2008 VOLKSWAGEN CC load capacity

WARNING
Exceeding maximum permissible weight ratings can result in
vehicle damage, accidents, and serious personal injury.
Never let the actual weights at the front and rear axles exceed
the permissible Gross Axle Weight Rating. Also, never let the
total of these actual weights exceed the Gross Vehicle Weight
Rating.
Always remember that the vehicle's handling and braking will
be affected by extra load and the distribution of this load. Ad-
just your speed accordingly.
NOTICE
Always distribute the load evenly and as low as possible in the
vehicle. The vehicle capacity weight figures apply when the load
is distributed evenly in the vehicle (passengers and luggage).
When transporting a heavy load in the luggage compartment,
carry the load as close to the rear axle (as far forward) as possi-
ble so that the vehicle's handling and braking are affected as
little as possible.

WARNING
Transporting heavy objects causes the handling characteristics
of the vehicle to change and increases braking distances.
Heavy loads which are not properly stowed or secured in the
vehicle can lead to a loss of vehicle control and cause serious
personal injury.
Transporting heavy items causes the handling characteris-
tics of the vehicle to change by shifting the vehicle's center of
gravity.
Always distribute luggage evenly and as low as possible
within the vehicle. The vehicle capacity weight figures apply
when the load is distributed evenly in the vehicle (passengers
and luggage).
Always stow luggage and heavy items in the luggage com-
partment as far forward of the rear axle as possible and secure
them with appropriate straps to the tie-downs provided.
Never exceed the vehicle's Gross Vehicle Weight Rating or
Gross Axle Weight Ratings, which are printed on the Safety
Compliance Certification Label located on the door jamb of the
driver door. Exceeding the permissible weight can cause the
vehicle to skid and behave differently.
Always adapt your speed and driving style to accommodate
your payload and its weight distribution within your vehicle.
Be especially cautious and gentle when stepping on the ac-
celerator pedal and avoid sudden braking and other maneu-
vers.
Brake earlier than you would if you were not driving a loaded
vehicle.
NOTICE
The defroster heating wires or antenna in the rear window can
be damaged by objects that rub against them.
The ventilation slots between the rear window and the shelf be-
hind the rear seat backrest must not be blocked so that stale air can
escape from the vehicle.

Maximum permissible roof load
The maximum permissible roof load is 220 lbs. (100 kg). The roof
load is the combined weight of the roof rack and the items being car-
ried on the roof ⇒ .
Be sure you know the weight of the roof rack and the items you want
to transport on the roof. Weigh them if necessary. Never carry a total
of more than the maximum permissible roof load.
When using a roof rack with a lower load limit, do not load the rack to
the maximum weight mentioned above. In this case, you may only
load the roof rack to the weight limit specified in the system's installa-
tion instructions.
Distributing the load
Distribute the load evenly and secure it properly ⇒ .
Checking the mountings
After the base carrier and rook rack have been installed, check all
bolts and fasteners after driving a short time and at regular intervals
thereafter.
WARNING
If the maximum permissible roof load is exceeded, accidents
and substantial vehicle damage may occur.
Never exceed the specified roof load, the maximum Gross
Axle Weight Rating, or the Gross Vehicle Weight Rating.
Do not exceed the loading capacity of the roof rack, even if
the permissible roof load is not fully utilized.
Always make sure that loads are evenly distributed and that
heavier items are, as far as possible, toward the front.
WARNING
Loose or improperly secured items can fall off the roof rack and
cause accidents and injuries.
Always use suitable, undamaged tie-down ropes and ratchet
straps.
Secure the load properly.

miles (kilometers) at low speeds in the 3 hour period before the tire
pressure is measured or adjusted.
Curb weight
The weight of a motor vehicle with standard equipment including the
maximum capacity of fuel, oil, and coolant, air conditioner, and addi-
tional weight of optional equipment.
Extra load tire
A tire designed to operate at higher loads and at higher inflation pres-
sures than the corresponding standard tire.
Gross Axle Weight Rating (GAWR)
The load-carrying capacity of a single axle system, measured where
the tire contacts the ground.
Gross Vehicle Weight Rating (GVWR)
The maximum loaded weight of the vehicle.
Groove
The space between 2 adjacent tread ribs.
Load rating (code)
The maximum load that a tire is rated to carry for a given inflation
pressure. You may not find this information on all tires because it is
not required by law.
Maximum load rating
The load rating for a tire at the maximum permissible inflation pres-
sure for that tire.
Maximum loaded vehicle weight
The total of:
Curb weight.
Accessory weight.
Vehicle capacity weight.
Production options weight.
Maximum (permissible) inflation pressure
The maximum cold inflation pressure to which a tire may be inflated.
Also called “maximum inflation pressure.”

