ERGONOMICS and COMFORT
3
69
Seats
REAR SIDE SEATS
Forwards/backwards adjustment
Lift bar A a n d s l i d e t h e s e a t f o r w a r d s
o r b a c k w a r d s . Handling the side seat
Adjusting the angle of the seat back
Push lever B u p w a r d s a n d a d j u s t t h e
a n g l e a s r e q u i r e d .
Release the lever to lock. Access to row 3
1. P l a c e t h e h e a d r e s t r a i n t i n t h e l o w
position.
2. Push lever B u p w a r d s a s f a r a s
possible.
Exit from row 3
1. P l a c e t h e h e a d r e s t r a i n t i n t h e l o w
position.
2. Pull control C .
3. G u i d e t h e t i l t i n g o f t h e s e a t b a c k
f o r w a r d s u n t i l t h e r e a r a n c h o r a g e s
a r e u n l o c k e d . I f y o u e x p e r i e n c e a n y
d i f fi c u l t y , u s e t h e r e d e m e r g e n c y
control to unlock the anchorages.
4. P l a c e t h e s e a t i n t h e v e r t i c a l c l o s e d
position.
F o l l o w i n g e a c h e n t r y o r e x i t ,
r e p o s i t i o n t h e r a i s e d s e a t g u i d i n g
it until the rear anchorages lock in
their rails.
3. F o l d t h e s e a t b a c k o n t o t h e s e a t
c u s h i o n a n d g u i d e t h e t i l t i n g o f t h e
s e a t b a c k f o r w a r d s u n t i l t h e r e a r
a n c h o r a g e s a r e u n l o c k e d . I f y o u
e x p e r i e n c e a n y d i f fi c u l t y , u s e t h e
emergency control to unlock the
anchorages.
4. P l a c e t h e s e a t i n t h e v e r t i c a l c l o s e d
position.
ERGONOMICS and COMFORT
3
7 3
Seats
REAR BENCH SEAT
F r o m t h e b o o t , y o u c a n p u l l
on strap B a n d s l i d e t h e s e a t
f o r w a r d s t o m a k e i t e a s i e r t o l o a d
the vehicle.
The rear bench seat must only be
fi t t e d i n r o w 3 . Seat back folded position
1. P l a c e t h e h e a d r e s t r a i n t s i n t h e l o w
position .
2. Pull the strap C u p w a r d s , f r o m t h e
tailgate.
3. Tilt the seat back on the seat
cushion .
Vertical position of the bench seat
1. P l a c e t h e h e a d r e s t r a i n t s i n t h e l o w
position.
2. Pull the strap C u p w a r d s , f r o m t h e
tailgate.
3. F o l d t h e s e a t b a c k o n t o t h e s e a t
cushion
4. Pull the lever D to unlock the rear
anchorages.
5. Place the seat in the vertical
" f o l d e d " p o s i t i o n .
W h e n d r i v i n g , a t t a c h t h e r e t a i n i n g
s t r a p s t o t h e h a n d l e s .
Forwards/backwards
adjustment
F r o m t h e s e a t c u s h i o n , l i f t b a r A a n d
s l i d e t h e s e a t t o w a r d s t h e f r o n t o r t h e
rear.
