2009.5. PEUGEOT 3008 gearbox

143
CRUISE CONTROL
System which automatically maintains
the speed of the vehicle at the value
programmed by the driver, without any
action on the accelerator pedal.
The cruise control is switched on
manually: it requires a minimum vehicle
speed of 25 mph (40 km/h) and the en-
gaging:
- of fourth gear on the manual gear- box,
- of second gear on the piloted manual gearbox or automatic gearbox, in se-
quential driving mode,
- of position A on the piloted manual
gearbox or D on the automatic gear-
box. The controls of this system are grouped
together on lever
A .

1. Cruise control mode selection dial

2. Speed programming/programmed
value decrease button

3. Speed programming/programmed
value increase button

4. Cruise control off/resume button The programmed information is grouped
together on the instrument panel display.

5. Cruise control off/resume indication

6.
Cruise control mode selection indication

7. Programmed speed value
Steering wheel controls Displays on the instrument panel
The cruise control cannot, in
any circumstances, replace
the need to respect speed lim-
its, nor can it replace the need for vigi-
lance and responsibility on the part of
the driver.
The cruise control is
switched off
manually or by pressing the brake or
clutch pedal or on triggering of the ESP
system for safety reasons.
It is possible to exceed the programmed
speed temporarily by pressing the ac-
celerator pedal.
To return to the programmed speed,
simply release the accelerator pedal.
Switching off the ignition cancels any
programmed speed value. This information is also dis-
played on the head up display.
For further details about the head up
display, refer to this "Driving" section.

145
6-SPEED MANUAL GEARBOX
As a safety precaution and to
facilitate starting of the engine:
- always select neutral,
- press the clutch pedal. Only engage reverse gear
when the vehicle is stationary
with the engine at idle.
Engaging reverse gear

 Raise the ring under the knob and
push the gear lever to the left then
forwards.
* According to engine.
GEAR CHANGE INDICATOR *
System which reduces fuel consump-
tion by advising the driver to change up
a gear on vehicles fi tted with a manual
gearbox.
Operation
The system acts solely in the context of
economical driving.
Depending on the driving situation and
your vehicle's equipment, the system
may advise you to skip one or more
gears. You can follow this instruc-
tion without engaging the intermediate
gears.
The gear engagement recommenda-
tions must not be considered compulsory.
In fact, the confi guration of the road, the
amount of traffi c and safety remain de-
termining factors when choosing the best
gear. Therefore, the driver remains re-
sponsible for deciding whether or not to
follow the advice given by the system.
This function cannot be deactivated. Example:
- You are in third gear.
In the case of driving which
makes particular demands on the
performance of the engine (fi rm
pressure on the accelerator pedal, for
example, when overtaking...), the sys-
tem will not recommend a gear change.
The system never suggests:
- engaging of fi rst gear,
- engaging of reverse gear,
- engaging of a lower gear. - You press the accelerator pedal
moderately.
- The system may suggest that you engage a higher gear, if appropriate.
The information appears in the form of
an arrow on the instrument panel dis-
play.
Depending on your vehicle's equipment,
this arrow may be accompanied by the
recommended gear.
This equipment will become available
during the year.

146
6-SPEED PILOTED MANUAL GEARBOX Gear lever

R. Reverse

 With your foot on the brake, move the
lever upwards to select this position.

N. Neutral.

 With your foot on the brake, select
this position to start.

A. Automatic mode.

 Move the lever downwards to select
this mode.

M. +/- Sequential mode with manual
changing of the gears.

 Move the lever downwards then to
the left to select this mode, then:
- push the lever forwards to change up a gear,
- or pull the lever rearwards to change down a gear.

S. Sport function.

 Press this button to activate or de-
activate this function.
+. Change up control to the right of the
steering wheel.

 Press the back of the "+" steering
wheel control to change up a gear.

-. Change down control to the left of
the steering wheel.