Normal occupant weight
Means 150 lbs (68 kilograms) times the number of occupants seated
in the vehicle up to the total seating capacity of your vehicle.
Occupant distribution
The placement of passengers in a vehicle.
Outer diameter
The diameter of a new, properly inflated tire.
Overall width
Total width measured at the exterior sidewalls of an inflated tire, in-
cluding the additional width of labeling, decorations, or protective
bands or ribs.
Passenger car tire
A tire intended for use on passenger cars, multipurpose passenger
vehicles, and trucks, that have a gross vehicle weight rating (GVWR)
of 10,000 pounds or less.
Ply
A layer of rubber-coated parallel cords.
Ply separation
A parting of rubber compound between adjacent plies.
Pneumatic tire
A mechanical device made of rubber, chemicals, fabric, and steel or
other materials, that, when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid that sustains the load.
Production options weight
The combined weight of installed regular production options weighing
over 5 lbs (2.3 kg) more than the standard items they replace, and not
previously considered as curb weight or accessory weight. These
include, for example, heavy-duty brakes, ride levelers, roof rack,
heavy-duty battery, and special trim.
Radial ply tires
A pneumatic tire in which the ply cords that extend to the beads are
laid at substantially 90 degrees to the centerline of the tread.

was manufactured. The last 4 numbers represent the week and year
of manufacture.
For example, the numbers 1709 mean that the tire was produced in
the 17th week of 2009. Any other numbers are marketing codes used
by the tire manufacturer. This information is used to help identify af-
fected consumers if a tire defect requires a recall.
Vehicle capacity weight
The total rated cargo, luggage and passenger load. Passenger load is
150 lbs (68 kilograms) times the vehicle's total seating capacity (as
listed on the label inside the driver door).
Vehicle maximum load on the tire
The load on an individual tire that is determined by taking each axle's
share of the maximum loaded vehicle weight (GAWR) and dividing
by 2.
Vehicle normal load on the tire
The load on an individual tire that is determined by taking each axle's
share of the curb weight, accessory weight, and normal occupant
weight (distributed according to the table below) and dividing by 2.
Wheel size designation
Wheel rim diameter and width.
Occupant loading and distribution for vehicle normal load for
various designated seating capacities

Designated seating
capacity, number of
occupants
Vehicle normal load,
number of occu-
pants
Occupant distribu-
tion in a normally
loaded vehicle
2, 3, or 4 2 2 in front
5 3 2 in front, 1 in back

Tires and vehicle load limits

There are limits to the load any vehicle or any tire can carry. A vehicle
that is overloaded will not handle well and is more difficult to stop.
Overloading can damage important parts of the vehicle. Overloading
can also lead to blowout, sudden loss of pressure or other tire failure
that can cause loss of control.
Your safety and the safety of your passengers depends on making
sure that load limits are not exceeded. Vehicle load includes every-
body and everything in and on the vehicle. These load limits are
technically referred to as the vehicle's Gross Vehicle Weight Rating
(GVWR).
The GVWR includes the weight of the basic vehicle, all factory-
installed and other accessories, a full tank of fuel, oil, coolant and
other fluids plus maximum load. The maximum load includes the
number of passengers that the vehicle is intended to carry (seating
capacity) with an assumed weight of 150 lbs (68 kg) for each passen-
ger at a designated seating position and the total weight of any lug-
gage in the vehicle. If you tow a trailer, the weight of the trailer hitch
and the tongue weight of the loaded trailer must be included as part
of the vehicle weight. At altitudes above 3000 ft (1000 m), combined
towing weight (vehicle plus trailer) must be reduced by 10% for every
3000 ft (1000 m).
The Gross Axle Weight Rating (GAWR) is the maximum load that
can be carried at each of the vehicle's 2 axles (by the front or rear
tires). GVWR and GAWR are listed on the safety compliance label on
the driver door jamb. Because there is an upper limit to your vehicle's
total weight (GVWR), the weight of whatever is being carried (includ-
ing the weight of a trailer hitch and the tongue weight of the loaded
trailer) is also limited. More passengers, or passengers who are heav-
ier than the assumed 150 lbs (68 kg), mean that less weight can be
carried as luggage or other cargo. The tire pressure label on your
Volkswagen also lists the maximum combined weight of all of the oc-
cupants and luggage or other cargo that the vehicle can carry.

Steps for Determining Correct Load Limit:
4. The resulting figure equals the available amount of cargo and
luggage load capacity.
For example, if the “XXX” amount equals 1400 lbs. and there
will be five 150 lb. passengers in your vehicle, the amount of
available cargo and luggage load capacity is 650 lbs. (1400-
750 (5 x 150) = 650 lbs.)
5. Determine the combined weight of luggage and cargo being
loaded on the vehicle. That weight may not safely exceed the
available cargo and luggage load capacity calculated in Step 4.
6. If your vehicle will be towing a trailer, load from your trailer will
be transferred to your vehicle. Consult this Manual to determine
how this reduces the available cargo and luggage capacity of
your vehicle.
Check the tire sidewall to determine the load index specified for
the tire.

UTQG classification
