2008 SATURN VUE lock

{CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol
and it will burn if the engine parts are hot
enough. Do not spill coolant on a hot engine.
1. You can remove the
coolant surge tank
pressure cap when
the cooling system,
including the coolant
surge tank pressure
cap and upper radiator
hose, is no longer hot.
Turn the pressure cap slowly counterclockwise
about one-quarter of a turn. If you hear a hiss, wait
for that to stop. This will allow any pressure still
left to be vented out the discharge hose.
2. Then keep turning the pressure cap slowly, and
remove it.3. Fill the coolant surge tank with the proper
DEX-COOL
®coolant mixture, to between the
MIN and MAX lines.
4. With the coolant surge tank pressure cap off, start
the engine and let it run until you can feel the upper
radiator hose getting hot. Watch out for the engine
cooling fan.
By this time, the coolant level inside the coolant
surge tank may be lower. If the level is lower, add
more of the proper DEX-COOL
®coolant mixture
to the coolant surge tank until the level reaches
between the MIN and MAX lines.
5. Then replace the pressure cap. Be sure the
pressure cap is hand-tight.
5-30
ProCarManuals.com

4. Open the hood on the other vehicle and locate the
positive (+) and negative (−) terminal locations on
that vehicle.
Open the hood on your vehicle and nd the remote
positive (+) and remote negative (−) jump starting
terminals.
The vehicle is equipped with a remote positive (+)
terminal. This is located in the engine compartment
on the driver’s side of the vehicle, on the underhood
fuse block. SeeEngine Compartment Overview on
page 5-12for more information on location.To uncover the remote positive (+) terminal, press
the tab on the bottom of the fuse block and lift
the cover up.
The remote negative (−) terminal is a stud on the
driver’s side near the underhood fuse block.
SeeEngine Compartment Overview on page 5-12.
Place the negative (-) jumper cable clamp on
the negative (−) terminal on top of the battery.
{CAUTION:
An electric fan can start up even when the
engine is not running and can injure you.
Keep hands, clothing and tools away from
any underhood electric fan.
5-38
ProCarManuals.com

7. Do not let the other end touch metal. Connect it to
the positive (+) terminal of the good battery. Use a
remote positive (+) terminal if the vehicle has one.
8. Now connect the black negative (−) cable to the
negative (−) terminal of the good battery. Use a
remote negative (−) terminal if the vehicle has one.
Do not let the other end touch anything until the
next step. The other end of the negative (−) cable
does not go to the dead battery. It goes to a heavy,
unpainted metal engine part or to a remote
negative (−) terminal on the vehicle with the
dead battery.
9. Connect the other end of the negative (−) cable
away from the dead battery, but not near engine
parts that move. The electrical connection is just
as good there, and the chance of sparks getting
back to the battery is much less.
10. Now start the vehicle with the good battery and run
the engine for a while.
11. Press the unlock symbol on the remote keyless
entry transmitter to disarm your security system,
if equipped.
12. Try to start the vehicle that had the dead battery.
If it will not start after a few tries, it probably needs
service.Notice:If the jumper cables are connected or
removed in the wrong order, electrical shorting may
occur and damage the vehicle. The repairs would
not be covered by your warranty. Always connect
and remove the jumper cables in the correct
order, making sure that the cables do not touch
each other or other metal.
A. Heavy, Unpainted Metal Engine Part or Remote
Negative (−) Terminal
B. Good Battery or Remote Positive (+) and Remote
Negative (−) Terminals
C. Dead Battery or Remote Positive (+) TerminalJumper Cable Removal
5-40
ProCarManuals.com

