2008 VOLKSWAGEN CC light

Indicator lights

WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
Whenever stalled or stopped for repair, move the vehicle a
safe distance off the road, stop the engine, turn on the emer-
gency flashers, and use other warning devices to warn ap-
proaching traffic.
Never park the vehicle in areas where the hot catalytic con-
verter and exhaust system can come into contact with dry
grass, brush, spilled fuel, oil, or other material that can catch
fire.
A broken down vehicle presents a high accident risk for itself
and others. Switch on emergency flashers and set up a warning
triangle to warn oncoming traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
High Intensity Discharge (HID) headlights provide bright, uniform
lighting to help you see and be seen. The light comes from an electric
arc between two electrodes in the gas-filled bulb. Over time, the elec-
trodes can wear down and the gap between them will get wider. The
HID lamp’s control unit then increases the voltage to keep the arc’s
brightness constant. However, the commonly called “Xenon” bulbs
will also ultimately burn out. Before they burn out, HID lamps can
flicker. A message will then appear in the MFI. This is your reminder
to see an authorized Volkswagen dealer or an authorized
Volkswagen Service facility to check the headlights.

mation System. If your vehicle is not equipped with the Lights & Vi-
sion menu, the convenience turn signal feature can be deactivated
by an authorized Volkswagen dealer or authorized Volkswagen Ser-
vice Facility.
WARNING
Improper use of high beams can distract and blind others,
causing accidents and serious injuries.
The turn signal light works only when the ignition is switched on.
The emergency flasher works even when the ignition is switched off
⇒  In an emergency.
The indicator light flashes twice as fast if a turn signal bulb is
burned out.
High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 86 Headlight switch next to the steering wheel. A: Vehicles with
fog lights. B: Vehicles without fog lights.

Symbol When the ignition is
switched off
When the ignition is
switched on
/ Fog lights and low beams
switched off.
Headlights off, daytime run-
ning lights (DRL) on.
!54/ Orientation lighting may be
switched on.
Automatic headlight control
active; DRL on.
 Low beams switched off.
The DRL may stay on. The
length of time they stay on
depends on the vehicle
battery charge.
Low beams switched on.
Fog lights switched off.
The DRL may stay on for
some time.
Headlights and fog lights
switched on.

Fog lights
The indicator light in the headlight switch or the instrument cluster
shows that the fog lights are switched on.
To switch on the fog lights : first turn the light switch to
position , then pull the light switch out to the first detent.
To switch off the fog lights, push the switch back in from the first
detent. To then turn off the headlights, turn the switch to position /.
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the
key out of the ignition and open the driver door. This is to remind you
that lights are still on.
Light switch in position  if the vehicle has no orientation lighting
⇒  Coming home and Leaving home feature (orientation lighting).

WARNING
Daytime running lights are not bright enough to let you see
ahead or be seen by others when it is dark.
Always switch on the low-beam headlights at dusk or when it
is dark and whenever the weather is bad or visibility is poor.
Never use the daytime running lights to see where you are
going. They are not bright enough and will not let you see far
enough ahead for safety, especially at dusk or when it is dark.
Always switch on the low-beam headlights at dusk or when it is
dark.
The taillights do not come on with the daytime running lights.
Unless the taillights are on, a vehicle cannot be seen by others
in bad weather, at dusk, or when it is dark.
Even if automatic headlight control (!54/) is switched on, the
low-beam headlights may still not come on by themselves in
fog or heavy rain. You have to switch on the low-beam head-
lights manually.
In cool or humid weather, the insides of the headlights, the rear
lights, and turn signals can temporarily fog up. This is normal and
does not affect the service life of the vehicle's lighting system.
Lights and vision features

If the light switch is in position !54/, a low-light sensor switches the
low beams as well as the instrument and switch lighting on and off
automatically.
Daytime running lights (DRL) parking feature
Some models are equipped with a daytime running lights (DRL) park-
ing feature that switches the daytime running lights off when the vehi-
cle is parked and the ignition is switched on.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the /
position.
– Set the parking brake.
Switching the DRL back on: – Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on
some models are also static cornering lights. On some models the
static cornering lights may be integrated in the headlights. At speeds
below about 25 mph (40 km/h), the light on one side of the vehicle will
come on automatically when you turn a corner. If you turn to the right,
the right fog light comes on; turn left and the left fog light comes on.
The light dims and goes out when the steering wheel is straightened
out again.
When you move the selector lever to Reverse (R), the static cornering
lights on both sides of the vehicle may come on so that you can see
the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If
you are using automatic headlight control (headlight switch in the !54/
position ⇒ fig. 86), they work only when the headlights have been
automatically switched on. The static cornering lights do not come on
when the headlight switch is in the / position or when the fog lights
themselves have been switched on ⇒ Switching lights on and off.

Automatic headlight control (!54/)
Automatic headlight control is a convenience feature only and cannot
always recognize all lighting and driving situations.
If the light switch is in the !54/ position, both vehicle lighting and in-
strument and switch lighting are automatically switched on and off in
the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers
darkness, for example when driv-
ing through a tunnel.
If sufficient brightness is regis-
tered.
If the rain sensor recognizes rain
and switches the windshield wip-
ers on.
If the windshield wipers have not
moved for several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams
switched on and only at speeds above about 6 mph (10 km/h). The
swivel-mounted lamps automatically improve road illumination during
cornering.
On vehicles equipped with the Adaptive Front Lighting System, the
feature is switched on and off via the Assistants menu in the instru-
ment cluster display ⇒ Volkswagen Information System.

WARNING
Crashes and other accidents can happen when you cannot see
the road ahead and when you cannot be seen by other motor-
ists.
Never use daytime running lights (DRL) to see where you are
going. DRL are not bright enough to light up the roadway and
be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark.
Always switch on the low-beam headlights at dusk or when it is
dark.
The taillights do not come on when the daytime running
lights are switched on. A vehicle without taillights on cannot be
seen by others in bad weather, at dusk, or when it is dark.
If automatic headlight control (!54/) is switched on, the low-
beam headlights still may not be switched on in fog or heavy
rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, the rear
lights, and turn signals can temporarily fog up. This is normal and
does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation
lighting)
