2008 SUBARU TRIBECA turn signal

Fuses and circuits&Fuse panel located in the passenger compartment
Fuse
panel Fuse
rating Circuit
1 20A .Trailer hitch connector
2 Empty
3 15A .Door locking
4 7.5A .Front wiper deicer relay
. Moonroof
5 7.5A .Combination meter
6 7.5A .Remote control rear
view mirrors
. Seat heater relay
7 15A .Combination meter
. Integrated unit
8 15A .Stop light
9 20A .Mirror heater
. Front wiper deicer
10 7.5A .Power supply (Battery)
11 7.5A .Turn signal unit
12 15A .Automatic transmission
unit
. SRS airbag system
(Sub)
. Engine control unit
. Integrated unitSpecifications
12-5
–
CONTINUED –
ProCarManuals.com

12-8
Specifications
Bulb chartDescriptionWattageBulb No.
High beam headlight 12V-65WHB3
Low beam headlight
Vehicles with HID light 12V-35WD1S
Vehicles without HID light 12V-55WH7
Fog light 12V-55WH3
Front turn signal/Parking light 12V-28/8W
2357NA
Parking/Front side marker light 12V-5W
168(W5W)
Rear combination light Rear turn signal light 12V-27W1156(W27W)
Brake/tail 12V-27/8W1157(W27/8W)
Tail light 12V-5W
168
Back-up light 12V-16W
921
License plate light 12V-5W
168(W5W)
Cargo area light 12V-13W
912
Dome light Vehicles with Rear Seat Entertainment 12V-5W
–
Vehicles without Rear Seat Entertainment 12V-8W
–
Map light 12V-8W
–
Vanity mirror light 12V-3W
–
Door step light 12V-3W
–
Rear gate light 12V-5W
(W5W)
ProCarManuals.com

14-4
