2009 CHEVROLET KODIAK keyless

Keys...............................................................2-2
Remote Keyless Entry (RKE) System................2-3
Remote Keyless Entry (RKE) System
Operation...................................................2-4
Doors and Locks.............................................2-6
Door Locks....................................................2-6
Power Door Locks..........................................2-7
Windows.........................................................2-8
Manual Windows............................................2-9
Power Windows.............................................2-9
Sliding Rear Window.......................................2-9
Sun Visors....................................................2-9
Starting and Operating Your Vehicle................2-10
New Vehicle Break-In....................................2-10
Ignition Positions..........................................2-11
Engine Starter Over-Crank Protection..............2-12
Starting the Gasoline Engine..........................2-12
Starting the Diesel Engine..............................2-14
Engine Alarm and Automatic Shutdown............2-18
Idle Shutdown..............................................2-19
High Idle System..........................................2-20
Exhaust Restrictor (Engine Warm-Up)..............2-22
Engine Checks Before Operating....................2-23
Engine Coolant Heater..................................2-25Diesel Engine Exhaust Brake.........................2-26
Automatic Transmission Operation...................2-27
Manual Transmission Operation......................2-28
Power Take-Off (PTO)...................................2-30
Four-Wheel Drive..........................................2-30
Parking.......................................................2-35
Two-Speed Rear Axle...................................2-36
Parking Brake (With Hydraulic Brakes).............2-38
Parking Brake (With Air Brakes)......................2-41
Parking Brake Burnish Procedure....................2-43
Air Suspension
.............................................2-44
Parking Over Things That Burn.......................2-44
Engine Exhaust............................................2-45
Diesel Particulate Filter..................................2-46
Running the Vehicle While Parked..................2-50
Mirrors...........................................................2-51
Manual Rearview Mirror.................................2-51
Outside Manual Mirrors..................................2-51
Outside Power Mirrors...................................2-51
Outside Convex Mirrors.................................2-52
Outside Heated Mirrors..................................2-52
Storage Areas................................................2-53
Center Console Storage.................................2-53
Section 2 Features and Controls
2-1

Remote Keyless Entry (RKE)
System
If this vehicle has the Remote Keyless Entry (RKE)
system, it operates on a radio frequency subject
to Federal Communications Commission (FCC) Rules
and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.If there is a decrease in the RKE operating range,
try this:
•Check the distance. The transmitter may be too far
from the vehicle. Stand closer during rainy or
snowy weather.
•Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the
left or right, hold the transmitter higher, and
try again.
•Check the transmitter’s battery. See “Battery
Replacement” later in this section.
•If the transmitter is still not working correctly, see
your dealer/retailer or a qualified technician for
service.
2-3

Remote Keyless Entry (RKE)
System Operation
For vehicles with the Remote Keyless Entry (RKE)
System, transmitter functions work up to 30 feet (9 m)
away from the vehicle.
LOCK:Press to lock all the doors.
UNLOCK:Press once to unlock the driver door.
Press this button again within five seconds to unlock all
the doors. The interior dome lamp comes on for about
40 seconds or until the ignition switch is activated.
Programming Transmitters to the
Vehicle
Only RKE transmitters programmed to the vehicle
will work. If a transmitter is lost or stolen, a replacement
can be purchased and programmed through your
dealer/retailer. When the replacement transmitter is
programmed to the vehicle, all remaining transmitters
must also be programmed. Any lost or stolen transmitters
no longer work once the new transmitter is programmed.
Each vehicle can have up to four transmitters
programmed to it.
Battery Replacement
Notice:When replacing the battery, do not touch
any of the circuitry on the transmitter. Static
from your body could damage the transmitter.
2-4

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
•Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. You increase the chance of
being thrown out of the vehicle in a crash if
the doors are not locked. So, wear safety
belts properly and lock the doors whenever
you drive.
CAUTION: (Continued)
CAUTION: (Continued)
•
Young children who get into unlocked vehicles
may be unable to get out. A child can be
overcome by extreme heat and can suffer
permanent injuries or even death from heat
stroke. Always lock your vehicle whenever
you leave it.
•Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.
On a vehicle equipped with keyless entry, you can
use your transmitter to lock or unlock your vehicle. See
Remote Keyless Entry (RKE) System Operation on
page 2-4.
To lock or unlock the door from the outside, use the key.
2-6

