If the AFS indicator comes on and
starts blinking while driving, pull to
the side of the road when it is saf e,
andturnoff theengine.If theAFS
indicator keeps blinking, or starts
blinking again while driving af ter
turning the ignition switch to the ON
(II) position, the AFS is not working
properly (see page ). Have the
AFS inspected by your dealer.
When the AFS indicator comes on,
you will also see a ‘‘CHECK
ADAPTIVE FRONT LIGHTING
SYSTEM’’ message on the multi-
inf ormation display (see page ).
Without AFS, your vehicle still has
normal lighting ability to continue
driving.
The adaptive f ront lighting system
(AFS) helps to improve visibility
during nighttime driving. The AFS
controls the aiming direction and
lighting distribution of the low
beams according to the amount of
turn applied to the steering wheel
during cornering or turning. Press
the AFS OFF switch to turn the AFS
on and off when the ignition switch
is in the ON (II) position and the
headlights are turned on.
69
78
If equippedAFS Indicator
A daptive Front L ighting System (A FS)
144
2009 RL

Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Acura-approved key blanks.Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The keys do not contain batteries.
Do not try to take them apart.
The built-in key (see page ) f its
all the locks on your vehicle. These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
180
Keys and Locks
150
KEY NUMBER TAG
BUILT-IN KEYS
2009 RL

As required by the FCC:This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on f or
a f ew seconds, then go out. If the
indicator starts to blink, it means the
system does not recognize the
coding of the Honda smart key or
built-in key. Turn the ignition switch
to the LOCK (0) position, release the
ignition switch and push it, or
remove the built-in key, and reinsert
it.ThenturntheswitchtotheON
(II) position again. The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
f ob) is near the ignition switch when
you turn the ignition switch to the
ON (II) position.
If the system repeatedly does not
recognize the coding of your remote
or built-in key, contact your dealer.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.
If you have lost your remote or
built-in key and cannot start the
engine, contact your dealer.
The immobilizer system protects
your vehicle f rom thef t. If an
improperly-coded key (or other
device) is used, the engine will not
start.
Immobilizer System
Inst rument s and Cont rols
151
Always take the keyless access remote
and built-in key with you whenever you
leave the vehicle alone.
2009 RL

µ
µ
µ µ
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the ignition switch.
To use the built-in key, you have to
remove the cover (see page ). This is the normal
ignition switch position when driving.
Several of the indicators on the
instrument panel come on as a test
when you turn the ignition switch
f rom the ACCESSORY (I) to the ON
(II) position.
If the f ront wheels are turned, the
anti-thef t lock may make it dif f icult
to turn the ignition switch. Firmly
turn the steering wheel to the left or
right as you turn the ignition switch.
You can insert or
remove the built-in key only in this
position. To turn the ignition switch
to the LOCK (0) position, the shift
lever must be in Park, and you must
push the knob or built-in key in slightly.
TheshiftlevermustbeinPark
bef ore you turn the ignition switch
knob to the LOCK (0) position or
remove the built-in key from the
ignition switch.
You can
operate the audio system and the
accessory power sockets in this
position.
When you turn the ignition switch to
the ACCESSORY (I) position, an
‘‘ACCESSORY (I) POSITION’’
message is shown on the multi-
inf ormation display. If you open the driver’s door and
leave the key in the ignition switch,
you will hear a reminder beeper, and
a message appears on the multi-
inf ormation display according to the
ignition switch position. When the
ignition switch is in the ACC (I)
position, a ‘‘RETURN IGNITION
SWITCH TO LOCK (0) POSITION’’
message is shown on the multi-
inf ormation display. When the
ignition switch is in the LOCK (0)
position, a ‘‘REMOVE KEY’’
message is shown on the multi-
inf ormation display.
180 ST A RT (III)
ON (II)
LOCK (0) A CCESSORY (I)
Ignition Switch
152
IGNITION SWITCH
COVER BUILT-IN KEY
2009 RL

