If the low tire pressure/TPMS
indicator comes on, or the multi-
inf ormation display shows a
‘‘CHECK TPMS SYSTEM’’ message,
the VSA system automatically turns
on even when the VSA system is
turned of f by pressing the VSA OFF
switch (see page ). If this
happens, you cannot turn the VSA
system of f by pressing the VSA OFF
switch again.
When you restart the vehicle with
thecompactsparetire,theTPMS
system message will also be
displayed on the multi-inf ormation
display af ter several miles
(kilometers) driving.
If you have a f lat tire, the low tire
pressure/TPMS and tire monitor
indicators will come on. Replace the
indicated f lat tire with the compact
sparetire(seepage ).After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on while
driving. Af ter several miles
(kilometers) driving, this indicator
begins to f lash, then stays on again.
You will also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display. This is normal;
the system cannot monitor the spare
tire pressure. Manually check the
spare tire pressure to be sure it is
correct.
This indicator and the warning
message on the multi-inf ormation
display will go of f , af ter several miles
(kilometers) driving, when the spare
tire is replaced with the specified
regular tire equipped with the tire
pressure monitor sensor.
Each wheel is equipped with a tire
pressure sensor mounted inside the
tire behind the valve stem. You must
use TPMS specif ic wheels. It is
recommended that you always haveyour tires serviced by your dealer or
a qualif ied technician.
Never use a puncture-repairing agent
in a f lat tire. If used, you will have to
replace the tire pressure sensor.
Havetheflattirerepairedbyyour
dealer as soon as possible.
436
512
CONT INUED
Changing a T ire with T PMS
Tire Pressure Monitoring System (TPMS) Touring models
Driving
431
——
y
y
(/yy
2009 Pilot

The floor mats that came with your
vehicle hook over the f loor mat
anchors. This keeps the f loor mats
f rom sliding f orward, possibly
interf ering with the pedals, or
backwards, making the f ront
passenger’s weight sensors
inef f ective.If you remove a f loor mat, make sure
tore-anchoritwhenyouputitback
in your vehicle.
If you use a non-Honda f loor mat,
make sure it f its properly and that it
canbeusedwiththefloormat
anchors. Do not put additional f loor
mats on top of the anchored mats.
Floor Mat s
Maint enance
495
FRONT REAR
——
y

y
(/yy
2009 Pilot

The exhaust emissions controls
include f our systems: PGM-FI,
ignition timing control, exhaust gas
recirculation, and three way catalytic
converter. These f our systems work
together to control the engine’s
combustion and minimize the
amount of HC, CO, and NOx that
come out the tailpipe. The exhaust
emissions control systems are
separate f rom the crankcase and
evaporative emissions control
systems.
The PGM-FI system uses sequential
multiport f uel injection.
It has three subsystems: air intake,
engine control, and f uel control. The
powertrain control module (PCM)
uses various sensors to determine
how much air is going into the
engine. It then controls how much
f uel to inject under all operating
conditions.This system constantly adjusts the
ignition timing, reducing the amount
of HC, CO, and NOx produced.
The exhaust gas recirculation (EGR)
system takes some of the exhaust
gas and routes it back into the intake
manif old. Adding exhaust gas to the
air/f uel mixture reduces the amount
of NOx produced when the f uel is
burned.
The three way catalytic converter is
in the exhaust system. Through
chemical reactions, it converts HC,
CO, and NOx in the engine’s exhaust
to carbon dioxide (CO ), nitrogen
(N ), and water vapor.
The emissions control systems are
covered by warranties separate from
the rest of your vehicle. Read your
warranty manual for more informa-
tion. The emissions control systems are
designed and certif ied to work to-
gether in reducing emissions to
levels that comply with the Clean Air
Act. To make sure the emissions
remain low, you should use only new
Honda replacement parts or their
equivalent f or repairs. Using lower
qualitypartsmayincreasethe
emissions f rom your vehicle.
2
2
Exhaust Emissions Controls Replacement Parts
PGM-FI SystemIgnit ion T iming Cont rol Syst em
Exhaust Gas Recirculat ion (EGR)Syst em
Three Way Catalytic Converter
Emissions Cont rols
552
——
y

