2008 MERCEDES-BENZ SLK-Class Comand Manual

145 Navigation*
During route guidance

Use

or

to select a destination
from the list.

The
Page
soft keys allow scrolling
through the list page by page.

Press the
Details
soft key if you want
to see details of a selected destination.
The details disappear again after

approx. 3 seconds, or when pressing
the
Details
soft key again.

Press

to confirm the selection of the
destination.
The system begins to calculate the
route to the selected stop-over destina
-
tion.
Changing/deleting the stop-over desti
-
nation
The soft key displays are shown ( page
139)
.
.
iThe arrows point in the direction of the
destination.

Distance information specifies the di
-
rect distance to the destination.
iA stop-over destination can be
changed or deleted only while the route
guidance to this stop-over is active (in
-
dicated by
.
If no route guidance to a stop-over des
-
tination is active yet
( page
144)
.


146 Navigation*During route guidance
Press the
St-over
soft key.
The menu for deleting or changing the
stop-over destination appears.

Use

to select the
Delete
active
stopover
entry.

Press

.
This will delete the stop-over. The sys
-
tem calculates the route to the final
destination;
or

Use

to select the
Replace
active
stopover
entry.

Press

.
The stop-over is deleted, a new stop-
over destination can be entered ( page
144)
.

The soft key displays are shown ( page
139)
.

Press the
Display
soft key.
The Display menu appears.
Selectable soft keys
Symbols
soft key

Provides access to setting the symbols
display
( page
147)
,

View
soft key

Provides access to setting the map ori
-
entation
( page
148)
,

Map
soft key

Provides access to the Map Display
menu
( page
148)
,

Auto
soft key

Provides access to the Automatic Map
Switching menu
( page
149)
,

Zoom
soft key

Provides access to the definition of the
scales for full-screen and split-screen
map display
( page
150)
.
Defining route guidance displays

147 Navigation*
During route guidance
You can select which POIs will appear as
symbols on the map.
In the Display menu
( page
146)

press the
Symbols
soft key.
The available options appear.

Use

or

to select an option.

Press

.
The selected option is activated. A solid
circle
designates an activated op
-
tion.
Standard
option:

The symbols for the system default
setting are displayed on the map;

Personal
option:

The symbols to be displayed can be
selected from a list
( page
147)
;

None
option:

No symbols will be displayed on the
map.
Setting personal symbol display
After activating the
Personal
option
( page
147)
, press the
Change
soft
key.The list of available symbols appears.

Use

or

to select a list entry.

Press

to activate or deactivate a se
-
lected symbol depending on its previ
-
ous state.

Finally, press the
Back
soft key or wait
for the screen to change.
The setting is stored.
Setting symbols display iThe symbols are on display only if the
map scale is set at 0.05 mi (50 m),

0.1 mi (100 m), 0.2 mi (200 m), or

0.5 mi (500 m).To set the map scale (
 page
133).
iThe
Change
soft key is only available if
the
Personal
option is selected. Other
-
wise, it will appear shaded out.
iEmpty square
= symbol deactivated

Solid square
= symbol activated
Any number of symbols can be activat
-
ed.

148 Navigation*During route guidanceOne of the following orientations can be
selected:
2D North
up
Fixed map orientation, north is always
pointing up;

2D Heading
up
Dynamic map orientation, driving direc
-
tion is always pointing up.

In the Display menu
( page
146)
,
press the
View
soft key.
Both options appear.
Changing map orientation
Use

or

to select the desired
option.

Press

.
The orientation changes.

Finally, press the
Back
soft key or wait
for the screen to change.
You can set the following to be displayed in
the status bar:
Time of arrival/Dist. to Dest.

If the full-screen map display is activat
-
ed
( page
134)
, the estimated time of
arrival and the remaining distance to
the destination will be displayed. If you
have entered a stopover destination ( page
143)
, the corresponding data
will be displayed.

Current-Location display

If the full-screen map display is activat
-
ed
( page
134)
, the following data will
be displayed:
The current position as coordi
-
nates.

The number of satellites that can
currently be received.

The current elevation (ALT = altitu
-
de) above sea level.
Setting map orientation
iEmpty circle
= deactivated

Solid circle
= activated
iDuring route guidance, a symbol will
appear on the left-hand side of the bot
-
tom status bar if map display is
switched ON.
North symbol
:
Fixed map orientation, north is al
-
ways pointing up;

Compass symbol
:
Dynamic map orientation, driving
direction is always pointing up.
Map display menu

149 Navigation*
During route guidance

No display

The name of the current road is dis
-
played.

