Do not travel with the
windscreen washer reser-
voir empty. The wind-
screen washer is fundamental for
improving visibility.Do not start the wind-
screen washer when the
fluid is finished to prevent
damaging the pump engine.
POWER STEERING FLUID
fig. 9
The oil level, with the vehicle on lev-
el ground and the engine cold should
correspond to the MAX reference
line.
This check should be performed
when the engine is cold and with the
car on level ground.When topping up (where necessary)
make sure that the oil has the same
specifications as the oil in the system.
Apply the following procedure:
– when the engine has been started,
turn the steering wheel repeatedly on
the left and on the right; then bring it
back to its central position;
– remove cap Aand wait for the oil
level in the reservoir to stabilize;
– top up to reach the MAX refer-
ence line and put the cap back to its
place. Certain commercial ad-
ditives for windscreen
washers are inflammable.
The engine compartment con-
tains hot components which may
set it on fire.
CAR MAINTENANCE
196fig. 9 - Versions 2.0 JTD 120 HP - 136 HP
Versions 2.2 JTD 170 HP
F0B0443b
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 196

DIESEL FUEL FILTER
DRAINING THE CONDENSE
fig. 12
The presence of water in the fuel
feed circuit can severely damage the
injection system and make the engine
misfire. For this reason, drain the con-
dense every 5,000 km.
Contact a Fiat Dealershipto have
this operation carried out.The following procedure is only for
information:
– loosen knob Ain the filter lower
part;
– tighten Aup again when diesel
without water starts flowing out.Dispose of the water and
diesel fuel drained from
the filter correctly. You
should have the operation car-
ried out by a Fiat Dealership
which is properly equipped for
disposing of it out in a way that
respects nature and the current
legislation.
fig. 12
F0B0172b
CAR MAINTENANCE
200
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 200

CAR MAINTENANCE
201
BATTERY
The battery, placed in a scuttle on
the floor in front of the passenger’s
seat, is of the “Limited Maintenance”
type. Under normal conditions it will
not need to be topped up with distilled
water.
REPLACING THE BATTERY
If required, replace the battery with
a genuine spare part having the same
specifications. If a battery with differ-
ent specifications is fitted, the service
intervals given in the Service Schedule
in this section will no longer be valid.
Refer to the instructions provide by
the battery manufacturer.Batteries contain sub-
stances that are very
harmful for the environ-
ment. You are advised to have
the battery changed at a Fiat
Dealership, which is properly
equipped for disposing of used
batteries respecting nature and
the law.
IMPORTANTMake sure the bat-
tery is correctly secured from a me-
chanical point view when removing
and refitting it.CHECKING THE BATTERY
FLUID LEVEL (electrolyte)
Check and top up the electrolyte lev-
el, if needed, in accordance with the
Service Schedule contained in this
chapter. Have this operation carried
out at a Fiat Dealership.
The liquid in the battery
is poisonous and corro-
sive. Avoid contact with
eyes and skin. Do not bring naked
flames or possible sources of
sparks near to the battery: risk of
fire and explosion.
184-213 ULYSSE ING:184-213 ULYSSE ING 13-11-2009 10:13 Pagina 201

TECHNICAL SPECIFICATIONS
219
ENGINE
2.2 JTD 163 HP (*)
2.2 JTD 163 HP
a.g. (*)
4HP/4HR (*)
Diesel
85 x 96
2179
16.6:1
120
163
4000
370
37.5
1500
Diesel for motor
vehicles (EN590
specifications)2.0 JTD 120 HP
RHK
Diesel
85 x 88
1997
17.5:1
88
120
4000
300
30.5
2000
Diesel for motor
vehicles (EN590
specifications)2.0 JTD 136 HP
RHR
Diesel
85 x 88
1997
17.5:1
100
136
4000
320
2000
Diesel for motor
vehicles (EN590
specifications)2.2 JTD 170 HP
4HT
Diesel
85 x 96
2179
16.6:1
125
170
4000
370
37.5
1500
Diesel for motor
vehicles (EN590
specifications)2.2 JTD 170 HP a.g.
4HS
Diesel
85 x 96
2179
16.6:1
125
170
4000
370
37,5
1500
Diesel for motor
vehicles (EN590
specifications)
Engine code
Cycle
Diameter x stroke mm
Total displacement cm3
Compression ratio
Max power (EEC) kW
corresponding ratio HP
rpm
Max torque (EEC) Nm
corresponding ratio kgm
rpm
Fuel
(*) Versions for specific markets
214-233 ULYSSE ING:214-233 ULYSSE ING 13-11-2009 10:21 Pagina 219

