2009 CADILLAC DTS instrument panel

Ashtray(s)
Notice:If papers, pins, or other ammable items
are put in the ashtray, hot cigarettes or other
smoking materials could ignite them and possibly
damage the vehicle. Never put ammable items
in the ashtray.
Front Ashtray
With the full oor console, the ashtray is located below
the climate control system. To open, push down and
then release the cover. To clean the ashtray, push
the lip of the ashtray to remove it. Push the opposite
side of the ashtray’s lip to install.
For vehicles without the oor console, pull the tray
located below the climate controls to reveal the ashtray.
The ashtray can be removed by pulling on the ledge
located at the top of the ashtray.
Rear Ashtray
The ashtrays are located on the door armrests.
To use an ashtray, lift the lid.
Analog Clock
The analog clock is located on the instrument panel
above the radio. The clock is not connected with
any other vehicle system and runs by itself. To adjust
the clock:
1. Locate the adjustment button directly below the
clock face.
2. Push and hold the adjustment button to advance
the clock hands. Holding the button down will
cause the clock to advance faster. Release the
button before reaching the desired time.
3. Push and release the button to increase the time
by one minute increments until the desired time is
reached.
3-39

Automatic Operation
AUTO9(Automatic Fan):When this position is
selected on the fan control, the system adjusts the
fan speed. If the OnStar
®system is activated when
this position is selected, the climate control fan speed
will lower.
AUTO (Automatic Mode):
1. Turn the fan control to the AUTO position.
2. Turn the mode control to the AUTO position.
3. Adjust the temperature to a comfortable setting
between 68°F (21°C) and 78°F (26°C).
Choosing the coldest or warmest temperature
setting will not cause the system to heat or cool
any faster. In cold weather, the system will start at
reduced fan speeds to avoid blowing cold air into
the vehicle until warmer air is available. The system
starts out blowing air at the oor but may change
modes automatically as the vehicle warms up to
maintain the chosen temperature setting. The length
of time needed to warm the interior depends on the
outside temperature and temperature of the vehicle.
4. Wait 20 to 30 minutes for the system to stabilize
in order for the system to regulate automatically.
Then adjust the temperature as necessary to
nd your comfort setting.Do not cover the solar sensor located in the center of
the instrument panel near the windshield. For more
information on the solar sensor, see “Sensors” later
in this section.
After the vehicle is started, the display shows the
interior temperature settings and the outside
temperature.
If the AUTO position is selected on the fan or mode
control, the system automatically controls the air
conditioning compressor. The A/C compressor will
run automatically even at cool outside temperatures
in order to dehumidify the air. The A/C indicator light
is lit when the system is operating automatically, even
at near freezing outside temperatures. Press
#on the
fan control to turn off the A/C. For improved window
clearing performance in defog or defrost modes, the
A/C compressor runs automatically.
h(AUTO RECIRCULATION):If the AUTO position is
selected on either the fan or mode control, the system
automatically controls the air inlet to supply fresh outside
air or recirculate the interior air to cool the car faster.
The light on the recirculation button will come on when
the system changes to recirculation. Outside air can be
forced by pressing
hwhen the light is lit. For vehicles
without rear climate controls, press
:to force outside
air. The next time AUTO fan or mode is selected, the air
inlet will reset back to AUTO operation.
3-41

Manual Operation
9(Off):Turns the entire climate control system off.
Outside air still enters the vehicle and is directed to
the oor. The airow direction and temperature can
be adjusted, as indicated below.
If the temperature is adjusted while the system is off,
the display will light to show the current settings.
wx(Driver’s Temperature Controls):Press the
up or down buttons next to the fan control to manually
increase or decrease the temperature inside the vehicle.
wx(Passenger’s Temperature Controls):
Press the up or down buttons next to the air delivery
mode control to manually increase or decrease the
temperature for the front passenger. If the passenger
climate control system is off, pressing one of these
buttons turns it on.
9(Fan Control):Turn clockwise or counterclockwise
to increase or decrease the fan speed. Turning this
control completely counterclockwise will turn on the
automatic fan operation. If the airow seems low
when the fan speed is at the highest setting, the
passenger compartment air lter may need to be
replaced. SeePassenger Compartment Air Filter
on page 3-48.Air Delivery Mode Control:Turn clockwise or
counterclockwise to change the current airow mode.
Select one of the following:
AUTO:Turns on the automatic delivery mode operation.
F(Vent):Air is directed to the instrument panel
outlets.
*(Bi-Level):Air is divided between the instrument
panel and the oor outlets. In automatic operation,
cooler air is directed to the upper outlets and warmer
air to the oor outlets.
7(Floor):Air is directed to the oor outlets with some
air directed to the side window outlets and the windshield.
If recirculation is selected, it only stays on for
three minutes to reduce windshield fogging.
W(Floor/Defog):This mode clears the windows of fog
or moisture. Air is directed to the oor outlets, with some
air going to the side window outlets and windshield.
When selected, the system turns off recirculation and
runs the air conditioning compressor unless the outside
temperature is at or below freezing. The recirculation
mode cannot be selected while in the oor/defog mode.
3-42

