Page 172 of 488
Rear Window Defogger
The rear window defogger uses a warming grid to
remove fog from the rear window.
<(Rear Window Defogger):Press this button on the
right knob to turn the rear window defogger on or off.
The rear window defogger stays on about 10 minutes
after the button is pressed, before turning off. The
defogger can also be turned off by pressing the button
again or by turning off the engine. Do not drive the
vehicle until all the windows are clear.
If your vehicle has heated outside rearview mirrors, the
mirrors heat to help clear fog or frost from the surface
of the mirror when the rear window defog button is
pressed.
Notice:Do not use anything sharp on the inside
of the rear window. If you do, you could cut or
damage the warming grid, and the repairs would not
be covered by the vehicle warranty. Do not attach
a temporary vehicle license, tape, a decal or
anything similar to the defogger grid.
Dual Automatic Climate Control
System
The heating, cooling, and ventilation in your vehicle can
be controlled with this system. Your vehicle also has
a ow-through ventilation system described later in this
section.
Different temperature settings can be selected for the
driver and all passengers.
3-26
ProCarManuals.com
Page 175 of 488
To avoid blowing cold air in cold weather, the system
delays turning on the fan until warm air is available.
The length of delay depends on the engine coolant
temperature. Press the fan switch to override this delay
and change the fan to a selected speed.
O(On/Off):Press this button to turn off the climate
control system. Outside air still enters the vehicle, and is
directed to the oor. This direction can be changed by
pressing the mode button. Recirculation can only
be selected in vent or bi-level mode. The temperature
can also be adjusted using either temperature button.
If you adjust the air delivery mode or temperature
settings with the system off, the display comes on brie y
to show the settings and then turns off. Press the
on/off button or the up down arrows on the fan switch,
the defrost button, AUTO button, or the air conditioning
button to turn the system on when it is off.
Manual Operation
The air delivery mode or fan speed can be manually
adjusted.
DC(Fan):The buttons with the fan symbols let you
manually adjust the fan speed. Press the up arrow
to increase fan speed and the down arrow to decrease
fan speed.
Pressing a fan button while the system is off will turn
the system on. Pressing a fan button while in automatic
control places the fan under manual control. The fan
setting remains displayed, the word AUTO is no longer
displayed, and the AUTO button indicator light turns
off. The air delivery mode remains in automatic control.
yNz(Mode):Press the mode up and down
buttons to manually change the direction of the air ow
in the vehicle. Repeatedly press the button until the
desired mode appears on the display. Pressing a mode
button while the system is off will change air delivery
mode without turning the system on. Pressing one
of these buttons while in automatic control to place the
mode under manual control.
3-29
ProCarManuals.com
Page 180 of 488
Outlet Adjustment
Use the slider switch in the center of the outlet, to
change the direction of the air ow. Use the thumbwheel
near the outlet to control the amount of air ow or to
shut off the air ow completely.
Keep all outlets open whenever possible for best
system performance.
Operation Tips
Clear away any ice, snow, or leaves from the air
inlets at the base of the windshield that can
block the ow of air into the vehicle.
Use of non-GM approved hood de ectors can
adversely affect the performance of the system.
Keep the path under all seats clear of objects to
help circulate the air inside the vehicle more
effectively.
If fogging reoccurs while in vent or bi-level modes
with mild temperature throughout the vehicle, turn
on the air conditioner to reduce windshield fogging.
Rear Air Conditioning and
Heating System
If your vehicle has this system, the rear controls are
three knobs located on the rear of the center console.
The system can be controlled from the front controls
as well as the rear controls.
To turn the system on, press the AUX button on the
front climate control system, an indicator will be
lit. Pressing the AUX button the rst time will turn the
rear system on in a mimic mode. In this mode, the
air ow in the rear will be approximately the same
direction, temperature, and fan speed as the front.
Pressing the AUX button again will turn the rear system
and the indicator off.
If the rear controls are adjusted, the system turns on in
a rear independent mode. Air ow in the rear will
then be directed according to the settings of the rear
controls. The rear system can be turned off by pressing
the AUX button on the front climate control system
and the indicator will turn off. The system can be turned
back on, by adjusting any of the rear air conditioning
control knobs.
3-34
