2008 VOLKSWAGEN CC check engine

Flashes
Temperature
gauge
needle
⇒ fig. 167
Possible
cause Proper response
(B)
Normal range
Engine coolant
level too low.
Check the engine coolant
level after the engine has
cooled down and add en-
gine coolant if low.
If the engine coolant level
is correct or the problem
continues after adding
coolant, do not drive any
farther. Contact an au-
thorized Volkswagen deal-
er or authorized
Volkswagen Service Facili-
ty.
These instructions apply
only when the coolant
temperature stays in the
normal range. Stop imme-
diately if the needle goes
into the red warning zone
(C).
–
Engine coolant
system
malfunction.

When the ignition is switched on, several warning and indicator lights
come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text mes-
sages can cause the vehicle to break down in traffic and result
in a collision and serious personal injury.
Never ignore warning lights or text WARNINGS.
Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in
vehicle damage.
Engine coolant specifications

Checking engine coolant level and topping off

Fig. 168 Coolant expansion tank in the engine compartment.

Fig. 169 Coolant expansion tank cap in the engine compartment.

Checking engine coolant level
When the engine is cold, check the engine coolant level relative to
the marking on the side of the expansion tank ⇒ fig. 168.
If the coolant level in the tank is below the minimum mark (“min”),
add coolant. When the engine is warm, the engine coolant level may
be slightly above the upper edge of the marked range.
Adding engine coolant
Always protect face, hands and arms from hot escaping coolant or
steam by covering the cap with a large, thick rag.
Carefully unscrew the cap ⇒ .
Add only new engine coolant according to Volkswagen specifica-
tions (⇒ Engine coolant specifications) ⇒ .
The engine coolant level must be inside the marks on the side of
the reservoir ⇒ fig. 168. Do not fill above the top edge of the filling
range! ⇒ 
Screw the lid tightly.
Even in an emergency, do not use any other kind of coolant addi-
tive if engine coolant meeting Volkswagen specifications (⇒ page 456,
Engine coolant specifications) is unavailable! Instead, add distilled
water only ⇒ . As soon as possible, have the correct coolant ratio
restored using engine coolant that meets Volkswagen specifications
⇒  Engine coolant specifications.

failure. If you have added non-distilled water, take the vehicle
immediately to an authorized Volkswagen dealer or an author-
ized Volkswagen Service Facility to have the coolant system
drained, flushed, and refilled completely with the proper coolant.
Refill engine coolant only up to the top edge of the marked fill
range ⇒ fig. 168. Excess engine coolant may be forced out of the
engine cooling system when it gets hot and cause damage.
In the case of significant engine coolant loss, refill engine
coolant only when the engine is completely cooled down. Signif-
icant engine coolant loss is a sign of leaks in the cooling sys-
tem. Have the engine cooling system checked immediately by an
authorized Volkswagen dealer or an authorized Volkswagen Ser-
vice Facility. Otherwise the engine may be damaged!
When changing or topping off operating fluids, make sure that
you pour the fluids into the correct reservoirs. Serious malfunc-
tions and engine damage can result if you pour operating fluids
into the wrong reservoir.

Checking the vehicle battery electrolyte level

Fig. 170 In the engine compartment: On vehicles with a 2.0 liter en-
gine, the vehicle battery is in the engine compartment.

Fig. 171 In the luggage compartment: On vehicles with a 3.6 liter en-
gine, the vehicle battery is on the left side of the luggage compart-
ment.

Vehicles with 3.6 liter engines: Open the luggage compartment lid
⇒  Luggage compartment lid.
Opening the battery cover
Depending on the engine type, there are different kinds of battery
covers:
Vehicles with 2.0 liter engines: Press on the clip in direction of the
arrow ⇒ fig. 170 (1) and remove the cover upward.
Vehicles with 3.6 liter engines: Remove the trim panel to access
the vehicle battery ⇒ fig. 171.
Checking the vehicle battery acid level
If the lighting conditions are poor, use a flashlight so that you can
clearly see the battery acid level indicator and tell what color it is.
Never use an open flame or an unprotected light source.
The round battery window (“acid level indicator”) on the top of the
battery changes color, depending on the battery's electrolyte level.

Color Action
Light yellow
or colorless
Battery electrolyte level is too low.
The vehicle battery may need to be
replaced. Have it checked by an
authorized Volkswagen dealer or an
authorized Volkswagen Service Fa-
cility.
Black Battery electrolyte level is satisfacto-
ry.

Practical tips
Frequently asked questions (FAQ)
If you suspect a malfunction or vehicle damage, read and follow the
following advice before contacting an authorized Volkswagen dealer
or an authorized Volkswagen Service Facility. You may also find help-
ful information under “Special considerations” or “Checklist” in the
index.

Description Possible causes,
among others Possible remedy
Engine does not
start.
Vehicle battery dead. – Perform jump-start
– Charge vehicle battery
The wrong vehicle
key is used. Use a valid vehicle key
Fuel level too low. Refuel
Vehicle cannot be
locked or un-
locked using ve-
hicle key.
– Battery in the re-
mote control vehicle
key is dead.
– Too far away from
the vehicle (out of
range).
– Buttons have been
pressed too many
times.
– Replace the battery in
the remote control vehicle
key
– Move closer to vehicle.
– Synchronize vehicle key
– Lock or unlock vehicle
manually
Unusual noises.
Cold engine, braking
assist systems, elec-
tronic steering col-
umn lock.
Check the “Noises” entry
in the index.
Odd driving
behavior.
Assistance systems
activated.
Check the “Assistance
systems” entry in the in-
dex.