To disconnect the jumper cables from both vehicles, do
the following:
1. Disconnect the black negative (−) cable from the
vehicle that had the dead battery.
2. Disconnect the black negative (−) cable from the
vehicle with the good battery.
3. Disconnect the red positive (+) cable from the
vehicle with the good battery.
4. Disconnect the red positive (+) cable from the other
vehicle.
5. Return the underhood fuse block cover to its
original position, if applicable.
All-Wheel Drive
If you have an all-wheel-drive vehicle, be sure to
perform the lubricant checks described in this section.
Transfer Case
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it.
SeeScheduled Maintenance on page 6-3.
How to Check Lubricant
A. Fill Plug
B. Drain Plug
To get an accurate reading, the vehicle should be on a
level surface.
If the level is below the bottom of the ller plug hole,
located on the transfer case, you’ll need to add
some lubricant. Add enough lubricant to raise the
level to the bottom of the ller plug hole. A uid loss
could indicate a problem; check and have it repaired,
if needed.
5-41
ProCarManuals.com

7. Locate the vertical headlamp aiming screws, which
are under the hood near each headlamp assembly.
The adjustment screw can be turned with a 6 mm
socket.
8. Turn the vertical aiming screw until the headlamp
beam is aimed to the horizontal tape line. Turn it
clockwise or counterclockwise to raise or lower the
angle of the beam.9. Make sure that the light from the headlamp is
positioned at the bottom edge of the horizontal tape
line. The lamp on the left (A) shows the correct
headlamp aim. The lamp on the right (B) shows the
incorrect headlamp aim.
10. Repeat Steps 7 through 9 for the opposite
headlamp.
5-45
ProCarManuals.com

Bulb Replacement
For the proper type of replacement bulbs, see
Replacement Bulbs on page 5-49.
For any bulb changing procedure not listed in this
section, contact your dealer/retailer.
Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside
and can burst if you drop or scratch the bulb.
You or others could be injured. Be sure to
read and follow the instructions on the bulb
package.
Headlamps
To replace one of the headlamp bulbs, use the following
procedure. To replace the parking/turn signal lamp
bulb, seeFront Turn Signal and Parking Lamps
on page 5-47.
1. Open the hood. SeeHood Release on page 5-11
for more information.
2. Remove the two screws from the top of the front
fascia and grille. They are inboard of the headlamp
assembly.
3. Remove the three screws retaining the headlamp
assembly.
4. Insert a at blade tool through the opening in the
top. Make sure the tool ts through the opening in
the headlamp bracket lower arm.
5. Push the locking tab toward the rear of the vehicle
with the tool to lift the headlamp bracket lower arm.
6. Pull back on the front fascia and then pull the
headlamp assembly out from the vehicle. Another
person might be needed to assist with this step.
5-46
ProCarManuals.com

7. Disconnect the electrical connector from the bulb
assembly.
8. Turn the bulb assembly counterclockwise to remove
it from the housing.
9. Replace the old bulb with a new one.
10. Reverse Steps 1 through 8 to reinstall.
Front Turn Signal and Parking
Lamps
To replace a front turn signal or parking lamp bulb:
1. Follow Steps 1 through 6 underHeadlamps
on page 5-46to access the front turn signal
or parking lamp.
2. Turn the bulb to be replaced counterclockwise to
remove it from the headlamp assembly.
3. Pull the bulb out of the bulb socket assembly.
4. Push the new bulb into the bulb socket assembly.
5-47
ProCarManuals.com

5. Insert the bulb assembly into the headlamp
assembly.
6. Turn the bulb assembly clockwise until seated.
7. Reverse the steps to reinstall the headlamp
assembly.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
To replace one of these bulbs:
A. Taillamp/Stoplamp
B. Turn Signal Lamp
C. Back-up Lamp
1. Open the liftgate.2. Remove the two screws holding in the taillamp
assembly.
3. Slide the taillamp assembly rearward and away
from the vehicle.
4. Turn the bulb socket being replaced
counterclockwise to disconnect it.
5. Pull the bulb out of the bulb socket.
6. Push the new bulb into the bulb socket.
7. Reverse Steps 2 through 4 to reinstall the taillamp
assembly.
5-48
