432 Practical hints
Fuses
The electrical fuses in your vehicle serve to
switch off malfunctioning power circuits.
If a fuse is blown, the components and
systems secured by that fuse will stop
operating.If a newly inserted fuse blows again, have
the cause determined and rectified by an
authorized Mercedes-Benz Center.
A fuse chart explains the fuse allocation
and fuse amperages. It is located in the
fuse box in the passenger compartment
(
page 433).
The electrical fuses are located in different
fuse boxes:

in the passenger compartment on the
driver’s side (
page 433)

on the driver’s side of the engine
compartment (
page 433)Before replacing fuses:
Apply the parking brake (page 59).
Make sure the gear selector lever* is
set to positionP (
page 157) (manual
transmission to Neutral).
Turn off all electrical consumers.
Turn off the engine (page 61).
Remove the SmartKey from the starter
switch.
Warning!G
Only use fuses approved by Mercedes-Benz
with the specified amperage for the system
in question and do not attempt to repair or
bridge a blown fuse. Using other than
approved fuses or using repaired or bridged
fuses may cause an overload leading to a
fire, and/or cause damage to electrical
components and/or systems. Have the
cause determined and remedied by an
authorized Mercedes-Benz Center.
iA blown fuse must be replaced by an
appropriate spare fuse (recognizable by its color
or the fuse rating given on the fuse) of the
amperage recommended in the fuse chart.
Any Mercedes-Benz Center will be glad to advise
you on this subject.
iIn case of a blown fuse contact Roadside
Assistance or an authorized Mercedes-Benz
Center.

433 Practical hints
Fuses
Fuse box in passenger compartment
1Fuse box cover
Opening
Open the driver’s door.
Insert flat, blunt object as a lever into
recess on the edge of cover1 at the
position indicated by the arrow.
Loosen cover1 from dashboard using
the lever.
Pull cover1 out and remove.Closing
Attach cover1 in the front.
Fold cover1 in until it engages.
Fuse box in engine compartment
The fuse box is located in the engine com-
partment on the driver’s side.
1Fuse box
2Clamp
3Fuse box cover
Opening
Open the hood (page 294).
With a dry cloth, remove any moisture
from the fuse box.
Release clamps2.
Remove fuse box cover3.
Closing
Make sure the sealing rubber is
properly positioned.
Press fuse box cover3 down and
secure with clamps2.
!Do not use sharp objects such as a
screw driver to open fuse box cover1 in the
dashboard, as this could damage it.
!Fuse box cover3 must be properly
positioned as described to prevent moisture or
dirt from entering the fuse box and possibly
impairing fuse operation.