In the Display menu
( page
146)
,
press the
Map
soft key.
The possible options appear.

Use

or

to select the desired
option.

Press

.
The map display is switched.

Finally, press the
Back
soft key or wait
for the screen to change.
If you have set the map view to full screen ( page
134)
and the automatic map tog
-
gling function is activated, then the follow
-
ing happens:
The system automatically switches to
the split-screen map display when a
driving maneuver is announced.

As soon as the driving maneuver is
completed, the system automatically
returns to full-screen map display.
Switching automatic toggling ON/OFF
In the Display menu
( page
146)
,
press the
Auto
soft key.
Option
On or
Off
appears.

Use

or

to select the desired
option.
iThe COMAND uses GPS to calculate
the elevation above sea level. For rea
-
sons of tolerance, this value may devi
-
ate from the actual value.
iThe solid circle
shows the current
setting.Automatic map toggling
iThe solid circle
shows the current
setting.


150 Navigation*During route guidance
Press

.
Depending on the previous setting, au
-
tomatic map toggling will be switched
ON or OFF.

Finally, press the
Back
soft key or wait
for the screen to change.
You can select whether the full-screen and
split-screen map scales are to be set to
-
gether (default setting) or individually.
In the Display menu, press the ( page
146)
Zoom
soft key.
The
Standard
setting
and
Manual
op
-
tions appear.
Standard
setting
option:

The scales for full-screen and split-
screen map display are always
identical. Changing the scale ( page
133)
on one map changes
the scale of the other.

Manual
option:

The scales can be different. Chang
-
ing the scale on one map has no ef
-
fect on the current scale of the
other map.

Use

or

to select the desired op
-
tion.

Press

.
Depending on the previous setting, the Standard
setting
(identical scale) or
Manual
(individual scale) option is acti
-
vated.

Finally, press the
Back
soft key or wait
for the screen to change.
Scales for full-screen and

split-screen map display
iThe solid circle
shows the current
setting.

151 Navigation*
Last destinations and destination memory


Last
destinations
and
destination
memory
The
Last destinations
memory automat
-
ically stores the last destination for which
route guidance had been started.The current vehicle position and positions
selected via the map can also be stored as
destinations in this memory (
 page
130
).
Such destinations are marked with
.
Altogether a maximum of 50 destinations
can be stored.
Open the Navigation main menu ( page
112)
.

Use

to select the

Last
destinations
menu item.

Press

.
The list of last destinations and map
positions is displayed. The most re
-
cently stored destination is shown at
the top of the list.
Selecting an entry from the Last desti
-
nations memory
Open the
Last
destinations
memory.

Use

or
to select an entry.

The
Page
soft keys allow scrolling
through the list page by page.
Selectable soft keys
Save
soft key

Stores the selected entry in the Desti
-
nation memory
( page
153)
,

Details
soft key

Displays details on the selected entry
(if available),

Delete
soft key

Allows the deletion the selected entry ( page
152)
.
Starting route guidance to a destina
-
tion from the Last destination memory
Select an entry
( page
151)
.

Press

.
The Start Route Guidance menu with
the full displayed destination appears.
Last destinations memory


152 Navigation*Last destinations and destination memory
Press

if you want to start route
guidance ( page
131)
, otherwise

press the
Back
soft key.
Deleting an entry from the Last destina
-
tions memory
Select an entry
( page
151)
.

Press the
Delete
soft key.
You are prompted to confirm whether
or not the destination is to be deleted.

Use

to select the menu item
Yes
.

Press

.
The destination is deleted.
Calling up the Destination memory and
selecting a destination
Open the Navigation main menu ( page
112)
.

Use

or

to select the
Destination memory
menu item.

Press

.
The Destination memory appears. This
is indicated by
Destination memory

displayed in the status bar.

Use

,
,
or

to select the
desired entry.
Selectable soft keys and options
Details
soft key

Displays details on the selected entry
(if available),

Delete
soft key

Allows to delete the selected entry ( page
153)
,
Starting route guidance to a destina
-
tion from the Destination memory
Select a destination.

Press

.

The Start Route Guidance menu ap
-
pears.

Press

if you want to start route
guidance ( page
131)
, otherwise

press the
Back
soft key.
Destination memory