Aftermarket Engine Performance
Enhancement Products and
Modifications
Some aftermarket engine performance products and
modifications promise a way to increase the horsepower
and torque levels of the vehicle’s powertrain. You should
be aware that these products could have harmful effects
on the performance and life of the engine, exhaust
emission system, transmission, and drivetrain. The
engines, transmissions, and drivetrains have been
designed and built to offer industry leading durability and
performance in the most demanding applications. Engine
power enhancement products may enable the engine to
operate at horsepower and torque levels that could
damage, create failure, or reduce the life of the engine,
engine emission system, transmission, and drivetrain.
Damage, failure, or reduced life of the engine,
transmission, emission system, drivetrain, or other
vehicle components caused by aftermarket engine
performance enhancement products or modifications
might not be covered under the vehicle warranty.
California Proposition 65 Warning
Most motor vehicles, including this one, contain and/or
emit chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
Engine exhaust, many parts and systems (including
some inside the vehicle), many fluids, and some
component wear by-products contain and/or emit
these chemicals.
California Perchlorate Materials
Requirements
Certain types of automotive applications, such as airbag
initiators, seat belt pretensioners, and lithium batteries
contained in remote keyless transmitters, may contain
perchlorate materials. Special handling may be
necessary. For additional information, see
www.dtsc.ca.gov/hazardouswaste/perchlorate.
5-4

K
Keyless Entry System....................................... 2-3
Keys............................................................... 2-2
L
Lamp
Malfunction Indicator....................................3-36
Lamps
Dome ........................................................3-16
Marker.......................................................3-16
Reading.....................................................3-17
Lap Belt........................................................1-27
Lap-Shoulder Belt...........................................1-24
LATCH System for Child Restraints...................1-40
Light
Airbag Off..................................................3-28
Airbag Readiness........................................3-27
Antilock Brake System (ABS) Warning............3-33
Brake System Warning.................................3-31
Change Engine Oil......................................3-39
Change Fuel Filter Warning..........................3-45
Charging System.........................................3-29
Check Gages Warning.................................3-43
Daytime Running Lamps Indicator..................3-42
Diesel Particulate Filter Warning....................3-46
Differential Lock Indicator..............................3-41
Engine Overspeed Warning...........................3-40Light (cont.)
Engine Shutdown Warning............................3-40
Exhaust Brake Indicator................................3-41
Highbeam On.............................................3-42
Low Coolant Warning...................................3-35
Low Oil Level.............................................3-39
Low Washer Fluid Warning...........................3-43
Power Take-Off...........................................3-43
Range Inhibit Warning Indicator.....................3-31
Reduced Engine Power................................3-42
Safety Belt Reminders..................................3-26
Service Transmission Warning.......................3-30
Trailer Antilock Brake System Warning............3-34
Wait to Start Indicator..................................3-35
Water in Fuel Warning.................................
3-45
Lighting
Entry.........................................................3-17
Lights
Exterior Lamps............................................3-14
High/Low Beam Changer................................ 3-8
On Reminder..............................................3-14
Loading Your Vehicle.......................................4-20
Locks
Door ........................................................... 2-6
Power Door .................................................. 2-7
Loss of Control...............................................4-12
Low Coolant Warning Light..............................3-35
Low Washer Fluid Warning Light.......................3-43
Lower Anchors and Tethers for Children.............1-40
7

Outside
Convex Mirrors............................................2-52
Heated Mirrors............................................2-52
Manual Mirrors............................................2-51
Power Mirrors.............................................2-51
Overspeed Warning Light.................................3-40
P
Paint, Damage...............................................5-93
Park Brake............................................2-38, 2-41
Parking.........................................................2-35
Brake Burnish Procedure..............................2-43
Over Things That Burn.................................2-44
Two-Speed Rear Axle..................................2-36
Part A - Scheduled Maintenance Services............ 6-4
Part B - Owner Checks and Services................6-26
PartC-Recommended Fluids and
Lubricants..................................................6-31
PartD-Maintenance Record...........................6-33
Passing.........................................................4-11
Perchlorate Materials Requirements,
California..................................................... 5-4
Power
Door Locks.................................................. 2-7
Electrical System.........................................5-96
Reduced Engine Light..................................3-42
Steering Fluid.............................................5-49
Windows...................................................... 2-9
Power Take-Off Light.......................................3-43Power Take-Off (PTO).....................................2-30
Privacy..........................................................7-11
Event Data Recorders..................................7-12
Navigation System.......................................7-13
OnStar.......................................................7-13
Radio Frequency Identification.......................7-13
R
Radio Frequency Identification (RFID),
Privacy......................................................7-13
Radio(s)........................................................3-49
Radios
Reception...................................................3-58
Setting the Clock.........................................3-48
Theft-Deterrent............................................3-57
Range Inhibit Warning Indicator........................3-31
Reading Lamps..............................................3-17
Rear Axle......................................................5-67
Differential Lock Control................................. 4-7
Shift Motor.................................................5-68
Rear Heating System......................................3-23
Rear Seat Operation.......................................1-10
Rearview Mirrors.............................................2-51
Reduced Engine Power Light............................3-42
Remote Keyless Entry (RKE) System.................. 2-3
Remote Keyless Entry (RKE) System,
Operation..................................................... 2-4
Replacement Parts, Maintenance.....................5-108
9
