2008 PONTIAC SOLSTICE Owners Manual

Keys...............................................................2-2
Remote Keyless Entry (RKE) System................2-3
Remote Keyless Entry (RKE) System
Operation...................................................2-4
Doors and Locks.............................................2-7
Manual Door Locks.........................................2-7
Power Door Locks..........................................2-8
Delayed Locking.............................................2-8
Automatic Door Lock.......................................2-8
Automatic Door Unlock....................................2-8
Trunk............................................................2-9
Windows........................................................2-10
Manual Windows..........................................2-11
Power Windows............................................2-12
Sun Visors...................................................2-13
Theft-Deterrent Systems..................................2-13
Content Theft-Deterrent.................................2-13
PASS-Key
®III+............................................2-15
PASS-Key®III+ Operation..............................2-15
Starting and Operating Your Vehicle................2-17
New Vehicle Break-In....................................2-17
Ignition Positions..........................................2-17
Retained Accessory Power (RAP)...................2-20Starting the Engine (Key Access)....................2-20
Automatic Transmission Operation...................2-22
Manual Transmission Operation......................2-24
Parking Brake..............................................2-25
Shifting Into PARK (P)
(Automatic Transmission)............................2-26
Shifting Out of PARK (P)...............................2-28
Parking Your Vehicle (Manual Transmission).....2-28
Parking Over Things That Burn.......................2-29
Engine Exhaust............................................2-29
Running the Engine While Parked...................2-30
Mirrors...........................................................2-31
Manual Rearview Mirror.................................2-31
Manual Rearview Mirror with OnStar
®..............2-31
Outside Manual Mirror...................................2-31
Outside Power Mirrors...................................2-31
OnStar
®System.............................................2-32
Storage Areas................................................2-35
Glove Box...................................................2-35
Cupholder(s)................................................2-35
Center Console Storage.................................2-36
Convertible Top..............................................2-36
Section 2 Features and Controls
2-1

Keys
{CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons, children
or others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
The windows will function with the keys in the
ignition and they could be seriously injured
or killed if caught in the path of a closing
window. Do not leave the keys in a vehicle
with children.
The key can be used for the ignition and all locks.
2-2

Your vehicle has a vehicle theft-deterrent system.
The key has a transponder in the key head that is
electronically coded to match a decoder in your
vehicle that allows the key to start the vehicle. If a
replacement key or any additional key is needed,
you must purchase it from your dealer/retailer.
SeePASS-Key
®III+ Operation on page 2-15for
additional information.
The key has a bar-coded key tag that a dealer/retailer
or qualied locksmith can use to make new keys.
Store this information in a safe place, not in your vehicle.
Notice:If you ever lock your keys in your vehicle,
you may have to damage the vehicle to get in.
Be sure you have spare keys.
If you are locked out of your vehicle, contact
Roadside Assistance. SeeRoadside Assistance
Program on page 7-7.
Remote Keyless Entry (RKE)
System
Your Remote Keyless Entry (RKE) system operates on
a radio frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
2-3

At times you may notice a decrease in operating range.
This is normal for any RKE system. If the transmitter
does not work or if you have to stand closer to
your vehicle for the transmitter to work, try this:
Check the distance. You may be too far from your
vehicle. You may need to stand closer during
rainy or snowy weather.
Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the
left or right, hold the transmitter higher, and
try again.
Check to determine if battery replacement is
necessary. See “Battery Replacement” later
in this section.
If you are still having trouble, see your
dealer/retailer or a qualied technician for
service.
Remote Keyless Entry (RKE)
System Operation
The vehicle’s doors can
be locked and unlocked,
and the trunk can be
unlatched from about
3 feet (1 m) up to
60 feet (18 m) away
with the Remote Keyless
Entry (RKE) transmitter.
Q(Lock):Press the lock button to lock all the doors.
If enabled through the Driver Information Center (DIC),
the parking lamps may ash once and the horn may chirp
to indicate locking has occurred. See “LOCK HORN”
underDIC Vehicle Personalization on page 3-44.
2-4

