AUDIO EQUIPMENT
34 -
EON system
This connects stations which are part
of the same network. It enables the
b r o a d c a s t o f t r a f i c i n f o r m a t i o n o r a
PTY programme, by a station that is
part of the same network as the sta-
tion to which you are listening.
This service is available when you
have selected the TA t r a f i c i n f o r m a -
tion programme or the PTY function.
Search by type of programme
(PTY)
This allows you to listen to stations broad-
c a s t i n g a s p e c i i c t y p e o f p r o g r a m m e
(news, culture, sport, rock, etc.).
To search for a
PTY programme :
With FM selected, press
the "TA" button for two
seconds to switch this
function on or off. - select the
PTY function,
- b r i e l y p r e s s b u t t o n L or N to
scroll down the list of the various
types of programmes offered,
- when the programme of your choice is displayed, keep button
L or N pressed for two seconds
to carry out an automatic search
(after an automatic search the
PTY function is switched off).
In PTY mode the different types
of programme can be stored in the
memory. To do this, press the prese-
lection buttons " 1" to " 6" for two
s e c o n d s . B r i e l y p r e s s t h e c o r r e -
sponding button to recall the type of
programme stored in the memory.
Page 34 of 123
35
AUDIO EQUIPMENT
-
Ejection of a disc Selecting a track
S h u f l e ( R D M )
When the CD player is selected,
press and hold button Q for two sec-
onds. The tracks will be played in
random sequence. Pressing the but-
ton again for two seconds returns
you to normal play.
S h u f l e m o d e i s d e - a c t i v a t e d e a c h
time the set is switched off.
COMPACT DISC
Press button L to select the next
track.
Press button N to return to the start
of the current track or to select the
previous track.
Accelerated play
Press and hold button L or N for for-
wards or backwards accelerated play.
Accelerated play stops as soon as
the button is released.
After insertion of a disc,
printed face upwards,
the player starts auto-
matically.
If a disc is already inserted, press
button Q.
Press button S to eject
the disc from the player.
The use of copied compact
discs may cause faults.
Insert circular compact discs
only.
Selecting CD mode
Page 35 of 123
AUDIO EQUIPMENT
36 -
RADIO RECEPTION
(AERIAL ADJUSTMENT)
Notes on radio reception. Your radio
will be subject to phenomena which
do not affect domestic radio sets.
Both MW/LW and FM reception are
subject to various forms of interfe-
r e n c e , w h i c h a r e n o r e l e c t i o n o n t h e
quality of your equipment but are due
to the nature of the signals and the
way in which they are transmitted.
On MW/LW, interference may be no-
ticed when passing underneath high
voltage power lines, under bridges or
in tunnels. On FM, interference may be the
result of increasing distance from the
t r a n s m i t t e r , d e l e c t i o n o f t h e s i g n a l
by obstacles (mountains, hills, buil-
dings, etc.), or of being in an area not
covered by a transmitter.
Saloon: recommended position for
the front aerial for best reception.
N o p a r t i c u l a r p o s i t i o n f o r t h e i x e d
rear aerial (preset aerial).
Page 36 of 123
37
AUDIO EQUIPMENT
-
206 AUDIO SYSTEM
Presentation
Y o u r 2 0 6 i s i t t e d w i t h a J B L a u d i o
s y s t e m , d e s i g n e d s p e c i i c a l l y f o r t h e
passenger compartment.
At the heart of the system, a
2 4 0 w a t t m u l t i f u n c t i o n a m p l i i e r
(1) (integrated in the subwoofer in
the boot) independently controls
8 h i g h a c o u s t i c d e i n i t i o n s p e a -
kers and the subwoofer. The speakers are situated:
- in the front door pillars : two
Tweeters (2) for reproduction of
the treble (high frequency) in the
front.
- in the front doors: two Woofers (3) for reproduction
of the bass (low frequencies)
in the front.
- in the rear doors: two Tweeters
(4) set into two Woofers
(5) , providing a balance of
frequencies in the rear.
- in the boot : a Subwoofer
(6) for reproduction of the
bass and ultra-bass (very
low frequencies) throughout
the whole of the passenger
compartment.
