AUXILIARY RELAY BOX
The relay box is located in the engine compartment by the power
distribution box.
Fuse/Relay
locationFuse amp
ratingDescription
1 — Not used
2 — Not used
3 — Not used
4 — Not used
5 10A Intercooler Pump
6 15A Fuel Pump Fuse #2
7 — Left HID
8 — Right HID
9 — Fuel Pump Relay #2
10 — S.C. Intercooler Pump
