2009 Citroen C4 DAG Owner's Manual

60
IV
A C C E S S
Lost keys
Visit a CITROËN dealer with the vehi-
cle's V5 registration document and your
personal identifi cation documents.
The CITROËN dealer will be able to
retrieve the key code and the trans-
ponder code required to order a
replacement key.
Remote control
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is a
possibility that it may unlock the vehi-
cle, without you being aware of it.
Do not repeatedly press the buttons
of your remote control out of range
and out of sight of your vehicle. You
run the risk of stopping it from work-
ing and the remote control would
have to be reinitialised.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off, ex-
cept for reinitialisation.
Locking the vehicle
Driving with the doors locked may
make access to the passenger com-
partment by the emergency services
more diffi cult in an emergency.
As a safety precaution (with children
on board), remove the key from the
ignition when you leave the vehicle,
even for a short time. Anti-theft protection
Do not make any modifi cations to
the electronic engine immobiliser
system; this could cause malfunc-
tions.
When purchasing a second-
hand vehicle
Have the key codes memorised by a
CITROËN dealer, to ensure that the
keys in your possession are the only
ones which can start the vehicle.
Do not throw the remote
control batteries away, they
contain metals which are
harmful to the environment.
Take them to an approved collection
point.

58
IV
A C C E S S
STARTING
1. "S": Steering lock
To unlock the steering, gently move
the steering wheel while turning the
key, without forcing it.
2. "M": Drive position
Depending on the version of your
vehicle, the orange and red warning
lamps should also come on for a short
time.
3. "D": Starter
Release the key as soon the engine
has started.
If the fi rst attempt fails, switch off the
ignition. Wait ten seconds then operate
the starter again. Steering lock

1. "
S": After removing the key, turn
the steering wheel to lock the steer-
ing. The key can only be removed in
position S .

2. "M": Ignition switched on, the
steering is unlocked (by turning the
key to position M , move the steering
wheel gently if necessary).

3. "D": Starter position.
Never turn the key to this position
when the engine is running.
Key in ignition buzzer
If you forget to remove the key from
the ignition, a buzzer sounds when
the driver’s door is opened.
DO NOT RUN THE ENGINE IN AN
ENCLOSED SPACE OR WHERE
THERE IS INSUFFICIENT VENTI-
LATION.

IT IS ESSENTIAL ALWAYS TO
KEEP THE ENGINE RUNNING
IN ORDER TO RETAIN BRAKING
AND STEERING ASSISTANCE .

NEVER REMOVE THE IGNITION
KEY BEFORE THE VEHICLE
HAS COME TO A COMPLETE
STOP.
Vehicles equipped with a
turbocharger
Never stop the engine without having
allowed it to run for a few seconds at
idle, this being the time required for
the turbocharger to return to a normal
speed.
Flicking the accelerator at the mo-
ment of switching off the ignition
could cause serious damage.

61
IV
A C C E S S
ALARM
System which protects and provides
a deterrent against the theft of your
vehicle. It provides two types of pro-
tection, exterior and interior, as well
as an anti-tamper function.
Exterior perimiter protection
The system detects opening of the
vehicle.
The alarm is triggered if anyone tries
to enter the vehicle by forcing a door,
the boot or the bonnet.
Interior volumetric protection
The system detects any variation in
the volume in the passenger com-
partment.
The alarm is triggered if anyone breaks
a window or moves inside the vehicle.
If you wish to leave a pet in the ve-
hicle or a window partially open,
deactivate the interior volumetric
protection.
Anti-tamper function
The system detects the putting out
of service of its components.
The alarm is triggered if anyone
tries to put the wires of the siren, the
central control or the battery out of
service.
Do not make any modifi cations to
the alarm system, this could cause
malfunctions. Locking the vehicle with full
alarm
Activation

 Switch off the ignition and get out
of the vehicle.