You will appreciate the clarity and
depth and notice that the sound
i l l s t h e w h o l e o f t h e v e h i c l e p e r -
fectly.
This system provides optimal re-
production and distribution of the
sound in the vehicle, both in the
front and the rear. Adjusting in CD or Radio mode
The basic functions remain those of
the audio set.
There is no need for any further ad-
justment. However, in order to take
f u l l a d v a n t a g e o f y o u r J B L a u d i o
system, you are advised to set the
AUDIO functions
(BASS, TREB,
FAD, BAL) to position "0" (zero), the
Loudness (LOUD) to the "ON" posi-
tion for CD mode and to the "OFF"
position for radio mode.
Page 108 of 123
1 0 1
PRACTICAL INFORMATION
-
Fuse N° Rating Functions
1 15A Heated seat - Alarm
4 2 0 AMultifunction display - Boot lighting - Audio equipment - Stee ring wheel controls - Trailer
5 15A Automatic gearbox diagnostics
6 1 0 A C o o l a n t l e v e l - A u t o m a t i c g e a r b o x - A u d i o e q u i p m e n t - S t e e r i n g w h e e l a n g l e s e n s o r ( E S P )
7 15A D r i v i n g s c h o o l a c c e s s o r y - A l a r m i t t e d a s a n a c c e s s o r y
9 3 0 A Rear electric windows
1 0 4 0 A Rear screen and mirror demisting
11 15A Rear windscreen wiper
1 2 3 0 A Front electric windows - Sunroof
14 1 0 AEngine fuse box - Air bags - Steering wheel controls - Rain sensor
15 15A Instrument panel - Multifunction display - Air condition ing - Audio equipment
1 6 3 0 A L o c k i n g / u n l o c k i n g c o n t r o l s f o r d o o r s , b o n n e t a n d b o o t
2 0 1 0 A Right-hand brake light
2 1 15A Left-hand brake light - 3rd brake light
2 2 2 0 A Front courtesy light - Map reading light - Glove box lighting - Lighter
S1 Shunt PARC shunt
Page 109 of 123
PRACTICAL INFORMATION
1 0 2 -
or The electrical circuit of
your vehicle is designed
to operate with standard
or optional equipment.
Before installing other electri-
cal equipment or accessories in
your vehicle, consult a PEUGEOT
dealer.
Some electrical accessories or the
w a y i n w h i c h t h e y a r e i t t e d m a y
have an adverse effect on the op-
e r a t i o n o f y o u r v e h i c l e ( i t s e l e c -
tronic control circuits, the audio
circuit and the electrical charging
circuit).
PEUGEOT declines any respon-
sibility for expenses incurred
through the repair of your vehicle
or for any malfunctions resulting
from the installation of auxiliary
accessories, not supplied and not
recommended by PEUGEOT and
not installed in accordance with
PEUGEOT's instructions, in par-
ticular for any equipment the pow-
er consumption of which exceeds
1 0 m i l l i a m p s .
Fuse N° Rating Functions
1 * 2 0 AFan unit
2 * 6 0 A A B S / E S P
3 * 3 0 A A B S / E S P
4 * 7 0 ABuilt-in systems interface supply
5 * 7 0 ABuilt-in systems interface supply
6 * - Not used
7 * 3 0 A Ignition switch supply
8 * 2 0 A A u d i o e q u i p m e n t a m p l i i e r Engine compartment fuse box
T o g a i n a c c e s s t o t h e b o x i n t h e e n g i n e c o m p a r t m e n t ( n e x t t o t h e b a t t e r y ) , u n c l i p
the cover.
After carrying out work, close the cover very carefully.
* The maxi fuses provide additional protection for the electr ical systems. Any
work on these fuses must be carried out by a PEUGEOT dealer.
