2009 BMW 135I Owner's Manual

Reference
At a glance
Controls
Driving tips
Mobility
143

Reference
This chapter contains technical data and an
index that will help you find information most
quickly.
Reference

Technical data
146
Technical data
Engine data
128i135i
Displacement cu in/cmμ182.8/2,996 181.8/2,979
Number of cylinders 6 6
Maximum power output hp 230 300
at engine speed rpm 6,500 5,800
Maximum torque lb ft/Nm 200/270 300/407
at engine speed rpm 2,750 1,400 - 5,000

Reference
At a glance
Controls
Driving tips
Mobility
147
Dimensions
Coupe
All dimensions given in inches/mm.
Smallest turning circle dia.: 35 ft 1 in/10.7 m.

Technical data
148
Convertible
All dimensions given in inches/mm.
Smallest turning circle dia.: 35 ft 1 in/10.7 m.

Reference
At a glance
Controls
Driving tips
Mobility
149
Weights
Coupe
Convertible
128i135i
Approved gross weight
>with manual transmission lbs/kg 4,134/1,875 4,255/1,930
>with automatic transmission lbs/kg 4,211/1,910 4,266/1,935
Load lbs/kg 794/360 794/360
Approved front axle load lbs/kg 2,028/920 2,116/960
Approved rear axle load
>with manual transmission lbs/kg 2,249/1,020 2,249/1,020
>with automatic transmission lbs/kg 2,393/1,040 2,393/1,040
Approved roof load capacity lbs/kg 165/75 165/75
Cargo bay capacity cu ft/liters 13.1/370 13.1/370
128i135i
Approved gross weight
>with manual transmission lbs/kg 4,398/1,995 4,564/2,070
>with automatic transmission lbs/kg 4,475/2,030 4,575/2,075
Load lbs/kg 772/350 772/350
Approved front axle load lbs/kg 2,050/930 2,149/975
Approved rear axle load lbs/kg 2,467/1,119 2,469/1,120
Approved roof load capacity lbs/kg – –
Cargo bay capacity cu ft/liters 9.1 - 10.7/260 - 305 9.1 - 10.7/260 - 305

Technical data
150
Capacities
Notes
Fuel tank: US gal/liters approx. 14.0/53 Fuel grade: page105
including reserve of US gal/liters approx. 2.1/8.0
Window washer system For more details: page53
including headlamp washers US qt/liters approx. 6.3/6.0