 Press the back of the "-" steering
wheel control to change down a
gear.
The steering wheel controls
do not permit the selection of
neutral or the engaging or di-
sengaging of reverse gear.
Six-speed piloted manual gearbox
which offers a choice between the com-
fort of fully automatic operation or the
pleasure of manual gear changing.
Therefore, three driving modes are of-
fered:
- the
automatic mode for automatic
control of the gears by the gearbox,
- the sequential mode for manual
changing of the gears by the driver,
- the auto sequential mode to over-
take, for example, remaining in auto-
matic mode while using the functions
of the sequential mode.
A Sport function is available in auto-
matic or sequential mode for a more dy-
namic style of driving.

147
Displays on the instrument panel
Gear lever positions

N. Neutral

R. Reverse

1, 2, 3, 4, 5, 6. Gears in sequential mode

AUTO. This comes on when the au-
tomatic mode is selected. It
switches off on changing to se-
quential mode.

S. Sport (Sport function)

 Place your foot on the
brake when this warning
light fl ashes (e.g.: when
starting the engine).
 Select position N .

 Press the brake pedal down fully.

 Start the engine.

 Select fi rst gear (position M or A ) or
reverse (position R ).

 Release the handbrake unless it is
programmed to automatic mode.

 Take your foot off the brake pedal,
then accelerate.

AUTO and 1 or R appear on
the instrument panel display.

N fl ashes on the instrument
panel, accompanied by an au-
dible signal and a message on
the multifunction display, if the gear
lever is not in position N on starting.

Foot on brake fl ashes on the instru-
ment panel, accompanied by an au-
dible signal and a message on the
multifunction display, if the brake
pedal is not pressed on starting.
An audible signal is heard when
reverse gear is engaged.
N appears on the instrument
panel display.
Sequential mode

 When the vehicle has moved off, se-
lect position M to change to sequen-
tial mode.

AUTO disappears and the
gears engaged appear in suc-
cession on the instrument
panel display.
The gear change requests are only car-
ried out if the engine speed permits.
It is not necessary to release the acce-
lerator during gear changes.
When braking or slowing down, the
gearbox changes down automatically to
permit reacceleration of the vehicle in
the correct gear.
At very low speed, if reverse
gear is requested, this will only
be taken into account when
the vehicle is immobilised. The Foot
on brake warning light may fl ash on
the instrument panel to prompt you
to brake.
At high speed, if reverse gear is re-
quested, the N indicator light will
fl ash and the gearbox will change to
neutral automatically. To engage a
gear again, return the lever to posi-
tion A or M .

148
The gearbox is then operating in auto-
active mode, without any action on the
part of the driver. It continuously selects
the most suitable gear in relation to the
following parameters:
- style of driving,
- profi le of the road.
AUTO and the gear engaged
appear on the instrument pan-
el display.
Automatic mode

 Following use of the sequential
mode, select position A to return to
the automatic mode.
"Auto sequential mode"
This mode enables you to overtake, for
example, remaining in automatic mode
while using the functions of the sequen-
tial mode.

 Activate steering wheel control posi-
tion + or - .
The gearbox engages the gear re-
quested if the engine speed permits.

AUTO is still displayed on the instru-
ment panel.
After a few moments without any action
on the controls, the gearbox resumes
automatic control of the gears.
On sharp acceleration, the
gearbox will not change up un-
less the driver acts on the gear
lever or the steering wheel controls.
Never select neutral N while the vehi-
cle is moving.
Only engage reverse gear R when
the vehicle is immobilised with the
brake pedal pressed.
For optimum acceleration, for
example when overtaking an-
other vehicle, press the acce-
lerator pedal fi rmly past the point of
resistance.

149
Stopping the vehicle Operating fault
With the ignition on, if this
warning light comes on and

AUTO fl ashes, accompanied
by an audible signal and a
message on the multifunction
display, this indicates a malfunction of
the gearbox.
Have it checked by a PEUGEOT dealer.
It is essential to press the
brake pedal when starting the
engine.
When parking, is it essential to apply
the handbrake to immobilise the ve-
hicle, whatever the circumstances.
When immobilising the vehi-
cle, with the engine running, it
is essential to place the gear
lever in neutral N .
Before carrying out any work in the
engine compartment, check that the
gear lever is in neutral N and that
the handbrake is applied.
Sport function

 Following selection of the sequential
mode or automatic mode, press but-
ton S to activate the Sport function
which offers you a more dynamic
style of driving.

