373 Controls in detailSeats
Seats
Seat adjustmentWarning!
G
All seat, head restraint adjustments, as well
as fastening of seat belts, must be done be-
fore the vehicle is put into motion.Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
back in an excessively reclined position as
this can be dangerous. You could slide un-
der the seat belt in a collision. If you slide
under it, the seat belt would apply force at
the abdomen or neck. That could cause se-
rious or fatal injuries. The seat backrest and
seat belts provide the best restraint when
the wearer is in a nearly upright position and
seat belts are properly positioned on the
body.
Warning!
G
Your seat must be adjusted so that you can
correctly fasten your seat belt
(page 395).
Observe the following points:


Adjust the backrest until your arms are
slightly angled when holding the steer-
ing wheel.


Adjust the seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The po-
sition should be as far back as possible
with the driver still able to operate the
controls properly.


Adjust the head restraint so that it is as
close to the head as possible and the
center of the head restraint supports
the back of the head at eye level.


Never place hands under the seat or
near any moving parts while a seat is be-
ing adjusted.
Failure to do so could result in injury to per-
sons.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.

376 Controls in detailSeatsAdjusting front passenger seat from
driver’s seat/rear*
Adjusting front passenger seat from
driver’s seat*
You can adjust the front passenger seat
using the seat switches on the driver’s
side.
1Adjusting front passenger seat

Press button1.When the indicator lamp on button1 is
on, you can operate the following features
of the front passenger seat:


seat adjustment


seat heating/ventilation*


memory function
Warning!
G
When adjusting the front passenger seat,
make sure the seat, if occupied, is as far
from the passenger front air bag as possi-
ble.
Otherwise, the passenger could be seriously
or even fatally injured in the event of an ac-
cident or braking maneuver.
Make sure no one is caught or injured while
the seat is being adjusted.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.
!
Do not move the front passenger seat com-
pletely forward if objects are stored in the parcel
net in the front passenger-side footwell. Items in
the net may be damaged.

384 Controls in detailSeatsEasy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the driver’s seat is in its
maximum rearward position and the steer-
ing wheel is in its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the “Vehicle” menu of
the COMAND system (
page 268).With the easy-entry/exit feature activated,
the steering wheel and driver’s seat will re-
turn to their last set memory position or a
factory-set maximum forward position
when you:


close the driver’s door with the ignition
switched on


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 372) once
with the driver’s door closed
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To stop seat/steering wheel movement, do
one of the following:

Press seat adjustment switch
(page 374).


Move steering wheel adjustment stalk
(page 386).


Press one of the memory position but-
tons or the memory buttonM
(page 393).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
!
Do not activate the easy-entry/exit feature
if the seat backrest is in an excessively reclined
position. Doing so could cause damage to front
or rear seats.
First move the seat backrest to an upright posi-
tion.
i
For safety reasons, the driver’s seat will not
return to its last set position with the easy-en-
try/exit feature activated if the system recogniz-
es the last set position as an extreme forward
position. Instead, the driver’s seat will remain at
or move to a factory-set maximum forward posi-
tion. To again fully return the driver’s seat to

385 Controls in detailSeats
With the easy-entry/exit feature activated
the steering wheel tilts upwards and the
driver’s seat moves a few inches to the
rear when you:

remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button (
page 372) in position1
your last set position or to memory position, ad-
just the seat to the desired position or press and
hold the respective memory position button
(page 393).
i
The last set driver’s seat and steering wheel
positions are stored when


the ignition is switched off (
page 370)


the position is stored in memory
(page 392)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
If the current seat position falls into a factory-set
position range and the system recognizes the
current seat position to be rearward enough for
easy entry and exit, the driver’s seat will not
move to the rear when the easy-entry/ exit fea-
ture is activated.
The adjustment procedure is briefly interrupted
when the engine is started.Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All driver’s seat and steering wheel ad-
justments must be completed before setting
the vehicle in motion. Driving off with the
driver’s seat/steering wheel still adjusting
could cause the driver to lose control of the
vehicle.

386 Controls in detailSteering wheel
Make sure that

you can reach the steering wheel with
your arms slightly bent at the elbows


you can move your legs freely


all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
Steering wheel adjustment
1Adjusting steering wheel, in or out
2Adjusting steering column, up or down
Adjusting steering wheel in or out:
Move stalk forward or back in the direc-
tion of arrow1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.

Adjusting steering wheel up or
down: Move stalk up or down in the di-
rection of arrow2.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the steering
wheel adjustment feature can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
i
The memory function (
page 392) lets you
store settings for the steering wheel together
with the settings for the seat position and the ex-
terior rear view mirrors.

387 Controls in detail
Steering wheel
Heated steering wheel*
The steering wheel heating warms up the
leather area of the steering wheel.
1Switching on
2Switching off
3Indicator lamp
Switch on the ignition (
page 370).

Switching on: Turn switch at the tip of
stalk in the direction of arrow1.
The steering wheel is heated. Indicator
lamp3 comes on.

Switching off: T u r n s w i t c h a t t h e t i p o f
stalk in the direction of arrow2.
The steering wheel heating is turned
off. Indicator lamp3 goes out.
i
The steering wheel heating will not switch
on, when the temperature of the vehicle interior
is above 86°F (30°C).
i
Indicator lamp3 flashes or goes out


in case of power surge or undervoltage


in case of a steering wheel heating malfunc-
tion
i
The steering wheel heating switches off au-
tomatically:


when you remove the SmartKey from the
starter switch


on vehicles with KEYLESS-GO*, when you
switch off the ignition (
page 370) and
open the driver’s door


when the temperature of the vehicle interior
is above 86°F (30°C)


after approximately 24 minutes

392 Controls in detailMemory functionPrior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach, and comfort. The head re-
straint should also be adjusted for proper
height. See also the section on air bags
(page 42) for proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213 and
210.2.With the memory function you can store up
to three different configurations.
Each stored position on the driver’s side
includes the following settings:


Driver’s seat: head restraint height,
seat and backrest position, backrest
curvature in lumbar area


Multicontour seat*: sides of backrest,
backrest curvature in lumbar and
shoulder area


Drive-dynamic multicontour seat*:
activation/deactivation


Steering wheel position


Exterior rear view mirrors positionWarning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s un-
supervised access to a vehicle could result
in an accident and/or serious personal
injury.

399 Controls in detail
Lighting
Lighting
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
i
If you drive in countries where vehicles drive
on the other side of the road than the country in
which the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Center.
i
The active Bi-Xenon headlamps monitor
your steering angle and driving speed, then auto-
matically shift their beams to either side to bet-
ter follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
1‚
Standing lamps, left (turn left two
stops)
2ˆ
Standing lamps, right (turn left
one stop)
3M
Off
Daytime running lamp mode
(page 401)
4*
Automatic headlamp mode
Daytime running lamp mode
(page 401)
5C
Parking lamps (also tail lamps, li-
cense plate lamps, side marker
lamps, instrument panel lamps)
6B
Low beam headlamps or high
beam headlamps
7‡
Front fog lamps
8†
Rear fog lamp
i
If you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message “Please Switch Off
Lights” appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message “Turn Lights Off or Remove Key”
appears in the multifunction display remove the
SmartKey from the starter switch or switch off
the automatic headlamp mode.
!
Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.
