364 Controls in detailLocking and unlocking

Remember that the engine can be
started by anyone with a SmartKey
wi th KEY LES S-GO tha t i s le ft ins id e t he
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.
Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message “Key Detected In
Vehicle” appears in the multifunction
display. The vehicle will not be locked.Factory setting
1Outside door handle

Global unlocking: Grasp an outside
door handle1.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:


neither a door nor the trunk is opened


the central locking/unlocking switch is
not activated
i
Your vehicle may be equipped with an
acoustic lock and unlock confirmation signal fea-
ture. If your vehicle is equipped with this feature
and the feature is activated, an acoustic signal
will sound when the vehicle is locked or unlocked
using the SmartKey with KEYLESS-GO.
To determine whether or not your vehicle is
equipped with this feature, contact an autho-
rized Mercedes-Benz Center. If equipped and
you wish to activate or deactivate the feature, or
adjust its signal volume, also contact an autho-
rized Mercedes-Benz Center.
i
The vehicle could inadvertently be unlocked
if the SmartKey with KEYLESS-GO is within 3 ft
(1 m) of the vehicle and:


an outside door handle is splashed with wa-
ter, or


you attempt to clean an outside door handle.

365 Controls in detail
Locking and unlocking

Global locking: Close all doors and
touch outside of door handle1. Do
not keep your hand in the door handle
recess.
With the trunk and both doors closed:

All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you, grasp the driv-
er’s outside door handle only the driver’s
door and the fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 361)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:

Unlocking driver’s door and fuel fill-
er flap: Grasp the driver’s outside door
handle.


All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 364).


The locking knob in the driver’s
door moves up.


The anti-theft alarm system is dis-
armed.

Global unlocking: Grasp any outside
door handle other than the driver’s out-
side door handle.

All turn signal lamps flash once.


An acoustic signal sounds once
(if equipped and feature activated).


The locking knobs in the doors
move up.


The anti-theft alarm system is dis-
armed.
i
Vehicles with trunk opening/closing
system*:
You can also lock the vehicle using the
KEYLESS-GO locking/closing switch
(
page 514).


366 Controls in detailLocking and unlocking
Global locking: Close all doors and
touch outside of door handle1
(page 364). Do not keep your hand in
the door handle recess.
With the trunk and both doors closed:


All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.

Restoring to factory setting: Press
and hold buttonsŒ and‹ si-
multaneously for about 5 seconds until
battery check lamp5 (
page 361)
flashes twice.
Checking batteries in the SmartKey or
SmartKey with KEYLESS-GO*
Press button‹ orŒ.
The battery check lamp (
page 358)
or (
page 361) comes on briefly to in-
dicate that the SmartKey or SmartKey
with KEYLESS-GO batteries are in or-
der.Loss of the SmartKey or SmartKey with
KEYLESS-GO*
If you lose your SmartKey, SmartKey with
KEYLESS-GO or mechanical key, you
should do the following:
Have the SmartKey or SmartKey with
KEYLESS-GO deactivated by an autho-
rized Mercedes-Benz Center.

Report the loss of the SmartKey,
SmartKey with KEYLESS-GO or the me-
chanical key immediately to your car
insurance company.

Have the mechanical lock replaced if
necessary.
Any authorized Mercedes-Benz Center will
be glad to supply you with a replacement.
i
Vehicles with trunk opening/closing
system*:
You can also lock the vehicle using the
KEYLESS-GO locking/closing switch
(
page 514).
!
If the battery check lamp does not come on
briefly during check, the SmartKey or SmartKey
with KEYLESS-GO batteries are discharged.
Replace the batteries (
page 712).
You can obtain the required batteries at any au-
thorized Mercedes-Benz Center.
i
If the batteries are checked within signal
range of the vehicle, pressing button‹ or
Πwill lock or unlock the vehicle accordingly.


367 Controls in detail
Locking and unlocking
Opening doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handleFront doors

Pull on door handle2 on the respec-
tive front door to open door.
If the door was locked, locking knob1
will move up.
Rear doors

Pull up locking knob1 on the respec-
tive rear door to unlock door.

Pull on door handle2 on the respec-
tive rear door to open door.
i
If the vehicle has been locked with the
SmartKey or KEYLESS-GO*, opening a door from
the inside will trigger the anti-theft alarm system.
To cancel the alarm, do one of the following:


Insert the SmartKey or SmartKey with
KEYLESS-GO* in the starter switch.


Press button Œ or ‹ on the SmartKey
or SmartKey with KEYLESS-GO*.
In vehicles with KEYLESS-GO*:


Grasp an outside door handle.
The SmartKey with KEYLESS-GO* must be
within 3 ft (1 m) of the vehicle.


