135
XI
P R A C T I C A L I N F O R M A T I O N
Removing a wheel
List of operations
P a r k t h e v e h i c l e o n s t a b l e , fi r m
g r o u n d . A p p l y t h e p a r k i n g b r a k e .
Switch off the ignition and en- g a g e fi r s t g e a r o r r e v e r s e g e a r ,
depending on the slope (for ve-
hicles with automatic gearbox,
s e l e c t p o s i t i o n P ) .
D e t a c h t h e e m b e l l i s h e r u s i n g t h e
wheelbrace 1 b y p u l l i n g c l o s e t o
t h e v a l v e .
For vehicles with aluminium wheel rims, slide the embellisher
removal tool 5 into the slot in the
c e n t r a l e m b e l l i s h e r a n d a p p l y
fi r m l e v e r a g e t o d e t a c h .
Slacken the wheel bolts using
the wheelbrace 1 .
For vehicles with aluminium wheel rims, slacken the anti-theft
bolt using the socket 6 fi t t e d o n
the wheelbrace 1 .
Position the jack under the
b o d y s h e l l , e x a c t l y a s i n t h e i l l u s -
tration at the mark A , closest to
t h e w h e e l t h a t i s t o b e r e p l a c e d .
Operate the jack 4 until its base
i s i n c o n t a c t w i t h t h e g r o u n d .
Make sure that the base of the
j a c k i s v e r t i c a l l y b e l o w t h e j a c k -
i n g p o i n t u s e d .
R a i s e t h e v e h i c l e .
Remove the bolts and disengage
t h e w h e e l . List of operations
Position the wheel using the cen-
tring guide 2 .
D o u p t h e 3 b o l t s b y h a n d a n d
r e m o v e t h e c e n t r i n g g u i d e .
P o s i t i o n t h e 4 t h b o l t .
Pretighten the bolts using the
wheelbrace 1 . F o r v e h i c l e s w i t h a l -
uminium wheel rims, pretighten the
anti-theft bolt using the socket 6
fi t t e d o n t h e w h e e l b r a c e 1 .
Retract the jack 4 a n d d i s e n g a g e i t .
Tighten the wheel bolts using the
wheelbrace 1 and the anti-theft
bolt using the socket 6 .
Reposition the embellisher, com-
m e n c i n g b y p l a c i n g t h e s l o t a t
the valve, pressing it home with
t h e p a l m o f y o u r h a n d .
For vehicles with aluminium wheel rims, reclip the central
e m b e l l i s h e r i n p l a c e .
Stow the tools and the wheel in
t h e b o o t .
C h e c k t h e t y r e p r e s s u r e a n d a l s o
h a v e i t s b a l a n c i n g c h e c k e d .
Fitting a wheel
Page 162 of 279
155
XI
P R A C T I C A L I N F O R M A T I O N
TOWING THE VEHICLE
P r o c e d u r e f o r h a v i n g y o u r v e h i c l e
towed or for towing another vehicle
u s i n g a r e m o v a b l e t o w i n g e y e .
Access to the tools
The tools are located under the boot
fl o o r .
To gain access to them:
open the boot,
l i f t u p t h e fl o o r ,
detach and remove the holder
c o n t a i n i n g t h e t o o l s . Towing your vehicle
On the front bumper, unclip the
c o v e r b y p r e s s i n g a t t h e t o p l e f t
a n d p u l l i n g a t t h e r i g h t .
S c r e w t h e t o w i n g e y e i n f u l l y .
A t t a c h t h e t o w i n g b a r .
S w i t c h o n t h e h a z a r d w a r n i n g
l a m p s o n t h e t o w e d v e h i c l e .
Place the gear lever in neutral
(position N on the electronic
g e a r b o x o r a u t o m a t i c g e a r b o x ) . Towing another vehicle
On the rear bumper, unclip the
c o v e r b y p r e s s i n g a t t h e b o t t o m
a t p u l l i n g a t t h e t o p .
S c r e w t h e t o w i n g e y e i n f u l l y .
A t t a c h t h e t o w i n g b a r .
S w i t c h o n t h e h a z a r d w a r n i n g
l a m p s o n t h e t o w e d v e h i c l e .
Failure to observe this special con-
dition could result in damage to
certain braking components and
the absence of braking assistance
t h e n e x t t i m e t h e e n g i n e i s s t a r t e d . When towing with all four wheels on
t h e g r o u n d , a l w a y s u s e a t o w i n g b a r .
W h e n t o w i n g w i t h o n l y t w o w h e e l s
o n t h e g r o u n d , a l w a y s u s e p r o f e s -
s i o n a l l i f t i n g e q u i p m e n t .
