an inf ant or
small child), the passenger’s
airbag will be turned off (see page ).
Two SRS (supplemental restraint
system) airbags. The driver’s
airbag is stored in the center of
the steering wheel; the passenger’s
airbag is stored in the dashboard.
Both are marked ‘‘SRS AIRBAG’’
(see page ).
A driver’s seat position sensor that
monitors the distance of the seat
f rom the airbag. If the seat is too
far forward, the airbag will inflate
with less f orce (see page ). Sensors that can detect whether
the driver’s seat belt and the
passenger’s seat belt are latched
or unlatched (see page ). Sensors that can detect a
moderate to severe front impact. Automatic seat belt tensioners
(see page ). 26
24
25
18
24
16
22
Additional Inf ormation About Your Airbags
Driver and Passenger Saf ety
21
2009 S2000

CONT INUED
When you turn the ignition switch to
the ON (II) position, this indicator
comes on brief ly then goes of f . This
tells you the system is working
properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
When the airbag is turned of f , a
‘‘passenger airbag of f ’’ indicator in
the center of the dashboard comes
on (see page ).
If the indicator stays on after the
engine starts.
If the indicator comes on or
flashesonandoff whileyoudrive.
If the weight sensors detect there is
no passenger in the seat, the airbag
will be of f . However, the passenger
airbag of f indicator will not come on.
To ensure that the passenger’s
advanced airbag system will work
properly,
The SRS indicator alerts you to a
potential problem with your airbags
or seat belt tensioners.
26
Additional Inf ormation About Your Airbags
do not do anyt hing t hat
would increase or decrease t he weight on the passenger’s seat, suchas hanging heavy objects on the seat.
How the SRS Indicator
Works
Driver and Passenger Saf ety
25
2009 S2000

µ
To remind you of the passenger’s
airbag hazards, your vehicle has
warninglabelsonthedashboard
(U.S. models) and on the driver’s and
passenger’s visors. Please read and
f ollow the instructions on these
labels.U.S. ModelsCanadian Models
Protecting Children General Guidelines
Driver and Passenger Saf ety
31
SUN VISOR
SUN VISOR DASHBOARD
2009 S2000

µ
If they do, they
could be very seriously injured in a
crash. Leaving children without
adult supervision is illegal in most
states and Canadian provinces,
and can be very hazardous. Even very young
children learn how to unlock
vehicle doors, turn on the ignition
switch, and open the trunk, which
can lead to accidental injury or
death.
For example, a small child lef t in a
vehicle on a hot day can die f rom
heatstroke. A child lef t alone with
the key in the ignition switch can
accidentally set the vehicle in
motion, possibly injuring
themselves or others.
Children who play in vehicles can
accidentally get trapped inside.
Teach your children not to play in
or around vehicles. Know how to
operate the emergency trunk
opener and decide if your children
should be shown how to use this
feature(seepage ).
During a crash, the
belt could press deep into the child
and cause serious or fatal injuries. If you are not wearing a seat
belt in a crash, you could be
thrown forward and crush the
child against the dashboard. If you
are wearing a seat belt, the child
canbetornfromyourarmsandbe
seriously hurt or killed.
66
Additional Saf ety Precautions
Never let two children use the
same seat belt . Do not leave children alone in a
vehicle. K eep vehicle keys and remot e
transmitters out of the reach ofchildren.
Lock both doors and the trunk when your vehicle is not in use.
Never put a seat belt over yourself
and a child.
Never hold a small child on your
lap.
Protecting Children General Guidelines
32
2009 S2000