y
(/yy
2009 Pilot

ÎÎ
Replacing Seat Belt Af ter a............................................
Crash .23
...
Reserve Tank, Engine Coolant . 402
...............................
Restraint, Child .37
..................
Reverse Gear Position . 418
.................................
Rotation Tire .503
..................................
Saf ety Belts .8, 20
.........
Safety Defects, Reporting . 560
.................................
Saf ety Features .7
...........................................
Airbags .
9
..................................
Door Locks .11
..........................
Head Restraints .14
.................................
Seat Belts .8, 15
...............
Seats & Seat-Backs . 13,14
.............
Saf ety Labels, Location of . 60
..............................
Saf ety Messages .iii
.............
Satellite Radio, XM
. 234, 264
.....................................
Seat Belts .8, 15
...............
Additional Information . 20
Automatic Seat Belt ...............................
Tensioners .22
.....................................
Cleaning .494
......................
Lap/Shoulder Belt .21 ................................
Maintenance .23
Reminder Light and ................................
Beeper .20, 67
...................
System Components . 20
...............
Use During Pregnancy . 18
...
Wearing a Lap/Shoulder Belt . 15
...............................................
Seats .152
.......
Adjusting the Second Seat . 157
..........
Folding the Second Seat . 158
.............
Folding the Third Seat . 159
........................
Head Restraints .155
.......................................
Heaters .162
......................
Position Memory .171
....................
Third Row Access .159
............................
Security System .347
Sensors ....
Driver’s Seat Position Sensor . 29
Front Passenger’s Weight .....................................
Sensors .29
......................
Impact Sensors .25, 26
...............................
Serial Number .540
...........................
Service Intervals .459
...........................
Service Manual .561
..............................
Service Minder .459
.........
Service Station Procedures . 399
..........................
Setting the Clock .312 Shif ting the Automatic
.............................
Transmission .417
.....
Shif t Lever Position Indicator . 417
........................
Shif t Lock Release .420
....................................
Side Airbags .30
................................
Of f Indicator .33
......................
Side Curtain Airbags .32
Side Marker Lights, Bulb .................
Replacement in . 488,489
...............................
Signaling Turns .71
.....................................
Snow Tires .506
........................
Sound System .206, 250
Spare Tire ..............................
Inf lating .501, 512
............................
Specif ications .543
....................
Specif ications Charts . 542
................................
Speed Control .348
................................
Speed Limiter .420
...................................
Speedometer .80
Index
S
VIII
——y
y
(/yy
2009 Pilot

CONT INUED
..........
SRS, Additional Inf ormation . 24
...
Additional Safety Precautions . 35
.............................
Airbag Service .35
......
Airbag System Components . 24
..
How the SRS Indicator Works . 33
How Your Front Airbags .........................................
Work .27
...
How Your Side Airbags Work . 30
How Your Side Curtain Airbags .........................................
Work .32
.............................
SRS Indicator .33 ,70
..
START (Ignition Key Position) . 135
.......................
Starting the Engine .415
...................
Auto Control Mode . 415
In Cold Weather at High ..................................
Altitude .416
................
With a Dead Battery . 521
........
Steam Coming f rom Engine . 523
Steering Wheel ................................
Adjustment .131
...........
Anti-thef t Column Lock . 135
......................
Buttons .309, 348,361
Stereo Sound ...............
System . 206,207,224,250
..................
Storage Compartment . 180
....................
Storing Your Vehicle .510 ........................
Sunglasses Holder .181
........................................
Sun Visor .182
Supplemental Restraint System ......................................
Servicing .35
.........................
SRS Indicator .33 ,70
...................
System Components . 24
..................................
Synthetic Oil .477
.....................................
Tachometer .80
..........................................
Tailgate .142
...............................
Glass Hatch .146
......................
Open Indicator .11, 93
...............................
Opening the .142
.........................................
Power .143
......
Taillights, Changing Bulbs in . 490
.
Taking Care of the Unexpected . 511
Technical Descriptions ......
DOT Tire Quality Grading . 544
.....
Emissions Control Systems . 551
Three Way Catalytic ...............................
Converter .553
.......................
Temperature Gauge .80
........
Temperature, Inside Sensor . 205
....................
Temperature, Outside . 88...................
Tensioners, Seat Belts . 22
..............
Tether Anchorage Points . 53
................
Thef t Protection, Radio . 311
..
Three Way Catalytic Converter . 553
.
Tilt/Telescopic Steering Wheel . 131
....................................
Timing Belt .486
....................................
Tire Chains .507
.........
Tire, How to Change a Flat . 513
.................................
Tire Labeling .546
Tire Pressure Monitoring ............
System (TPMS) . 424,548
Low Tire Pressure ...........................
Indicator .72, 427
.......
Tire Pressure Monitor . 89,428
Index
INDEX
T
IX
——