Your vehicle has a keyless access
system. When you carry the remote
with you, you can lock/unlock the
door(s), unlock the trunk, and start
the engine without using the built-in
key.
The system may not work if:Thebatteryof theremoteisweak.
You carry a cell phone, a laptop
computer, or other electrical
device near the remote.
There is strong electrical current
nearby.
The remote is covered by metal.
A vehicle is being operated with a
transmitter nearby.
When the remote battery is dead. Protect the remote and the built-in
key f rom direct sunlight, high
temperature, and high humidity.
Always keep the remote and the
built-in key away from any magnetic
material.
Youshouldhavereceivedakey
number tag with your built-in key.
You will need this key number if you
ever have to get a lost key replaced.
Use only Acura-approved key blanks.
When the vehicle battery is dead.
Make sure the driver always carries
the remote/built-in key set. Do not drop the remote or the
built-in key, and do not set heavy
objects on them.
The built-in keys do not contain
batteries.
Keep the remote and the built-in key
away f rom liquids. If they get wet,
dry them immediately with a sof t
cloth.
K eyless A ccess System
166
2009 RL

This remote is used to lock/unlockthe doors and unlock the trunk.
When you carry the remote, you can
lock/unlock the doors, unlock the
trunk, and start the engine without a
key.
You can lock/unlock the doors
within about a 32 inch (about 80 cm)
radius f rom the outside door handle.
The f ollowing keys come with your
vehicle. Refer to page for how to
separate the keys.
This key is used to lock/unlock the
doors, glove box, trunk pass-through
cover, and to start the engine (af ter
you remove the ignition switch cover,
see page ). You can open the trunk within about
a 32 inch (about 80 cm) radius f rom
thetrunkreleaseswitch.Anyone can lock/unlock a door or
open the trunk if the remote is
within the operating range of the
door or the trunk.
Theremotemaynotworkif:
It is too close to the vehicle.
It is above or below the vehicle,
even when it is within its operating
range.
180
177
Keys
Built -in K ey
K eyless A ccess Remot e
K eyless A ccess System
Inst rument s and Cont rols
167
BUILT-IN KEYS OPERATING
RANGE
KEYLESS ACCESS
REMOTES
KEY NUMBER TAG
2009 RL

The engine may not run, and some
malf unctions may occur, if the
remote is:The engine may not start if the
remote is subjected to strong radio
waves.
Also, the engine may not start if the
remote is too close to the windows.
Outside the vehicle.
On the dashboard.
On the rear interior panel.
In the glove box.
In the door pockets.
In the trunk, etc.
Ignition Switch Operating Range
K eyless A ccess System
Inst rument s and Cont rols
175
Make sure you know where the remote
is when you are inside the vehicle.
Remember that you can start the engine
without using the built-in key when the
remote is inside the vehicle.
Make sure you always carry the remote
with you.
2009 RL

When you are pressing the ignition
switch, or when the ignition switch is
in the ON (II) position, the beeper
sounds if you take the remote out of
the vehicle and close the door.
To remove the ignition switch cover,
insert the built-in key (see page ),
then pull the cover out by pulling the
built-in key while pushing it.
Also, if you close the door when the
ignition switch is not in the LOCK
(0) position and the remote is not
inside the vehicle, the keyless access
alarm sounds outside the vehicle, a
message appears on the multi-
inf ormation display, and the beeper
sounds if the ignition switch is in the
ON (II) position.
When the beeper sounds af ter you
close the driver’s door outside the
vehicle, check the position of the
ignition switch and the location of
the remote.
If the engine is running and you
removetheremotefromthevehicle,
it will continue to run. But once
turned to the LOCK (0) position, the
engine will not restart until a remote
is brought back into the vehicle.
180
CONT INUED
Beeper and Message
Removing the Ignition Switch
Cover
K eyless Remot e Not Det ect ed
K eyless A ccess System
Inst rument s and Cont rols
177
BUILT-IN KEY
IGNITION SWITCH COVER
pushpull
