2009.5 Citroen DS3 boot

33Instruments and controls
Warning lampis onCauseAction/Obser vations
Engine oil
pressure
fixed. There is a fault with the engine
lubrication system.
Stop as soon it is safe to do so.
Park, switch off the ignition and contact a CITROËN dealer.
Batter y charge fixed. The battery charging circuit has a fault (dir ty or loose terminals, slack or cut alternator belt, ...).
This lamp should switch off when the engine is star t ed. If it does not switch off, contact a CITROËN dealer.
Door(s) open
fixed if the speed is below 6 mph (10 km/h).
A door or the boot is still open. Close the door or boot. fixed and accompanied by an audible signal if the speed is above
6 mph (10 km/h).

Monochrome screen A
This displays the following information: - time, - date, - ambient temperature (this flashes if there is a risk of ice), - status of the doors and boot, - audio sources (radio, CD...), - trip computer (refer to the "Instruments and Controls" section). Warning messages (e.g.: "Emission control
system faulty") or information messages (e.g.: "Boot open") may appear temporarily. These can be cleared by pressing the "ESC" button.
Displays on the screen
From the control panel of your Audio system, you can:  press the "MENU" button to gain access to the main menu ,  press the "  " or "  " buttons to scroll through the items on the screen,  press the "MODE" button to change the permanent application (date, audio source...),  press the "  " or "  " buttons to change a setting value,  press the "OK" button to confirm, or  press the "ESC" button to abandon the operation in progress.
Controls
 Press the "MENU" button to gain access to the main menu , then press the "  " or "  " buttons to scroll through the various menus: - radio- CD, - vehicle configuration, - options, - display settings, - languages, - units.  Press the "OK" button to select the menu required.
Main menu

49Multifunction screens
Monochrome screen C
This displays the following information: - time, - date, - ambient temperature (this flashes if there is a risk of ice), - status of doors and boot, - audio sources (radio, CD, USB por t, jack socket etc.), - trip computer (refer to the "Instruments and controls" section). Warning messages (E.g. "Emisions control system faulty") or information messages (E.g.: Automatic headlamps active") may appear temporarily. These can be cleared by pressing the "ESC" button.
Displays on the screen
From your Audio system control panel, you can:  press the "MENU" button to gain access to the main menu ,  press the "  " or "  " buttons to scroll through the items on the screen,  press the "MODE" button to change the permanent application (trip computer, audio source...),  press the "  " or "  " buttons to change a setting value,
 press the "OK" button to confirm, or  press the "ESC" button to abandon the operation in progress.
Controls
 Press the "MENU" button to gain access to the main menu : - audio functions, - the trip computer, - personalisation-configuration, - telephone (hands-free kit).  Press the "  " or "  " buttons to select the menu required, then confirm by pressing the "OK" button.
Main menu

59Comfort
Recommendations for ventilation and air co nditioning
If after an extended stop in sunshine, the interior temperature is very high, first ventilate the passenger compar tment for a few moments.
Put the air flow control at a setting high enough to quickly change the air in the passenger compar tment. The air conditioning system does not contain chlorine and does not present any danger to the ozone layer.
In order for these systems to be fully effective, follow the operation and maintenance guidelines below:  To obtain an even air distribution, take care not to obstruct the exterior air intake grilles located at the base of the windscreen, the nozzles, the vents and the air outlets, as well as the air extractor located in the boot.  Do not cover the sunshine sensor, located on the d ashboard; this is used for regulation of the air conditioning system.  Operate the air conditioning system for at least 5 to 10 minutes, once or twice a month to keep it in per fect working order.  Ensure that the passenger compar tment filter is in g ood condition and have the filter elements replaced regularly (refer to the "Checks" secti on). We recommend the use of a combined passenger compa r tment filter. Thanks to its special active additive, it contributes to the purification of the air breathed by the occupants and the cleanliness of the passenger compar t ment (reduction of allergic symptoms, bad odours and greasy deposits).  To guarantee correct operation of the air conditioning system, you are also advised to have it checked regularly as recommended in the Maint enance and Warranty Guide.
 If the system does not produce cold air, deactivate it and contact a CITROËN dealer. When towing the maximum load on a steep gradient in high temperatures, switching off the air conditioning increases the available engine power and so improves the towing ability.
The condensation created by the air conditioning results in a discharge of water under the vehicle which is per fectly normal.