When towing with the engine off,
t h e r e i s n o l o n g e r a n y b r a k i n g o r
s t e e r i n g a s s i s t a n c e .
Page 163 of 279
156
XI
P R A C T I C A L I N F O R M A T I O N
TOWING A TRAILER,A CARAVAN, ETC.
Towbar suited to the attachment of a
trailer or caravan with additional sig-
n a l l i n g a n d l i g h t i n g .
Y o u r v e h i c l e i s p r i m a r i l y d e s i g n e d
for transporting people and luggage,
b u t i t m a y a l s o b e u s e d f o r t o w i n g a
t r a i l e r . I f t h e t r a i l e r i s n o t fi t t e d b y a
CITROËN dealer, it is imper-
a t i v e t h a t i t i s fi t t e d u s i n g t h e
electrical pre-equipment installed at
the rear of the vehicle, in accordance
w i t h t h e m a n u f a c t u r e r ' s i n s t r u c t i o n s .
Driving advice
Distribution of loads
D i s t r i b u t e t h e l o a d i n t h e t r a i l e r s o
that the heaviest items are as close
as possible to the axle and the nose
weight approaches the maximum
p e r m i t t e d w i t h o u t e x c e e d i n g i t .
A i r d e n s i t y d e c r e a s e s w i t h a l t i t u d e ,
t h u s r e d u c i n g e n g i n e p e r f o r m a n c e .
Above 1 000 metres, the maximum
t o w i n g l o a d m u s t b e r e d u c e d b y
1 0 % a n d s o o n f o r e v e r y 1 0 0 0 m e -
t r e s o f a l t i t u d e .
R e f e r t o t h e " T e c h n i c a l D a t a " s e c t i o n
for details of the weights and towing
l o a d s w h i c h a p p l y t o y o u r v e h i c l e .
Side wind
Take into account the increased
s e n s i t i v i t y t o s i d e w i n d . Cooling
Towing a trailer on a slope increases
t h e t e m p e r a t u r e o f t h e c o o l a n t .
A s t h e f a n i s e l e c t r i c a l l y c o n t r o l l e d ,
i t s c o o l i n g c a p a c i t y i s n o t d e p e n d e n t
o n t h e e n g i n e s p e e d .
To lower the engine speed, reduce
y o u r s p e e d .
The maximum towing load on a long
slope depends on the gradient and
t h e a m b i e n t t e m p e r a t u r e .
I n a l l c a s e s , p a y a t t e n t i o n t o t h e
c o o l a n t t e m p e r a t u r e .
If the warning lamp and
the STOP warning lamp
come on, stop the vehicle
and switch off the engine
a s s o o n a s p o s s i b l e .
Braking
Towing a trailer increases the brak-
i n g d i s t a n c e .
Tyres
C h e c k t h e t y r e p r e s s u r e s o f t h e
towing vehicle and of the trailer,
observing the recommended
p r e s s u r e s .
Lighting
Check the electrical signalling on
t h e t r a i l e r .
The rear parking assistance will
b e d e a c t i v a t e d a u t o m a t i c a l l y i f a n
o r i g i n a l C I T R O Ë N t o w b a r i s u s e d .
We recommend the use of genuine
CITROËN towbars and their har-
nesses that have been tested and
approved from the design stage
o f y o u r v e h i c l e , a n d t h a t t h e fi t -
ting of the towbar is entrusted to a
C I T R O Ë N d e a l e r . D r i v i n g w i t h a t r a i l e r s u b j e c t s t h e
t o w i n g v e h i c l e t o m o r e s i g n i fi c a n t
stress and its driver must be particu-
l a r l y c a r e f u l .
Page 164 of 279
157
P R A C T I C A L I N F O R M A T I O N
ROOF BARS
T h e d e s i g n o f y o u r v e h i c l e r e q u i r e s
the use of roof bars and roof box-
e s t h a t a r e t e s t e d a n d a p p r o v e d b y
C I T R O Ë N , f o r y o u r s a f e t y a n d t o a v o i d
damage to the roof and tailgate
R e g a r d l e s s o f t h e t y p e o f l o a d i n g
equipment to be transported on the
r o o f ( r o o f b o x , b i c y c l e c a r r i e r , s k i
c a r r i e r . . . ) , i t i s i m p e r a t i v e t h a t y o u
a d d t r a n s v e r s e r o o f b a r s .
Recommendations
D i s t r i b u t e y o u r l o a d e v e n l y , a v o i d -
i n g o v e r l o a d i n g o n o n e s i d e .
Arrange the heaviest part of the
load as close as possible to the
r o o f .
