2009 CADILLAC ESCALADE ESV navigation system

Remote Control To use the remote control, aim it at the transmitter
window at the rear of the overhead console and press
the desired button. Direct sunlight or very bright light
can affect the ability of the RSE transmitter to receive
signals from the remote control. If the remote control
does not seem to be working, the batteries may need
to be replaced. See “Battery Replacement” later in
this section. Objects blocking the line of sight can
also affect the function of the remote control.
If a CD or DVD is in the Radio DVD slot, the remote
control power button can be used to turn on the video
screen display and start the disc. The radio can also
turn on the video screen display. See Navigation Audio
System on page 4-62 for more information.
Notice: Storing the remote control in a hot area or
in direct sunlight can damage it, and the repairs will
not be covered by the warranty. Storage in extreme
cold can weaken the batteries. Keep the remote
control stored in a cool, dry place.
If the remote control becomes lost or damaged,
a new universal remote control can be purchased.
If this happens, make sure the universal remote control
uses a code set of Toshiba ®
. Remote Control Buttons
O (Power): Press to turn the video screen on and off.
P (Illumination): Press to turn the remote control
backlight on. The backlight automatically times out after
7 to 10 seconds if no other button is pressed while
the backlight is on.
v (Title): Press to return the DVD to the main menu
of the DVD. This function can vary for each disc.
3-92

SOUND AROUND ON/OFF: Press to turn the FM
Transmitter power on or off.
MUTE
> (For DVD Only): Press to turn off the
headphone sound. Press again to turn the sound
on again.
PIX (Picture Selection): Press to adjust the picture’s
On Screen Display (OSD). Each time this button is
pressed, the picture adjustment OSD, cycles through
bars for BRIGHTNESS, CONTRAST, COLOR, and TINT.
Use the right/left navigation arrows to adjust the setting.
This feature automatically shuts off id another button is
pressed or adjustments are not made within six seconds.
SOUND AROUND SELECT: Press to select an FM
transmitter channel. The SOUND AROUND SELECT
lets the DVD audio play over the vehicle’s sound system
by tuning the radio to one of the six FM frequencies
listed below.
CH1: 88.3MHz
CH2: 88.7MHz
CH3: 89.1MHz
CH4: 89.5MHz
CH5: 89.9MHz
CH6: 90.3MHz
MENU: Press to enter the DVD disc menu while the
disc is playing. Q ,
R ,
q ,
r (Navigation Arrows): Press to navigate
through menus.
ENTER: Press to enter a selected function or to begin
playback of the disc.
REPEAT
7 : Press to repeat part or all of a chapter,
title, track, or the entire disc after using the A-B button to
setup repeat preset sections.
RETURN
8 : This button is not used with the system.
A-B: This button is used to setup repeat preset
sections. Press this button once while the disc is playing
to select the starting position. Press a second time to
select the end position. Press a third time to turn the
function off. To view the preset section, press
7 .
AUTO MEMORY: This button is not used with the
system.
SEARCH/SKIP: This button is not used with the
system.
ERASE/ADD: This button is not used with the system.
R-S: This button is not used with the system.
3-103

Playing Audio CD When an audio CD is playing, the display shows the
current track and the amount of time that track has been
playing, the total amount of time on the disc, and the
current time running on the disc.
DISPLAY: Press to choose from the following display
options:
1. Press DISPLAY once and Single Elapsed appears
along with the current track playing and the length
of time for that track.
2. Press DISPLAY twice and Single Remain appears
along with the current track playing and the amount
of time left on the track.
3. Press DISPLAY three times and Total Elapsed
appears along with the current track playing and
the total time that has played on the CD.
4. Press DISPLAY four times and Total Remain
appears along with the current track playing and
the amount of time left on the CD. REPEAT: Press to toggle between Track and All.
The default for repeat is OFF.
Track repeats the track that is playing.
All repeats the disc that is playing.
Playing MP3 CD MP3 is the format for storing digital audio. An audio CD
quality song can be compressed into the MP3 format with
very little loss of quality, while taking up much less space.
CD-R/RW discs that have been encoded in MP3 format
can be played on the DVD player. See “Using an MP3”
under the Audio System(s) section in the vehicle’s owner
manual.
Selecting Folders and Songs When an MP3 disc is inserted in the player, the
navigation screen appears. The folders and songs
can be changed by navigating through the le system.
The DVD player plays the songs in the order they
were burned to the disc.
3-110

Overview ........................................................ .4-2
Navigation System Overview ........................... .4-2
Getting Started .............................................. .4-4
Cleaning the Display .................................... .4-12
Features and Controls ................................... .4-13
Using the Navigation System ......................... .4-13
Maps ......................................................... .4-15
Symbols ..................................................... .4-19
Destination ................................................. .4-25
Congure Menu ........................................... .4-43
Global Positioning System (GPS) ................... .4-59 Vehicle Positioning ....................................... .4-60
Problems with Route Guidance ...................... .4-61
If the System Needs Service ......................... .4-61
Ordering Map DVDs ..................................... .4-61
Database Coverage Explanations ................... .4-62
Navigation Audio System ............................... .4-62
CD Player .................................................. .4-71
DVD Player ................................................ .4-78
Care of Your CDs and DVDs ........................ .4-84
Auxiliary Devices ......................................... .4-85
Voice Recognition ......................................... .4-86
Section 4 Navigation System
4-1