TECHNICAL SPECIFICATIONS
221
BRAKES
SERVICE AND EMERGENCY
BRAKES
Front and rear disc brakes with two
operating cylinders for each wheel and
floating shoe.
Crossed hydraulic circuit control fit-
ted with:– ABS with EBD;
– HBA
– TC + ASR
– MSR
– ESP.
HANDBRAKE
Controlled by a lever, it works me-
chanically on the rear brake shoes.
SUSPENSIONS
FRONT
Independent wheel, McPherson sus-
pension with:
– telescopic hydraulic dampers with
flexible anchorage on the body side
and rubber dust guards;
– coil and knock-guard buffers off-
set with the shock absorber;
– stabiliser anchored to the shock ab-
sorber and the swivel arms.
REAR
The suspension is fitted with:
– cross member;
– pulled arms;
– hydraulic shock absorbers;
– coil springs;
– stabiliser.
214-233 ULYSSE ING:214-233 ULYSSE ING 13-11-2009 10:21 Pagina 221

TECHNICAL SPECIFICATIONS
224
Maximum speed index
Q =up to 160 km/h
R =up to 170 km/h
S =up to 180 km/h
T =up to 190 km/h
U =up to 200 km/h
H =up to 210 km/h
V =over 210 km/h
ZR =over 240 km/h
W =up to 270 km/h
Y =up to 300 km/h.
Maximum speed rating
for snow tyres
Q M + S =up to 160 km/h.
T M + S =up to 190 km/h.
H M + S =up to 210 km/h.UNDERSTANDING RIM
MARKINGS
The following are the necessary in-
structions to understand the meaning
of the markings on the rim, as shown
in fig. 6a.RIM PROTECTOR TYRES
fig. 6b
Example: 6 1/2J x 15 H2 ET43
fig. 6b
F0B0510b
fig. 6a
F0B0267b
6 1/2=rim width in inches 1-fig. 6a;
J =rim drop centre outline (side
projection where the tyre bead rests)
2-fig. 6a;
15 =rim nominal diameter in inches
(corresponds to diameter of the tyre
to be mounted) 3-fig. 6a;
H2 =“hump” shape and number (re-
lief on the circumference holding the
Tubeless tyre bead on the rim);
ET43 =wheel camber angle (dis-
tance between the disc/rim support-
ing plane and the wheel rim centre
line).If after-sale tyres with
rim protector are used
(fig. 6b) and the car has
integral cups fixed (by springs) to
the sheet wheel, DO NOT fit
wheel cups. The use of unsuitable
tyres and wheel cups could cause
a sudden pressure loss of the ty-
re.
214-233 ULYSSE ING:214-233 ULYSSE ING 13-11-2009 10:21 Pagina 224

TECHNICAL SPECIFICATIONS
228
WEIGHTS
2.0 JTD 136 HP
6 5/7/8
seats seats
1854÷1957 1818÷1983
1256 1263
1274 1267
2530 2530
100 100
––
750 750
76 76
2.0 JTD 120 HP
6 5/7/8
seats seats
1846÷1949 1811÷1976
1253 1259
1277 1271
2530 2530
100 100
––
750 750
73 72
2.2 JTD 170 HP
6 5/7/8
seats seats
1902÷1988 1875÷2017
1304 1318
1266 1252
2570 2570
100 100
––
750 750
75 75
2.2 JTD 170 HP a.g.
6 5/7/8
seats seats
1930÷2016 1898÷2045
1336 1346
1274 1264
2610 2610
100 100
––
750 750
80 75
(kg)
Weight empty (including fluids,
90% fuel in the tank and
no optional)
Maximum allowed loads (1)
– front axle:
– rear axle:
– total:
Maximum load on roof:
Towable weight
– trailer with brakes:
– trailer without brakes:
Maximum load on ball coupling
(trailer with brakes):
(1) Loads not to be exceeded. The driver is responsible for arranging the loads so that they comply with these limits.
214-233 ULYSSE ING:214-233 ULYSSE ING 13-11-2009 10:21 Pagina 228

TECHNICAL SPECIFICATIONS
229
CAPACITIES
2.0 JTD
120 HP
litres
80
8
9
5.25
1.9
–
1.2
1.2
0.519
7.52.0 JTD
136 HP
litres
80
8
9
5.25
1.9
–
1.2
1.2
0.519
7.52.2 JTD
170 HP
litres
80
8
9
4.75
–
–
1.2
1.2
0.93
7.5
2.2 JTD
170 HP a.g.
litres
80
8
9
4.75
–
3/4
1.2
1.2
0.93
7.5
Fuel tank:
– including a reserve of:
Engine cooling system:
Engine sump and filter:
Transaxle:
Automatic gearbox
Hydraulic power steering:
Electro-hydraulic power steering
Hydraulic brake circuit with:
ABS (with ESP)
Windscreen, rear mirror and
headlight liquid reservoir:
Recommended fluids
and lubricants
Recommended products
Diesel for motor vehicles
(EN590 specifications)
Mixture of distilled water and
PARAFLU
UP(red) at 50%
SELENIA WR
TUTELA CAR EXPERYA
TUTELA GI/E
TUTELA GI/E
TUTELA GI/R
TUTELA TOP 4
50-50 mixture of distilled
water and TUTELA
PROFESSIONAL SC 35
214-233 ULYSSE ING:214-233 ULYSSE ING 13-11-2009 10:21 Pagina 229