Press the KEYLESS-GO* start/stop button
(page 372).
The SmartKey with KEYLESS-GO* must be
inside the vehicle.
i
If you hear a warning signal you have forgot-
ten to switch off the low beam headlamps or the
parking lamps before opening the driver’s door.
In addition the message “Please Switch Off
Lights” appears in the multifunction display.Switch off the low beam headlamps or the park-
ing lamps.
If the message “Turn Lights Off or Remove Key”
appears in the multifunction display remove the
SmartKey from the starter switch or switch off
the automatic headlamp mode.
!
Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.

369 Controls in detail
Locking and unlocking
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from the inside using the central
locking or unlocking switch. This can be
useful, for example, if you want to lock the
vehicle before starting to drive.
The central locking switch and central un-
locking switch do not lock or unlock the
fuel filler flap or the interior storage com-
partments such as the glove box.1Central unlocking switch
2Central locking switch

Locking: Press switch ‹.
If the front passenger door is closed,
the vehicle locks.

Unlocking: Press switch Œ.
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
i
You can open a locked door from inside at
any time. Open door only when conditions are
safe to do so.
If the vehicle was previously centrally locked
with the SmartKey or with KEYLESS-GO*, it will
not unlock using the central unlocking switch.
If the vehicle was previously locked with the cen-
tral locking switch:


and the SmartKey or SmartKey with
KEYLESS-GO* is set to factory settings, the
complete vehicle is unlocked when a door is
opened from the inside


and the SmartKey or SmartKey with
KEYLESS-GO* is set to selective settings,
only the door opened from the inside is un-
locked

370 Controls in detailStarter switch positionsSmartKeyStarter switch
0For removing SmartKey
1Power supply for some electrical con-
sumers
2Ignition (power supply for all electrical
consumers) and driving position.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary.
If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 628).
3Starting positionFor information on starting the engine us-
ing the SmartKey, see “Starting with the
SmartKey” (
page 417).
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.
i
When the SmartKey is removed from the
starter switch and the automatic transmission is
in a position other than park positionP, the auto-
matic transmission automatically shifts to park
positionP.
!
If the SmartKey cannot be turned in the
starter switch, the battery may not be sufficient-
ly charged.


Check the battery and charge it if necessary
(page 729).


Have the vehicle jump-started (
page 734).
To prevent accelerated battery discharge or a
completely discharged battery, always remove
the SmartKey from the starter switch when the
engine is not in operation.

371 Controls in detail
Starter switch positions
SmartKey with KEYLESS-GO*
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function and a re-
movable KEYLESS-GO start/stop button.
With the KEYLESS-GO start/stop button
inserted and the SmartKey with
KEYLESS-GO present in the vehicle, press-
ing the KEYLESS-GO start/stop button

without the brake pedal depressed
corresponds to the various starter
switch positions (
page 372)


with the brake pedal firmly depressed
will start the engine (
page 417)If you wish or should there be a need to in-
sert the SmartKey with KEYLESS-GO in the
starter switch, the KEYLESS-GO start/stop
button can be easily removed by pulling it
out of the starter switch.
1KEYLESS-GO start/stop button
2Starter switch

Insert KEYLESS-GO start/stop
button1 into starter switch 2 (if not
inserted already).
i
The function of the SmartKey overrules the
KEYLESS-GO function.
i
The KEYLESS-GO start/stop button does
not need to be removed from the starter switch
when you leave the vehicle. However, always
take the SmartKey with KEYLESS-GO with you
when you leave the vehicle. As long as the
S m a r t K e y w i t h K E Y L E S S - G O i s i n t h e v e h i c l e , t h e
vehicle’s electrical systems can be switched on
or the engine can be started using the
KEYLESS-GO start/stop button.
i
When you switch from SmartKey mode back
to KEYLESS-GO mode, the system requires
2 seconds of detection time before you can use
the KEYLESS-GO button as usual.


372 Controls in detailStarter switch positionsThe SmartKey with KEYLESS-GO must be
located in the vehicle.
Make sure the automatic transmission
is set to park positionP.

Do not depress the brake pedal.
KEYLESS-GO start/stop button1USA only
2Canada only
Position 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have status 0 (as with
SmartKey removed).Position 1

Press the KEYLESS-GO start/stop but-
ton once.
This supplies power for some electrical
consumers.
Ignition (or position 2)

Press the KEYLESS-GO start/stop but-
ton twice.
This supplies power for all electrical
consumers.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 628).
For information on starting the engine us-
ing the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 417).
i
If you now press the KEYLESS-GO
start/stop button


once again, the ignition (position2) is
switched on


twice, the power supply is again switched off
i
If you now press the KEYLESS-GO
start/stop button once, the power supply is
again switched off.
i
When you switch on the ignition, the indica-
tor and warning lamps (except high beam head-
lamp indicator lamp and turn signal indicator
lamps unless activated) in the instrument cluster
come on. The indicator and warning lamps (ex-
cept high beam headlamp indicator lamp and
turn signal indicator lamps if activated) should go
out when the engine is running. This indicates
that the respective systems are operational.