81Access
Locking the vehicle
Locking using the remote control Locking using the key
 Turn the key to the left in the driver’s door lock to lock the vehicle completely. Locking is confirmed by fixed lighting of the direction indicators for approximately two seconds. According to version, the door mirrors fold at the same time.
 Press the closed padlock to lock the vehicle.
If one of the doors or the boot is still open, the central locking does not take place. When the vehicle is locked, if it is unlocked inadver tently, it will relock automatically after thir ty seconds unless a door or the boot is open.
The folding and unfolding of the door
mirrors using the remote control can be deactivated by a CITROËN dealer.

87Access
Alarm
System which protects and provides a deterrent agains t the theft of your vehicle. It provides two types of protection, exterior and interior, as well as a self-protection function.
Exterior perimeter protection
The system detects opening of the vehicle. The alarm is triggered if anyone tries to enter the vehicle by forcing a door, the boot or the bonnet.
Interior volumetric protection
The system detects any variation in the volume in the passenger compar tment. The alarm is triggered if anyone breaks a window or moves inside the vehicle. If you wish to leave a pet in the vehicle or a window par tially open, deactivate the interior volumetric protection.
Self-protection function
The system detects the putting out of ser vice of its components. The alarm is triggered if anyone tries to put the wires of the siren, the central control or the battery out of ser vice.
Do not make any modifications to the alarm system, this could cause malfunctions.

To be effective, this deactivation must be carried out each time the ignition is switched off.
Locking the vehicle with full
alarm
Activation
 Switch off the ignition and get out of the vehicle.
 Lock or deadlock the vehicle using the locking button on the remote control.
The alarm is activated; the indicator lamp on button A flashes once per second. The exterior perimeter protection is activated, 5 seconds after the locking button on the remote control is pressed. The interior volumetric protection is activated, 45 seconds after the locking button on the remote control is pressed.
Deactivation
 Unlock the vehicle using the unlocking button on the remote control. The alarm is deactivated; the indicator lamp on button A switches off.
Locking the vehicle with exterior
perimeter protection only
Deactivation of the interior volumetric protection
 Switch off the ignition.  Within ten seconds, press button A until the indicator lamp is lit continuously.  Get out of the vehicle.  Lock or deadlock the vehicle without delay using the locking button on the remote control. The exterior perimeter protection alone remains activated; the indicator lamp on button Aflashes once per second.
Reactivation of the interior volumetric protection
 Unlock the vehicle using the unlocking button on the remote control.  Relock the vehicle using the remote control. The alarm is activated again with both types of protection; the indicator lamp on button A
flashes once per second.
If an opening - door or boot - is not closed fully, the vehicle is not locked, but the exterior perimeter protection will be activated after 45 seconds at the same time as the interior volumetric protection.

89Access
Triggering of the alarm
This is indicated by sounding of the siren and flashing of the direction indicators for approximately thir ty seconds. After it has been triggered, both types of protection are again operational.
If the alarm is triggered ten times in succession, the eleventh time will result in it becoming inactive. If the indicator lamp on button A flashes rapidly, this indicates that the alarm was triggered during your absence. When the ignition is switched on, this flashing stops immediately. To avoid triggering the alarm when washing your vehicle, lock it using the
key in the driver’s door lock.
Failure of the remote control
 Unlock the vehicle using the key in the driver’s door lock.  Open the door; the alarm is triggered.
 Switch on the ignition; the alarm stops.
Locking the vehicle without
activating the alarm
 Lock or deadlock the vehicle using the key in the driver’s door lock.
Malfunction
When the ignition is switched on, lighting of the indicator lamp on button A for ten seconds indicates a siren fault. Have it checked by a CITROËN dealer.
* According to country.
Automatic activation *
2 minutes after the last door or the boot is closed, the alarm is activated automatically.  To avoid triggering the alarm on entering the vehicle, first press the unlocking button on the remote control.