A n c h o r t h e l o a d s e c u r e l y a n d
s i g n a l i f a n y p a r t o f i t i s o v e r -
h a n g i n g .
D r i v e g e n t l y , a s t h e v e h i c l e w i l l
be more liable to the effects of
s i d e w i n d s ( v e h i c l e s t a b i l i t y m a y
b e a l t e r e d ) .
Remove the roof bars as soon
a s t h e y a r e n o l o n g e r n e e d e d . Bicycle carrier
T h e i n s t a l l a t i o n o f a b i c y c l e c a r r i e r
on the tailgate of the 3-door model is
s t r i c t l y p r o h i b i t e d .
Maximum load that can be dis-
tributed on the roof bars (for a
loading height not exceeding
4 0 c m ; e x c e p t b i c y c l e c a r r i e r ) : 8 0 k g .
If the height exceeds 40 cm, adapt
y o u r s p e e d t o t h e p r o fi l e o f t h e r o a d
to avoid damaging the roof bars
a n d t h e fi x i n g s o n t h e r o o f .
Please refer to national legislation
i n o r d e r t o c o m p l y w i t h t h e r e g u l a -
tions concerning the transportation
of objects which are longer than
t h e v e h i c l e .
* A c c o r d i n g t o c o u n t r y .
VERY COLD CLIMATE SCREEN *
Removable device which prevents
the accumulation of snow at the ra-
d i a t o r c o o l i n g f a n .
Fitting
O f f e r u p t h e v e r y c o l d c l i m a t e
screen to the front of the lower
s e c t i o n o f t h e f r o n t b u m p e r .
P r e s s o n i t s p e r i p h e r y t o c l i p i t s
fi x i n g c l i p s o n e b y o n e .
Removal
Use a screwdriver as a lever to
u n c l i p e a c h fi x i n g c l i p i n t u r n .
D o n o t f o r g e t t o r e m o v e t h e v e r y
cold climate screen:
- when the outside temperature exceeds 10 °C,
- when towing,
- at speeds higher than 75 mph ( 1 2 0 k m / h ) .
Page 172 of 279
162
XII
T E C H N I C A L D A T A
WEIGHTS AND TOWED LOADS (5-DOOR) in kg
Petrol engines 1.4
L
16V
1.6
L
16V
110 hp
1.6
L
16VTi
120 hp
1.6
L
THP
16V 150 hp
1.6
L
THP
16V 140 hp
1.6
L
16V
BioFlex
Gearboxes Manual
Manual
Auto.
Manual
Auto. Manual Auto. Manual
Model codes:
LA... LC... LG... LR...
KFU-C NFU-C NFU-F 5FW-C 5FW-F 5FX-H 5FT-F NFU-C/FF
- Unladen weight 1 182 1 200 1 274 1 220 1 273 1 276 1 290 1 200
- Kerb weight 1 257 1 275 1 349 1 295 1 348 1 351 1 365 1 275
- Payload 520 532 520 511 488 48 7 486 532
- Gross vehicle weight (GVW) 1 702 1 732 1 794 1 731 1 761 1 763 1 776 1 732
- Gross train weight (GTW) 2 902 2 932 2 994 3 031 3 031 3 163 3 076 2 932
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 200 1 200 1 30 0 1 270 1 400 1 300 1 200
on an 8 % or 10 % gradient 1 200 1 200 1 30 0 1 270 1 400 1 300 1 200
on a gradient of less than 8 % 1 500 1 400 1 400 1 300 1 500 1 350 1 400
- Unbraked trailer 628 637 674 645 67 0 645 680 637
- Recommended nose weight 63 61 62 65 70 70 61
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High exterior temperatures may result in a reduction in the perf ormance of the vehicle in order to protect the engine; when
the exterior temperature is higher than 37 °C, limit the wei ght towed.
Page 173 of 279
163
XII
T E C H N I C A L D A T A
WEIGHTS AND TOWED LOADS (3-DOOR) in kg
Petrol engines 1.4
L
16V 1.6
L
16V 110 hp 1.6
L
16VTi 120 hp
1.6
L
THP
16V 150 hp
1.6
L
16V
BioFlex
Gearboxes Manual Manual Auto. Manual Auto. Manual Manual
Model codes:
LA... LC... LG... LR...