S appears next to the gear en-
gaged on the instrument panel
display.

 Press button S again to deactivate
the function.

S is then cleared from the instrument
panel display.
The gearbox returns to normal
mode automatically each time
the ignition is switched off. Before switching off the engine, you can
choose to:
- move to position
N to engage neutral,
- leave the gear engaged; in this case, it will not be possible to move
the vehicle.
In both cases, it is essential that you
apply the handbrake to immobilise the
vehicle.

150
"PORSCHE TIPTRONIC SYSTEM" AUTOMATIC GEARBOX
Six speed automatic gearbox which of-
fers a choice between the comfort of
fully automatic operation, enhanced by
sport and snow programmes, or manual
gear changing.
Therefore, four driving modes are of-
fered:
- automatic operation for electronic
management of the gears by the
gearbox,
- sport programme for a more dy-
namic style of driving,
- snow programme to improve driv-
ing when traction is poor,
- manual operation for sequential
changing of the gears by the driver.
Gear lever

P. Park.
- Immobilisation of the vehicle, hand- brake on or off.
- Starting the engine.

R. Reverse.
- Reversing manoeuvres, vehicle sta- tionary, engine at idle.

N. Neutral.
- Immobilisation of the vehicle, hand- brake on.
- Starting the engine.

D. Automatic operation.

M.+/- Manual operation with sequential
changing of the six gears.

 Press forwards to change up through
the gears.
or

 Press rearwards to change down
through the gears.
Displays on the instrument panel
When you move the lever in the gate
to select a position, the corresponding
indicator light is displayed on the instru-
ment panel.

P. Park

R. Reverse

N. Neutral

D. Drive (Automatic driving)

S. Sport programme

 . Snow programme

1 to 6. Gear engaged during manual
operation

-. Invalid value during manual operation
Gear selection gate

1. Gear lever.

2. Button "S" (sport) .

3. Button "  " (snow) .

151
Moving off

 With your foot on the brake, select
position P or N .

 Start the engine.
If this procedure is not followed, an au-
dible signal is heard, accompanied by a
message on the multifunction display.

 With the engine running, press the
brake pedal.

 Release the handbrake, unless it is
programmed to automatic mode.

 Select position R , D or M ,

 Gradually release the brake pedal.
The vehicle moves off immediately.
If position N is engaged inad-
vertently while driving, allow the
engine to return to idle then en-
gage position D to accelerate. The gearbox then operates in auto-
adaptive mode, without any intervention
on the part of the driver. It continuously
selects the most suitable gear according
to the style of driving, the profi le of the
road and the load in the vehicle.
For maximum acceleration without
touching the lever, press the accelera-
tor pedal down fully (kick down). The
gearbox changes down automatically
or maintains the gear selected until the
maximum engine speed is reached.
On braking, the gearbox changes down
automatically to provide effi cient engine
braking.
If you release the accelerator sharply,
the gearbox will not change to a higher
gear for safety reasons.
 Select position D for automatic
changing of the six gears.

 appears on the instrument
panel.
Snow programme "
 "

 Press button "  ", after starting the
engine.
The gearbox adapts to driving on slip-
pery roads.
This programme improves starting and
drive when traction is poor.
S appears on the instrument
panel.
Sport programme "S"

 Press button "S" , after starting the
engine.
The gearbox automatically favours a
dynamic style of driving.
Never select position N while
the vehicle is moving.
Never select positions P or R unless
the vehicle is completely stationary.
When the engine is running at
idle, with the brakes released,
if position
R , D or M is select-
ed, the vehicle moves even without
the accelerator being pressed.
When the engine is running, never
leave children in the vehicle without
supervision.
When carrying out maintenance with
the engine running, apply the hand-
brake and select position P .
Sport and snow programmes
These two special programmes supple-
ment the automatic operation in very
specifi c conditions of use.
Return to automatic operation

 At any time, press the button se-
lected again to quit the programme
engaged and return to auto-adaptive
mode.