"(Unlock):Press the unlock button one time to unlock
the driver’s door. Press the unlock button again within
ve seconds to unlock the other doors. The interior
lamps will come on and stay on for 20 seconds or until
the ignition is turned on. If enabled through the DIC,
the parking lamps will ash once to indicate unlocking
has occurred. See “UNLOCK HORN” underDIC
Vehicle Personalization on page 3-44.
V(Trunk Release):Press and hold this button for
approximately one second to release the trunk lid.
The trunk release will only work if the ignition is off
or the vehicle speed is less than 2 mph (3 km/h).
L(Vehicle Locator/Panic Alarm):Press and release
this button to help locate your vehicle. The horn will
sound three times and the hazard lamps will ash
three times. Press and hold the button for three seconds
to sound the panic alarm. The horn will sound and the
hazard lamps will ash for 30 seconds. The ignition
must be off for the vehicle locator/remote alarm to work.
Press the vehicle locator/panic alarm button again or
turn the ignition to ACC/ACCESSORY or ON/RUN
to turn off the alarm.The vehicle may have Remote Lock/Unlock
Conrmation. This feature provides feedback that
a command has been received by the vehicle.
The parking lamps will ash and the horn may sound
briey. See “LOCK HORN” and “UNLOCK HORN”
underDIC Vehicle Personalization on page 3-44
for programming information.
Matching Transmitter(s) to
Your Vehicle
Each RKE transmitter is uniquely coded to prevent
another transmitter from unlocking the vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer/retailer. Remember
to bring any additional transmitters so they can also
be re-coded to match the new transmitter. Once
your dealer/retailer has coded the new transmitter, the
lost transmitter cannot unlock the vehicle. The vehicle
can have a maximum of four transmitters coded to it.
2-5

Battery Replacement
Under normal use, the battery in the RKE transmitter
should last about four years.
If the battery is weak the transmitter will not work within
its normal range. It is probably time to change the
battery if you have to be very close to the vehicle
before the transmitter works.
Notice:When replacing the battery, use care not
to touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.
To replace the battery do the following:
1. Insert a at object with a thin edge into the notch,
located below the trunk release button, and pry the
front and back apart.
2. Remove the old battery, but do not use a metal
object to do this.
3. Slide the new battery into the transmitter with the
positive side of the battery facing up. Use a type
CR2032 battery, or equivalent type.
4. Snap the front and the back of the transmitter
together.
5. Test the operation of the transmitter with the vehicle.
2-6

Doors and Locks
Manual Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. You increase the chance
of being thrown out of the vehicle in a
crash if the doors are not locked. So, wear
safety belts properly and lock the doors
whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.There are a couple of ways to lock and unlock your
vehicle manually.
From inside the vehicle,
use the manual door lock
knob. Pull up or down
on the knob to unlock or
lock the door.
To lock either door from the outside, turn the key
toward the rear of the vehicle. To unlock the door,
turn the key toward the front of the vehicle.
2-7

Power Door Locks
You can use the Remote Keyless Entry (RKE)
transmitter to lock and unlock the doors from inside
or outside the vehicle. SeeRemote Keyless Entry (RKE)
System Operation on page 2-4for more information.
In vehicles with power door lock switches, the switches
are located on the doors.
T:Press the top of the switch to lock all doors.
Press the bottom of the switch to unlock all doors.
Delayed Locking
If your vehicle has power door locks, it will have the
delayed locking feature. This feature delays the actual
locking of the doors when the Remote Keyless
Entry (RKE) transmitter is used to lock the vehicle.
If any door is open when locking the vehicle using the
RKE transmitter, three chimes will sound signaling
that the delayed locking feature is active. Five seconds
after the last door is closed, both doors will lock and
the parking lamps will ash. To cancel the delay
and lock the doors immediately, press the lock button
on the RKE a second time.
If the key is in the ignition, this feature will not lock
the doors.
Automatic Door Lock
If your vehicle has power door locks, the doors will
automatically lock when the shift lever is moved out of
PARK (P) for a vehicle with an automatic transmission.
For a vehicle with a manual transmission, the speed
must be greater than 5 mph (8 km/h).
The automatic door locking feature cannot be disabled.
Automatic Door Unlock
If your vehicle has an automatic transmission and power
door locks, the doors with automatically unlock when
the shift lever is moved into PARK (P).
If your vehicle has a manual transmission and power
door locks, the doors will automatically unlock when
the key is removed from the ignition.
The automatic unlock feature can be disabled or
programmed in different ways if the vehicle has an
automatic transmission and a Driver Information
Center (DIC). SeeDIC Vehicle Personalization on
page 3-44for more information.
2-8
