2009 FIAT GRANDE PUNTO Dualogic Transmission Manual

16
TRANSMISSION
1.4
Five forward gears and reverse electrohydraulic system
Gearbox with
with electronic control
Clutch Single-disk, dry with electric-hydraulic control
Drive Front
603.97.236 PuntoACTUAL Dual GB 31-07-2009 11:03 Pagina 16

17
1.4
3 door 3 door 5 door
4 seat 5 seat 5 seat
1025 1025 1040
480 560 560
850 850 850
850 850 850
1505 1585 1600
1000 1000 1000
400 400 400
50 50 50
60 60 60
WEIGHTS
Weights (kg)
Kerb weight
(including fuel, space-saver spare
wheel, tools and accessories):
Payload (*)
including the driver:
Maximum admitted loads (**)
– front axle:
– rear axle:
– total:
Towable loads:
– trailer with brakes:
– trailer without brakes:
Maximum load on roof:
Maximum load on tow hitch:
(*) If special equipment is fitted (sunroof, tow hitch, etc.) the unladen car weight increases thus reducing the specified payload.
(**) Loads not to be exceeded. It is the driver’s responsibility to place goods in the boot and/or on the loading surface in accor-
dance with the maximum permissible loads.
603.97.236 PuntoACTUAL Dual GB 31-07-2009 11:03 Pagina 17

18
kg
0,59 1.4
CO2 EMISSIONS
CO2emissions according to European Directive in force (gr x 100 km).
CO
2emission value referred to combined consumption is 134 (gr x 100 km) with engine 1.4.
CAPACITIES
Dualogic gearbox
hydraulic system
litres
0,7Specified fuels
Recommended products
TUTELA CAR CS SPEED -
Special oil with
“ATF DEXRON III” additive
603.97.236 PuntoACTUAL Dual GB 31-07-2009 11:03 Pagina 18

19
FUEL CONSUMPTION
Fuel consumption according to European Directive in force Urban Extra-urban Combined(litres x 100 km)
1.46.85.0 5.7
Consumption in AUTO-ECO logic.
603.97.236 PuntoACTUAL Dual GB 31-07-2009 11:03 Pagina 19

Fiat Group Automobiles S.p.A. - Customer Services - Technical Services - Service Engineering
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print n° 603.97.236 - 07/2009 - 1 Edition
