417
4−3. Do−it−yourself maintenance
4
Maintenance and care
Fuse layout and amperage ratings
n
Engine compartment
FuseAmpere Circuit
1 A/F15 A
A/F heater
2 HORN10 A
Horn
3 EFI MAIN25 A
EFI, A/F heater
4 IG2 MAIN30 A
Injector, ignition, meter
5 RR A/C50 A
No circuit
6 SEAT−A/C LH25 A
No circuit
7 RR S/HTR20 A
Rear seat heater
8 DEICER20 A
Windshield wiper de−icer
9 CDS FAN25 A
Condenser fan
10 TOW TAIL30 A
Towing tail
11 RR P/SEAT30 A
No circuit
12 ALT−CDS10 A
Alternator condenser
13 FR FOG15 A
Front fog lights
14 SECURITY5 A
Security horn
15 SEAT−A/C RH25 A
No circuit
419
4−3. Do−it−yourself maintenance
4
Maintenance and care
41 ECU−B25 ADriving position memory sys−
tem
42 TEL5 A
No circuit
43 RSE7.5 A
Rear seat entertainment
44 TOWING30 A
To w i n g
45 DOOR NO.225 A
Main body ECU
46 STR LOCK20 A
Steering lock system
47 TURN−HAZ15 AMeter, front turn signal lights,
rear turn signal lights, towing
converter
48 EFI MAIN220 A
Fuel pump
49 ETCS10 A
EFI
50 ALT−S5 A
IC−ALT
51 AMP30 A
Audio system
52 RAD NO.110 ANavigation system, radio
receiver assembly
53 ECU−B15 Asmart key system, overhead
module, tilt and telescopic
steering, meter, cool box, gate−
way ECU, steering sensor
54 DOME15 A
Door courtesy lights, clock
55 HEAD LH15 A
Headlight high beam (left)
56 HEAD LL15 A
Headlight low beam (left)
57 INJ10 A
Injector, ignition
58 MET5 A
Meter
59 IGN10 ACircuit open, SRS airbag sys−
tem, gateway ECU, occupant
detection system, smart key
system, ABS, VSC, steering
lock system, GBS
60 HEAD RH15 A
Headlight high beam (right)
FuseAmpereCircuit