 Lock or deadlock the vehicle us-
ing the locking button on the re-
mote control.
The alarm is activated; the indicator
light on button A fl ashes once per
second.
Deactivation

 Unlock the vehicle using the
unlocking button on the remote
control.
The alarm is deactivated; the indica-
tor light on button A switches off. Locking the vehicle with
exterior protection alarm only
Deactivation of the interior
volumetric protection

 Switch off the ignition.

 Within ten seconds, press but-
ton A until the indicator lamp is lit
continuously.

 Get out of the vehicle.

 Lock or deadlock the vehicle us-
ing the locking button on the re-
mote control.
The exterior protection alarm alone
remains activated; the indicator
lamp on button A fl ashes once per
second.
To be effective, this deactivation
must be carried out each time the
ignition is switched off.
Reactivation of the interior
volumetric protection

 Unlock the vehicle using the
unlocking button on the remote
control.

 Relock the vehicle using the re-
mote control.
The alarm is activated again with
both types of protection; the indica-
tor lamp on button A switches off.

62
IV
A C C E S S
Triggering
This is indicated by sounding of the
siren and fl ashing of the direction
indicators for approximately thirty
seconds.
After it has been triggered, the alarm
is again operational.
If the alarm is triggered ten times in
succession, the eleventh time will
result in it becoming inactive. If the indicator lamp on button A
fl ashes rapidly, this indicates that
the alarm was triggered during
your absence. When the ignition is
switched on, this fl ashing stops im-
mediately.
To avoid triggering the alarm when
washing your vehicle, lock it using
the key.
Do not activate the alarm before
disconnecting the battery, other-
wise the siren will sound. Failure of the remote control

 Unlock the vehicle using the key
in the driver's door lock.

 Open the door; the alarm is trig-
gered.

 Switch on the ignition; the alarm
stops.
Locking the vehicle without
alarm

 Lock or deadlock the vehicle us-
ing the key in the driver's door
lock.
* According to country.
Malfunction
When the ignition is switched on,
lighting of the indicator lamp on but-
ton
A for ten seconds indicates a si-
ren fault.
Have it checked by a CITROËN
dealer. Automatic operation *
Depending on the legislation in force
in your country, one of these cases
may occur:
- 45 seconds after the vehicle is
locked using the remote control,
the alarm is activated, regard-
less of the status of the doors
and boot.
- 2 minutes after the last door or the boot is closed, the alarm is
activated.

 To avoid triggering the alarm
on entering the vehicle, fi rst
press the unlocking button on
the remote control.

63
IV
A C C E S S
ELECTRIC WINDOWS
System intended to open or close a
window manually or automatically.
Fitted with a safety anti-pinch sys-
tem and a system for deactivation in
the event of misuse of the rear con-
trols.

1. Driver's electric
window control.

2. Passenger's electric
window control.

3. Rear right electric
window control.

4. Rear left electric
window control.

5. Deactivation of the rear
electric window and door
controls. One-touch electric
windows
There are two options:
-
manual mode

 Press or pull the control gently.
The window stops when the
control is released.
- automatic mode

 Press or pull the control fi rmly.
The window opens or closes
fully when the control is re-
leased.

 Pressing the control again
stops the movement of the
window.
The electric window controls re-
main operational for approximately
45 seconds after the ignition is
switched off or until the vehicle is
locked after a door is opened.
If one of the passenger windows can-
not be operated from the driver's door
control pad, carry out the operation
from the control pad of the passenger
door concerned, and vice versa. Safety anti-pinch
When the window rises and meets
an obstacle, it stops and partially
lowers again.
If the window cannot be closed (for
example, in the presence of ice),
immediately after the movement is
reversed:

 press and hold the control until
the window opens fully,

 then pull the control immediate-
ly and hold it until the window
closes,


 continue to hold the control for
approximately one second after
the window has closed.

The safety anti-pinch function is
not operational during these ope-
rations.

