2008 TOYOTA CAMRY 5w-30

321
4-3. Do-it-yourself maintenance
4
Maintenance and care
Install the filler cap, turning it clockwise.
The approximate quantity of oil needed to raise the level between low and
full on the dipstick is indicated as follows:
2.4 L 4-cylinder (2AZ-FE) engine
1.2 qt. (1.1 L, 1.0 lmp. qt.)
3.5 L V6 (2GR-FE) engine
1.6 qt. (1.5 L, 1.3 lmp. qt.)
■ Recommended viscosity
2.4 L 4-cylinder (2AZ-FE) engine
5W-20 or 0W-20
*1: SAE 5W-20 or 0W-20 motor oilmay be used. However, SAE
0W-20 is the best choice for
fuel economy, and good start-
ing in cold weather.
3.5 L V6 (2GR-FE) engine
SAE 5W-30 is the best choice for
good fuel economy, and good
starting in cold weather.
*2: If SAE 5W-30 oil is not avail-able, SAE 10W-30 oil may be
used. However, it should be
replaced with SAE 5W-30 at
the next oil change.
STEP3
Outside temperature
*1
*2
Outside temperature

432 6-1. Specifications
*1: 0W-20 is the oil that provides the optimal level of fuel efficiency.
*
2: 5W-30 is the oil that provides the optimal level of fuel efficiency.
Oil viscosity
● The 5W portion of the oil viscosity rating indicates the characteristic
of the oil which allows cold startab ility. Oils with a lower value before
the W allow for easier starting of the engine in cold weather.
● The 30 in 5W-30 indicates the oil viscosity when the oil is at its oper-
ating temperature. An oil with a higher viscosity may be better suited
if the vehicle is operated at high speeds, or under extreme load con-
ditions.

476
GAS STATION INFORMATION
Auxiliary catch leverP. 313Trunk openerP. 4 6Fuel filler door P. 7 3
Hood lock release lever
P. 3 1 3
Fuel filler door opener P. 7 3Tire inflation pressure
P. 436
Fuel tank capacity 18.5 gal. (70 L, 15.4 lmp.gal.)
Fuel type Unleaded gasoline only P. 74, 430
Cold tire inflation pressure P. 436
Engine oil
capacity
(Drain and refill)
2.4 L 4-cyl-
inder (2AZ-
FE) engineqt. (L, lmp.qt)
With filter 4.5 (4.3, 3.8)
Without filter 4.3 (4.1, 3.6)
3.5 L V6
(2GR-FE)
engine With filter 6.4 (6.1, 5.4)
Without filter 6.0 (5.7, 5.0)
Engine oil type Toyota Genuine Motor Oil or equivalent
Oil grade: ILSAC multigrade engine oil
P. 4 3 1
Recommended oil viscosity:
SAE 5W-20 or 0W-20 (2.4 L 4-cylinder
[2AZ-FE] engine) SAE 5W-30 (3.5 L V6
[2GR-FE] engine)
