Item CapacityFord part name
or equivalentFord part
number / Ford
Specification
Transmission
fluid
36.35 pints
(3.5L)4Motorcraft
MERCONVATFXT-5-QM /
MERCONV
Windshield
washer fluid4.0 quarts
(3.8L)Motorcraft
Premium
Windshield
Washer
ConcentrateZC-32-A /
WSB-M8B16–A2
1Add the coolant type originally equipped in your vehicle.
2Rear axle lubricants do not need to be checked or changed unless a
leak is suspected, service is required or the axle assembly has been
submerged in water. The axle lubricant should be changed any time the
rear axle has been submerged in water, using SAE 75W-140 High
Performance rear axle lube, meeting Ford specification WSL-M2C192–A.
Fill 1/4-9/16 in. (6-14 mm) below bottom of fill hold. Add 4 oz. (118 ml)
of Additive Friction Modifier C3AZ-19B546-A or equivalent meeting Ford
specification EST-M2C118-A for complete refill of Traction-Lok axles.
3The Tremec TR-6060 6–Speed manual transmission on your Shelby
GT500 uses MERCONV automatic transmission fluid. Ensure that the
correct MERCONV ATF automatic transmission fluid is used as
indicated on the label on your transmission.
4Service refill capacity is determined by filling the transmission to the
bottom of the filler hole with the vehicle on a level surface.
USING THE RIGHT BULBS
Function Trade Number
Park lamp, turn lamp, side marker (front) 3156K
Luggage compartment lamp S211
Fog lamp PS24N
2009 05+ Mustang(197)
Supplement
USA(fus)
Maintenance and Specifications
29