64
IV
A C C E S S
Reinitialisation
If a window does not rise automati-
cally, its operation must be reinitial-
ised:

 pull the control until the window
stops,

 release the control and pull it
again until the window closes
fully,

 continue to hold the control for
approximately one second after
the window has closed,

 press the control to lower the
window automatically to the low
position,

 when the window has reached
the low position, press the con-
trol again for approximately one
second.

The safety anti-pinch function is
not operational during these ope-
rations. Deactivation of the rear
electric window and door
controls

 For the safety of your children,
press control 5 to deactivate the
rear electric window controls re-
gardless of their position.
Indicator lamp on, the rear controls
are deactivated.
Indicator lamp off, the rear controls
are activated. Always remove the key from the
ignition when leaving the vehicle,
even for a short time.
If an obstacle is encountered during
operation of the electric windows,
you must reverse the movement of
the window. To do this, press the
control concerned.
When the driver operates the con-
trols for the passengers' electric
windows, he must ensure that no
one is preventing correct closing of
the windows.
The driver must ensure that the pas-
sengers use the electric windows
correctly.
Be aware of children when operating
the windows.
This warning lamp comes
on temporarily on the instru-
ment panel on deactivation
and each time the ignition is
switched on. This control also deactivates the
interior controls for the rear doors
(refer to the section "Child safety -
§ Electric child lock").
Any other status of the indicator
lamp indicates a malfunction of the
electric child lock. Have it checked
by a CITROËN dealer.

65
IV
A C C E S S
DOORS
Opening
From outside When the selective unlocking is acti-
vated, the fi rst press of the remote
control unlocking button permits
unlocking of the driver’s door only.
 Pull on the front door control to
open the door; this unlocks the
vehicle completely.

 Pull on the rear door control to
open the door; this unlocks the
door concerned only.
With the selective unlocking acti-
vated:
- the driver’s door control unlocks the driver’s door only.
- the other door controls unlock the other doors and the boot.
The interior door controls do not
operate when the vehicle is dead-
locked. Central manual control
System which provides full manual
locking or unlocking of the doors
and boot from the inside.
Locking

 Press button A to lock the vehicle.
The red indicator lamp on the button
comes on.
If one of the doors is open, the cen-
tral locking from the inside does not
take place.
If the boot is open, the central lock-
ing from the inside is active for the
doors, to permit the transportation
of long objects.

 After unlocking the vehicle com-
pletely using the remote control
or the key, pull the door handle. From inside

66
IV
A C C E S S
Unlocking

 Press button A again to unlock
the vehicle.
The red indicator lamp on the button
switches off.
If the vehicle is locked or dead-
locked from the outside, the red in-
dicator lamp fl ashes and button A
is inactive.

 In this case, use the remote
control or the key to unlock the
vehicle.
Central automatic control Locking
When the speed exceeds 6 mph
(10 km/h), the doors and boot lock
automatically.
If one of the doors is open, the auto-
matic central locking does not take
place.
If the boot is open, the automatic cen-
tral locking of the doors is active.
Unlocking

 Above 6 mph (10 km/h), press
button A to unlock the doors and
boot temporarily.
Activation

 Press button A for more than two
seconds.
A confi rmation message appears on
the multifunction screen.
Deactivation

 Press button A again for more
than two seconds.
A confi rmation message appears on
the multifunction screen.
Emergency control
System which locks or unlocks the
doors mechanically in the event of
a malfunction of the battery or of the
central locking. Locking the driver’s door

 Insert the key in the lock, then
turn it to the right.
Locking the front and rear
passenger doors

 Insert the key in the lock, located
on the edge of the door, then turn
it one eighth of a turn .
System which provides full automat-
ic locking or unlocking of the doors
and boot while driving.
You can activate or deactivate this
function. Unlocking the driver’s door

 Insert the key in the lock, then
turn it to the left.
Unlocking the front and rear
passenger doors

 Pull the interior door opening
control.