KFU-C NFU-C NFU-F 5FW-C 5FW-F 5FX-H NFU-C/FF
- Unladen weight 1 181 1 200 1 278 1 217 1 273 1 271 1 200
- Kerb weight 1 256 1 275 1 353 1 292 1 348 1 346 1 275
- Payload 520 520 520 510 484 48 3 520
- Gross vehicle weight (GVW) 1 701 1 720 1 798 1 727 1 757 1 754 1 720
- Gross train weight (GTW) 2 901 2 920 2 998 3 027 3 027 3 154 2 920
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 200 1 200 1 30 0 1 270 1 400 1 200
on an 8 % or 10 % gradient 1 200 1 200 1 30 0 1 270 1 400 1 200
on a gradient of less than 8 % 1 500 1 400 1 400 1 300 1 500 1 400
- Unbraked trailer 628 637 676 645 67 0 645 637
- Recommended nose weight 63 61 63 65 65 70 61
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High exterior temperatures may result in a reduction in the perf ormance of the vehicle in order to protect the engine; when
the exterior temperature is higher than 37 °C, limit the wei ght towed.
Page 174 of 279
167
XII
T E C H N I C A L D A T A
WEIGHTS AND TOWED LOADS (5-DOOR) in kg
Diesel engines
1.6
L
HDi
16V 92 hp
1.6
L
HDi 16V
92 hp PEF
1.6
L
HDi
16V 110 hp
1.6
L
HDi 16V 110 hp
PEF
2
L
HDi
16V 138 hp
2
L
HDi
16V 140 hp
Gearboxes Manual Manual Manual Manual
Electronic
Gearbox System
Auto. Manual
Model codes:
LA... LC... LG... LR...
9HX-C 9HV-C
9HY-B
9HY-C
9HZ-C 9HZ-H/P RHR-J RHF-8
- Unladen weight 1 257 1 280 1 270 1 280 1 293 1 416 1 381
- Kerb weight 1 332 1 355 1 345 1 355 1 368 1 491 1 456
- Payload 520 520 530 520 507 46 4 468
- Gross vehicle weight (GVW) 1 777 1 800 1 800 1 800 1 800 1 88
0 1 849
- Gross train weight (GTW) 3 077 3 100 3 100 3 100 3 350 3 44
9
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 300 1 300 1 30 0 1 300 1 570 1 500
on an 8 % or 10 % gradient 1 300 1 300 1 30 0 1 300 1 570 1 500
on a gradient of less than 8 % 1 300 1 300 1 300 1 300 1 570 1 800
- Unbraked trailer 666 677 672 677 67 5 740 738
- Recommended nose weight 66 66 66 66 65 70 73
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High exterior temperatures may result in a reduction in the perf ormance of the vehicle in order to protect the engine; when
the exterior temperature is higher than 37 °C, limit the wei ght towed.
Page 175 of 279
168
XII
T E C H N I C A L D A T A
The GTW and towed load values indicated apply up to a maximum altitude of 1,000 metres; the towed load mentioned
must be reduced by 10 % for each additional 1,000 metres of a ltitude.
The speed of a towing vehicle must not exceed 100 km/h (appro x. 60 mph) (comply with the legislation in force in your
country).
High exterior temperatures may result in a reduction in the perf ormance of the vehicle in order to protect the engine; when
the exterior temperature is higher than 37 °C, limit the wei ght towed.
WEIGHTS AND TOWED LOADS (3-DOOR) in kg
Diesel engines
1.6
L
HDi
16V 92 hp
1.6
L
HDi 16V
92 hp PEF
1.6
L
HDi
16V 110 hp
1.6
L
HDi 16V 110 hp
PEF
2
L
HDi
16V 138 hp
2
L
HDi
16V 140 hp
Gearboxes Manual Manual Manual Manual
Electronic
Gearbox System
Auto. Manual
Model codes:
LA... LC... LG... LR...
9HX-C 9HV-C
9HY-B
9HY-C
9HZ-C 9HZ-H/P RHR-J RHF-8
- Unladen weight 1 255 1 279 1 269 1 279 1 293 1 410 1 379
- Kerb weight 1 330 1 354 1 344 1 354 1 368 1 485 1 454
- Payload 520 520 521 520 497 47 0 456
- Gross vehicle weight (GVW) 1 775 1 799 1 790 1 799 1 790 1 88
0 1 835
- Gross train weight (GTW) 3 075 3 099 3 090 3 099 3 090 3 45
0 3 335
- Braked trailer (within GTW limit)
on a 10 % or 12 % gradient 1 300 1 300 1 30 0 1 300 1 570 1 500
on an 8 % or 10 % gradient 1 300 1 300 1 30 0 1 300 1 570 1 500
on a gradient of less than 8 % 1 300 1 300 1 300 1 300 1 570 1 800
- Unbraked trailer 665 677 672 677 67 5 740 727
- Recommended nose weight 66 66 66 66 65 70 73