Page 111 of 123
PRACTICAL INFORMATION
1 0 4 -
BATTERY
To charge the battery using a bat-
tery charger:
- Disconnect the battery,
- Follow the instructions for use
given by the battery charger
manufacturer,
- Reconnect starting with the n e g a t i v e ( - ) t e r m i n a l ,
- Check that the terminals and connectors are clean. If they are
c o v e r e d w i t h s u l p h a t e ( w h i t e o r
greenish deposit), disconnect
them and clean them. - W a i t f o r 2 m i n u t e s
after switching off
the ignition before
disconnecting the
battery.
- Never disconnect a terminal when the engine is running.
- Never charge a battery w i t h o u t i r s t d i s c o n n e c t i n g t h e
terminals.
- Close the windows and the roof before disconnecting the
battery.
- After every reconnection of the battery, switch on the
ignition and wait 1 minute
before starting to allow the
electronic systems to be
i n i t i a l i s e d . I f s l i g h t d i f i c u l t i e s
are experienced after this,
please consult a PEUGEOT
dealer.
It is advisable to disconnect the
battery if the vehicle is not to be
used for a period of more than
one month.
ECONOMY MODE
FUNCTION
After the engine has stopped, certain
f u n c t i o n s ( w i n d s c r e e n w i p e r , e l e c
-
tric windows, courtesy lights, audio
equipment, etc.) can only be used for
a combined duration of approximately
thirty minutes, to prevent discharging
the battery.
Once the thirty minutes are over, a
switching to economy mode mes-
sage appears on the multi-function
display and the active functions are
put on standby.
These functions are reactivated au-
tomatically next time the vehicle is
driven.
In order to resume the use of these
functions immediately, the engine
must be started and left to run for a
few minutes.
The time available to you will then
be double the duration for which the
engine is left running. However,
this period will always be between
i v e a n d t h i r t y m i n u t e s .
To start the vehicle from another
battery:
- Connect the red cable to the
p o s i t i v e ( + ) t e r m i n a l s o f t h e
two batteries,
- Connect one end of the green o r b l a c k c a b l e t o t h e n e g a t i v e ( - )
terminal of the slave battery,
- Connect the other end of the green or black cable to an
earth point on the broken down
vehicle, as far as possible from
t h e b a t t e r y ( f o r e x a m p l e , r i g h t -
hand engine mounting),
- Operate the starter, let the engine run,
- Wait for the engine to return to idle, then disconnect the cables.
A l a t b a t t e r y p r e v e n t s t h e
engine from starting.
Page 112 of 123
1 0 5
PRACTICAL INFORMATION
-
FITTING SPEAKERS
T h e f a c t o r y - i t t e d e q u i p m e n t a l l o w s
t h e i t t i n g o f :
- 1 6 5 m m d i a m e t e r s p e a k e r s i n
the front doors,
- 1 3 0 m m d i a m e t e r s p e a k e r s i n the rear doors,
- 2 2 . 5 m m d i a m e t e r t w e e t e r s i n the mirror trims. Making the connections
A1 : -
A 2 : -
A3 : -
A4 : -
A5 : -
A 6 : ( + v e ) I g n i t i o n p o s i t i v e
A 7 : ( + v e ) P e r m a n e n t
A 8 : E a r t h
B 1 : ( + ) R e a r r i g h t s p e a k e r
B 2 : ( - ) R e a r r i g h t s p e a k e r
B 3 : ( + ) F r o n t r i g h t s p e a k e r a n d
tweeter
B 4 : ( - ) F r o n t r i g h t s p e a k e r a n d tweeter
B 5 : ( + ) F r o n t l e f t s p e a k e r a n d t w e e t e r
B 6 : ( - ) F r o n t l e f t s p e a k e r a n d t w e e t e r
B 7 : ( + ) R e a r l e f t s p e a k e r
B 8 : ( - ) R e a r l e f t s p e a k e r
Consult a PEUGEOT dealer
before installing audio equip-
ment or speakers in your
vehicle.
FITTING AUDIO EQUIPMENT
Your vehicle is equipped with certain
f a c t o r y - i t t e d a u d i o e q u i p m e n t :
- roof aerial,
- coaxial aerial cable,
- basic interference suppression,
- supply to front speakers,
- supply to rear speakers,
- t w o 8 - w a y c o n n e c t o r s .
