2009 Citroen NEMO Owner's Manual

5
FAMILIARISATION
Familiarisation
EXTERIOR
Roof rack and roof bars
Fixing points are provided on each side of the
roof for securing the roof rack or the transverse
roof bars.

 109
Opening the hinged rear doors
to 180°
Once the vehicle has been unlocked, the
hinged rear doors can be opened to 180° to
make unloading/loading operations easier.

 34
Rear parking assistance
This equipment warns you, by means of an
audible signal, if an obstacle is detected
behind the vehicle when reverse gear is
engaged.

 68
"Guide-me-home" lighting
After switching off the ignition, when you leave
your vehicle, the front lamps remain on briefl y.

 39

6
Familiarisation
OPEN
Remote control key

A. Unfolding/Folding of the key.

B. Unlocking of the front doors only (Light
van) or of all of the doors (Combi)
(two fl ashes of the direction indicators).

C. Central locking of the vehicle
(one press; one fl ash of the direction indicators).
or
Deadlocking of the vehicle
(two consecutive presses; one fl ash of the direction indicators).

D. Unlocking of the load space (Light van) or
of the hinged rear doors or tailgate only
(Combi).
If a door is open or has not been closed
properly, the failed locking is indicated by three
fl ashes of the direction indicators.
Fuel tank

1. Opening of the fuel fi ller fl ap.

2. Opening and hooking of the fuel tank cap.
Capacity of the tank: approximately 45 litres.

 29
 129
Opening to 180°

 34
Press the catch while opening the door.

7
FAMILIARISATION
Familiarisation
INTERIOR
Trip computer
By means of the MENU button, this system
permits management or consultation of the
various vehicle confi gurations/information such
as the disarming of the passenger air bag, the
automatic locking of the doors, the language,
etc.

 64
Retractable multifunction passenger
seat
This equipment enables you to confi gure your
passenger seat in three positions:
- seat for the transportation of a passenger,
- table to accommodate your various
documents,
- retracted for the transportation of long objects.

 76
Audio system
This equipment benefi ts from the latest
technology: MP3 compatible audio equipment
and Bluetooth ®
hands-free kit.

 69
Cruise control/speed limiter
These two functions control the speed of the
vehicle in relation to the programmed value.

 41, 44
Electronic gearbox system
This equipment guarantees perfect driving
by combining a fully automatic mode and a
manual mode.

 50

8
Familiarisation INSTRUMENTS AND CONTROLS

1. Steering wheel adjustment control.

2. Lights and direction indicators controls.

3. Instrument panel.

4. Driver’s air bag.
Horn.

5. Cruise control/speed limiter switches.

6. Gear lever.

7. Handbrake.

8. Bonnet release.

9. Exterior mirror controls.

10. Fuse box.

11. Manual headlamp height adjustment.

12. Side adjustable and closing vent.

13. Front side window demisting vent.

14. Windscreen demisting vent.

15. Steering lock and ignition.

16. Wipers/wash-wipe/trip computer controls.

17. Central adjustable and closing vents.

18. Passenger air bag.

19. MENU button.

20. Glove box.

21. Lighter.

22. Ashtray.

23. Heating/air conditioning controls.

24. Audio equipment.

25. Electric window controls.

26. 12 V accessories socket.

9
FAMILIARISATION
Familiarisation
LOAD SPACE (LIGHT VAN)

1. Stowing rings.

2. Storage tray.

3. Torch.

4. Partition.

5. Spare wheel.

 82 It is advisable to immobilise the load
by fi xing it securely using the stowing
rings
1 on the fl oor.

10
Familiarisation
REAR LAYOUT (COMBI)

 8 9
With hinged rear doors

1. Stowing rings.

2. Luggage retaining net.

3. Tool kit.

4. Rear shelf.
With tailgate

1. Stowing rings.

2. Luggage retaining net.

3. Rear shelf.

4. Retaining straps/Tool kit.

5. Torch/Boot light.

11
FAMILIARISATION
Familiarisation
SIT COMFORTABLY
Driver’s seat adjustment
Forwards-backwards Height Seat back angle (A)
Lumbar support (B)

 74

12
Familiarisation Front seat belts

A. Fastening.

 94
SIT COMFORTABLY
Steering wheel adjustment

1. Unlocking of the control.

2. Adjustment of the height and depth.

3. Locking of the control.
As a safety precaution, it is imperative
that these operations are carried out
while stationary.

 49
Electric exterior mirror adjustment

A. Selection of the driver’s mirror.

B. Selection of the passenger’s mirror.

C. Adjustment of the position of the mirror.

 47
Interior mirror adjustment

1. Selection of the "day/night" position of the
mirror.

2. Directing of the mirror.

 47