Rear Window Defogger
The rear window defogger uses a warming grid to
remove fog or frost from the rear window.
<(Rear Defogger):Press to turn the rear window
defogger on or off. Be sure to clear as much snow from
the rear window as possible. The rear window defogger
will turn off approximately 20 minutes after the button is
pressed if the vehicle is moving at slower vehicle speeds.
At higher vehicle speeds, the rear defogger may stay on
continuously. Each additional press will run the defogger
for approximately 10 minutes.
The heated outside rearview mirrors will turn on to help
clear fog or frost from the surface of the mirror when
the rear window defogger is on.
Notice:Do not use a razor blade or sharp object
to clear the inside rear window. Do not adhere
anything to the defogger grid lines in the rear glass.
These actions may damage the rear defogger.
Repairs would not be covered by your warranty.
Sensors
The solar sensor, located in the defrost grille, middle
of the instrument panel, monitors the solar radiation.
Do not cover the solar sensor or the system will not
work properly.
3-44

Instrument Panel Cluster
The instrument panel cluster is designed to show how the vehicle is running. It show how fast the vehicle is going,
how much fuel has been used and many of the other things needed drive safely and economically.
United States version shown, Canada similar
3-51

Safety Belt Reminders
Safety Belt Reminder Light
When the engine is started, a chime sounds for
several seconds to remind a driver to fasten the safety
belt, unless the driver safety belt is already buckled.
The safety belt light
comes on and stays on
for several seconds, then
ashes for several more.
This chime and light are repeated if the driver remains
unbuckled and the vehicle is in motion. If the driver
safety belt is already buckled, neither the chime nor
the light comes on.
Passenger Safety Belt Reminder Light
Several seconds after the engine is started, a
chime sounds for several seconds to remind the front
passenger to buckle their safety belt. This only occurs
if the passenger airbag is enabled. SeePassenger
Sensing System on page 1-64for more information.
The passenger safety belt light, located on the instrument
panel, comes on and stays on for several seconds and
then ashes for several more.
This chime and light are
repeated if the passenger
remains unbuckled and
the vehicle is in motion.
If the passenger safety belt is buckled, neither the
chime nor the light comes on.
The front passenger safety belt warning light and
chime may turn on if an object is put on the seat such
as a briefcase, handbag, grocery bag, laptop or other
electronic device. To turn off the warning light and or
chime, remove the object from the seat or buckle the
safety belt.
3-53

Here are a few situations that may occur with the fuel
gage. All of these situations are normal and do not
indicate that anything is wrong with the fuel gage:
At the gas station the gas pump shuts off before the
gage reads full.
The gage may change when the vehicle is turning,
stops quickly or accelerates quickly.
It takes a little more or less fuel to ll the tank
than the gage indicated. For example, the gage
may have indicated that the tank was half full,
but it actually took a little more or less than half
the tank’s capacity to ll the tank.
Driver Information Center (DIC)
The Driver Information Center (DIC) gives you the status
of many of your vehicle’s systems. The DIC is also used
to display warning/status messages. All messages will
appear in the DIC display located at the bottom of the
instrument panel cluster, below the tachometer and
speedometer. The DIC buttons are located on the
instrument panel, to the left of the steering wheel.
The DIC comes on when the ignition is on. After a short
delay, the DIC will display the information that was
last displayed before the engine was turned off.
The top line of the DIC display shows the vehicle
system information and the warning/status messages.
The bottom line of the DIC display shows the odometer
on the left side. The bottom line of the DIC display
also shows a digital speedometer on the right side.
If a problem is detected, a warning message will appear
on the display. Be sure to take any message that
appears on the display seriously and remember that
clearing the message will only make the message
disappear, not correct the problem.
3-67

DIC Operation and Displays
The Driver Information
Center (DIC) has different
displays which can be
accessed by pressing the
DIC buttons located on
the instrument panel, to the
left of the steering wheel.
3Trip/Fuel:Press this button to scroll through the
trip and fuel displays. See “Trip/Fuel Display Menu Items”
following for more information on these displays.
TVehicle Information:Press this button to scroll
through the vehicle information displays. See “Vehicle
Information Display Menu Items” following for more
information on these displays.
UCustomization:Press this button to scroll through
each of the customization features. SeeDIC Vehicle
Customization on page 3-86for more information on
the customization features.
VSet/Reset:Press this button to reset certain DIC
features and to acknowledge DIC warning messages
and clear them from the DIC display.
yzMenu Up/Down:Press this button to scroll up
and down the menu items.
Trip/Fuel Display Menu Items
3
(Trip/Fuel):The following display menu items can
be displayed by pressing the trip/fuel button:
TRIP A or TRIP B
These displays show the current distance traveled since
the last reset for each trip odometer in either miles (mi)
or kilometers (km). Both odometers can be used at the
same time. Each trip odometer can be reset to zero
separately by pressing and holding the set/reset button
for a few seconds while the desired trip odometer is
displayed.
3-68