Overview Navigation System Overview
Screen shown with Map Disc Inserted
4-2

A. Source (AM, FM, XM, CD, etc.) Touch Screen
Button. See Navigation Audio System on page 4-62
for more information.
B. Clock Touch Screen Button. See “Setting the Clock”
under Configure Menu on page 4-43 for more
information.
C. POI (Point of Interest) Touch Screen Button.
See “Displaying Points of Interest (POI) on the
Map Screen” under Symbols on page 4-19 for
more information.
D.
1 (Zoom Out) Touch Screen Button.
See “Map Scales” under Maps on page 4-15
for more information.
E.
y©¨z (Seek) Key (Previous/Next).
See Navigation Audio System on page 4-62
for more information.
F.
w (Tune) Knob. See Navigation Audio System
on page 4-62 for more information.
G. NAV (Navigation) Key. See “Hard Keys” under
Using the Navigation System on page 4-13 for
more information.
H. RPT (Repeat) Key. See “Hard Keys” under Using
the Navigation System on page 4-13 for more
information.
I. DEST (Destination) Key. See Destination on
page 4-25 for more information. J. CONFIG (Congure) Key. See Configure Menu on
page 4-43 for more information.
K.
e (Sound) Key. See “Sound Menu” under
Navigation Audio System on page 4-62 for
more information.
L.
5 (Phone) Key. See OnStar ®
System on page 2-52
and Bluetooth ®
on page 3-75 for more information.
M. FAV (Favorite) Key. See “Storing Radio Station
Presets” under Navigation Audio System on
page 4-62 for more information.
N. AUDIO Key. See Navigation Audio System on
page 4-62 for more information.
O.
M (Disc Up/Down) Key. See “Hard Keys” under
Using the Navigation System on page 4-13 for more
information.
P.
O /
n (Power/Volume) Knob. See Navigation
Audio System on page 4-62 for more information.
Q. CD/DVD Video/Audio Slot. See CD Player on
page 4-71 or DVD Player on page 4-78 for more
information.
R.
Z (CD/DVD Video/Audio Eject) Key. See CD
Player on page 4-71 or DVD Player on page 4-78
for more information.
S.
M (Load) Key. See CD Player on page 4-71 or
DVD Player on page 4-78 for more information.
4-3

T. Map DVD Slot. See “Installing the Map DVD” under
Maps on page 4-15 for information on how to
install and eject a map DVD.
U.
Z (DVD Map Disc Eject) Key. See Maps on
page 4-15 for more information.
V. Mark Touch Screen Button. See “Adding
Destinations to the Address Book” under
Destination on page 4-25 for more information.
W.
0 (Zoom In) Touch Screen Button.
See “Map Scales” under Maps on page 4-15
for more information.
X. Map Scale. See “Map Scales” under Maps on
page 4-15 for more information.
Y. North Up/Heading Up Symbol. See Symbols on
page 4-19 for more information.
Z. No GPS Symbol. See Symbols on page 4-19 for
more information.
AA. FULL MAP Touch Screen Button. See “NAV” under
“Hard Keys” under Using the Navigation System
on page 4-13 for more information. Getting Started Read this manual thoroughly to become familiar with
how the navigation system operates.
The navigation system includes navigation and audio
functions.
While entering the vehicle or when turning the vehicle
off, some DVD Map Disc noise is normal.
Keeping your eyes on the road and your mind on the
drive is important for safe driving. The navigation system
has built-in features intended to help keep your eyes on
the road and mind on the drive. Some features may be
disabled while driving. Note that these functions will be
grayed-out. A grayed-out function indicates it is not
available when the vehicle is moving.
4-4

All functions are available when the vehicle is parked.
Do the following before driving:
Become familiar with the navigation system
operation, hard keys on the faceplate, and
touch-sensitive screen buttons of the navigation
system.
Set up the audio by presetting favorite stations,
setting the tone, and adjusting the speakers.
Set up the navigation features before beginning
driving, such as entering an address or a preset
destination.
Set up your phone numbers in advance so they can
be called easily with the press of a single button or
a single voice command (for navigation systems
equipped with phone capability).
{ CAUTION: Taking your eyes off the road too long or too often
while using the navigation system could cause a
crash resulting in injury or death to you or others.
Focus your attention on driving. { CAUTION: Avoid looking too long or too often at the moving
map on the navigation screen. This could cause a
crash and you or others can be injured or killed.
Use the turn-by-turn voice guidance directions
whenever possible.
Use the navigation system to:
Plan a route.
Select a destination using various methods and
choices.
Follow turn-by-turn route and map guidance with
voice prompts, only if permitted by traffic laws,
controls, and conditions.
You should always be alert and obey traffic and
roadway laws and instructions, regardless of the
guidance from the navigation system. Because the
navigation system uses street map information that
does not include all traffic restrictions or the latest road
changes, it may suggest using a road that is now closed
for construction or a turn that is prohibited by signs
at the intersection. Because the system uses limited
information, you must always evaluate whether following
the system’s directions is safe and legal for the current
conditions.
4-5
