2009 DODGE CHALLENGER SRT hood release

When the seatback is folded to the upright position, make
sure it is latched by strongly pulling on the top of the
seatback above the seat strap.
WARNING!
•Be certain that the seatback is securely locked into
position. If the seatback is not securely locked into
position, the seat will not provide the proper
stability for child seats and/or passengers. An
improperly latched seat could cause serious injury.
•The cargo area in the rear of the vehicle (with the
rear seatbacks in the locked-up or folded down
position) should not be used as a play area by
children when the vehicle is in motion. They could
be seriously injured in an accident. Children
should be seated and using the proper restraint
system.
TO OPEN AND CLOSE THE HOOD
Two latches must be released to open the hood. First, pull
the hood release lever located under the left side of the
instrument panel.
Hood Release Lever
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Then, turn the ignition switch to the START position and
release it as soon as the starter engages. The starter motor
will disengage automatically in 10 seconds. Once this
occurs, release the accelerator pedal, turn the ignition
switch to the LOCK position, wait 10 to 15 seconds, then
repeat the normal starting procedure.
CAUTION!
To prevent damage to the starter, wait 10 to 15
seconds before trying again.
After Starting
The idle speed is controlled automatically and it will
decrease as the engine warms up.
ENGINE BLOCK HEATER — IF EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 Volt AC electrical outlet with a
grounded, three-wire extension cord.
The engine block heater cord is routed under the hood on
the driver side of the vehicle. It has a removable cap that
is located on the driver side of the Integrated Power
Module.
WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 Volt electrical cord could cause
electrocution.
STARTING AND OPERATING 219
5

WARNING!
Fluid level should be checked on a level surface and
with the engine OFF to prevent injury from moving
parts and to ensure accurate fluid level reading. Do
not overfill. Use only manufacturer’s recommended
power steering fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to “Fluids, Lubricants, and Genuine
Parts” in this section for the correct fluid type.
Front And Rear Suspension Ball Joints
The suspension ball joints should be inspected for exter-
nal leakage or damage when other maintenance is per-
formed.
Steering Linkage
The tie rod end ball joints should be inspected for
external leakage or damage when other maintenance is
performed.
Body Lubrication
Locks and all body pivot points, including seat tracks,
door hinges, trunk hinges, and hood hinges, should be
lubricated periodically to assure quiet, easy operation
and to protect against rust and wear. Prior to the appli-
cation of any lubricant, the parts concerned should be
wiped clean to remove dust and grit; after lubricating,
excess oil and grease should be removed. Particular
attention should also be given to hood latching compo-
nents to ensure proper function. When performing other
underhood services, the hood latch, release mechanism,
and safety catch should be cleaned and lubricated.
MAINTAINING YOUR VEHICLE 311
7

Washers............................. 312
Heated Mirrors .......................... 77
Heated Seats ........................... 112
Heater ............................... 203
Heater, Engine Block ..................... 219
High Beam/Low Beam Select (Dimmer) Switch . . 120
Holder, Cup ........................... 142
HomeLink
(Garage Door Opener) Transmitter . . . 130
Hood Release .......................... 114
Hoses ................................ 319
Ignition ............................... 14
Key ............................... 12,14
Ignition Key Removal ..................... 14
Illuminated Entry ........................ 20
Immobilizer (Sentry Key) ................... 15
Infant Restraint .......................... 58
Inflation Pressure Tires .................... 156
Information Center, Vehicle ................. 159 Instrument Cluster
.................... 149,150
Instrument Panel and Controls .............. 148
Instrument Panel Lens Cleaning ............. 328
Integrated Power Module (Fuses) ............ 329
Interior Appearance Care .................. 326
Interior Lights .......................... 121
Intermittent Wipers (Delay Wipers) ........... 122
Introduction ............................. 4
Jump Starting .......................... 286
Key, Programming ........................ 17
Key, Replacement ........................ 16
Key, Sentry (Immobilizer) ................... 15
Key-In Reminder ......................... 15
Keyless Entry System ...................... 21
Keyless Go .......................... 12,216
Keys ................................. 12
Kicker Sound System ..................... 200
370 INDEX

Mirrors.............................. 76
Outlet (Auxiliary Electrical Outlet) .......... 140
Seats ............................... 109
Steering ............................. 237
Steering, Checking ..................... 310
Sunroof ............................. 136
Windows ............................. 33
Power Steering Fluid .................. 310,343
Pregnant Women and Seat Belts .............. 45
Pretensioners Seat Belts ............................. 43
Programmable Electronic Features ............ 172
Programming Transmitters (Remote Keyless
Entry) ................................. 21
Radial Ply Tires ......................... 257
Radiator Cap (Coolant Pressure Cap) .......... 316
Radio Broadcast Signals ................... 175
Radio, Navigation ....................... 191 Radio Operation
...................... 192,202
Radio Remote Controls .................... 201
Radio, Satellite .................... 191,192,195
Radio (Sound Systems) .................... 191
Rear Cup Holder ........................ 142
Rear Seat, Folding ....................... 113
Rear Wheel Bearings ..................... 324
Rear Window Defroster ................... 144
Rear Window Features .................... 144
Reception, Radio ........................ 175
Recorder, Event Data ...................... 56
Recreational Towing ...................... 278
Reformulated Gasoline .................... 270
Refrigerant ............................ 310
Release, Hood .......................... 114
Reminder, Lights On ..................... 118
Reminder, Seat Belt ....................... 43
Remote Control Starting System ........................ 27
INDEX 375
10
