2009 CADILLAC ESCALADE EXT Owners Manual

2. Unlock the cargo panel 3 by pulling forward on the
driver side and passenger side cargo panel latches,
located on the bottom of each cargo panel.
3. Remove cargo panel 2 in the same way and set it
aside. Remove as many cargo panels as needed.
4. To remove cargo panel 1, unlock the two rear
latches, lift the cover slightly and pull rearward.
After each cargo panel is removed, store them within
the cargo storage area using the cargo panel storage
system.
Cargo Panel Storage System
The three cargo panels can be stored in the cargo area
using the storage strap system. Always use the
storage strap system to store the cargo panels while
driving.
2-69

To store the panels:
1. Secure the storage
strap system in the
cargo storage area by
attaching the six clips
on the cargo strap
system to the tie down
locations on either side
of the storage area.
Before storing the cargo panels, make sure that
their latches are in the locked position. The latches
are in the locked position when they are parallel
to the front and back edge of the panel.Use the following instructions for the proper storage
sequence and location for each panel:
A. Secure clip A on the secondary strap.
B. Secure clip B on the secondary strap.
C. Place the remaining primary straps on top of the
lid and tray at the top of the cargo area.
2-70

2. Starting with cargo panel 1, load the cargo panel
with the latches facing up toward the side of the
cargo box.
Do the same for cargo panel 2 then 3. Make sure to
store panel 2 with the latches facing down and
panel 3 with latches facing up toward the side of the
cargo box.3. Place the primary straps over the three cargo
covers (A). Fasten the four strap clips (B).
2-71

4. Tighten all straps by pulling on the free end of
each strap.5. Close both cross locks at the center of the strap
system to secure tightly.
2-72

Reinstalling the Cargo Cover Panels
The strap system can remain attached to the side of the
cargo area while it is not in use, or it can be stored
inside the top box storage compartment. SeeTop-Box
Storage on page 2-81for more information.
To reinstall a cargo panel:
1. Starting with cargo panel 1, place the latches in the
unlocked position. Place cargo panel 1 on the cargo
area rails while holding the back of the cargo
panel up. Panels 3, 2, 1 Loaded
2-73

Place the cover on the cargo box within 4 inches of
the Midgate®and lower the rear of the panel
within 2 to 3 inches from the top of the cargo box.
Push the cover forward making sure that the
guide block engages the retainer bracket opening.
Continue to push forward until the panel is fully
seated against the Midgate. Then lower the rear of
the cover to engage the striker pegs (A) to align
with the striker assembly (B).2. The driver side cargo cover panel latch must lock in
place before the passenger side latch can be
locked. If this procedure is not followed exactly, the
cargo cover panels might not correctly lock in
place. Push the driver side latch toward the front of
the vehicle to lock the cover in position. A click
sounds when each latch locks. Lock the remaining
passenger side latch on panel 1. Driver Side Shown, Passenger Side Similar
2-74

3. Install cargo cover 2 followed by 3 next. Place the
latches in the unlocked position. Place the cargo
cover panel on the cargo area rails while holding the
back of the cargo panel up.
Push the panel forward until it is snug against the
other panel and then let the back of the panel down
making sure that the pegs (A) align with the
receivers (B).4. Push the latches toward the front of the vehicle,
starting with the driver side latch, to lock the
panel in place. A click sounds when each latch
locks correctly.
Folding and Storage of Straps
Fold the straps for storing inside the top box storage
compartment:
1. Extend the six strap ends on a at surface.
Driver Side Shown, Passenger Side Similar
2-75

2. Fold the four primary strap ends towards the center
as shown.
3. Take the short strap and surround the folded
webbing, forming a package.4. Take the secondary strap and wrap it around the
folded webbing, forming a package. Finally, attach
the hooks to the webbing and place inside the
top box storage compartment.
2-76
