2008 MERCEDES-BENZ S-Class ESP

173 Control systems
COMAND telephone*
Switching between private or business
data
Select symbol 2.
The display switches to private or busi-
ness data, depending on the previous
status.
Selecting a different data field

Rotate ymz or slide qmr.
Displaying abbreviated content in full

Select “Options”
“Details”.
The display is shown in full.

Closing entire display: Slide omp or
pressn.
Closing the detailed view

Select “Back”.Displaying of a complete phone book
entry in the mobile phone
Searching for the desired entry

Search for a phone book entry in the
mobile phone (
page 161).

Press n.
The detailed view appears.1To go back to the previous menu
2Category symbol
3Display for phone book entry in mobile
phone
4To call up options
i
The mobile phone must be inserted in the
cradle*.
i
If a phone book entry in the mobile phone
has more than one telephone number, you will
see all telephone numbers with the respective
category symbol 2 in the detailed view.

187 Control systems
COMAND navigation
COMAND navigation
Safety precautionsWarning!
G
For safety reasons, only enter a destination
when the vehicle is stationary. When the ve-
hicle is in motion, a passenger should enter
the destination. Study manual and select
route before driving.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
COMAND calculates the route to the desti-
nation without taking account of the follow-
ing, for example:

Traffic lights


Stop and right-of-way signs


Parking or stopping prohibited areas


Lane merging


Other road and traffic rules and regula-
tions


Narrow bridges
COMAND may give incorrect navigation
commands if the data in the digital map
does not correspond with the actual
road/traffic situation. DVD maps do not
cover all areas nor all routes within an area.
For example, if the traffic routing has been
changed or the direction of a one-way road
has been reversed.
For this reason, you must always observe
applicable road and traffic rules and regula-
tions during your journey. Road and traffic
rules and regulations always have priority
over the navigation commands generated by
the system.
Warning!
G
Navigation announcements are intended to
direct you while driving without diverting
your attention from the road and driving.
Please always use this feature instead of
consulting the map display for directions.
Consulting the symbols or map display for
directions may cause you to divert your at-
tention from driving and increase your risk
of an accident.

189 Control systems
COMAND navigation (introduction)
Loading a DVD into the DVD changer
1Disc slot
2Magazine tray buttons 1 – 6

Switch on COMAND (
page 87).

Press one of the magazine tray
buttons2.
If a disc is loaded, it will be ejected.

Take disc out of slot 1.

Wait until LED for magazine button 2
which you pressed flashes quickly.

Slide DVD into slot 1 with printed side
facing upwards.
COMAND loads the DVD.
i
If you carry out the update with the engine
switched off and the vehicle battery has insuffi-
cient power, COMAND may automatically switch
off during the process in order to protect the bat-
tery. If this occurs, restart the update with the
engine running period. Similarly, if the SmartKey
position is unintentionally switched to 0, restart
the update.Warning!
G
Never leave the engine running in an en-
closed space. The exhaust gases contain
carbon monoxide. Inhaling exhaust gases
constitutes a health hazard and could lead
to loss of consciousness or even death.
i
Each magazine tray button 2 indicates the
status of the corresponding magazine tray by
means of an LED.


LED off = magazine tray is empty


LED constantly lit = magazine tray is loaded


LED flashes = CD/DVD changer requesting
disc to be loaded

190 Control systemsCOMAND navigation (introduction)Updating
After you have loaded the DVD, you will
see a message to the effect that the disc
does not contain a recognizable audio for-
mat.
Confirming message: Press n.
COMAND checks whether the map
software on the DVD is compatible with
the vehicle’s navigation system and
whether it is compatible with the cur-
rent system software.
Map software is compatible with the
navigation system and the current sys-
tem software
COMAND now checks whether the map
data on the DVD is already installed.
Map data is not yet installed
You will see a comparison of the version
statuses in the display and a prompt will
appear asking whether you want to contin-
ue with the update.

Select “Yes” or “No”.
If you select “No”, COMAND automati-
cally ejects the DVD and the map data
is not updated.
Take DVD out of the slot.
If you select “Yes”, the map data is up-
dated.
Map data is already installed
You will see a message that the map data
is already installed and a prompt will ap-
pear asking you whether you want to con-
tinue with the update.

Select “Yes” or “No”.
If you select “No”, COMAND automati-
cally ejects the DVD and the map data
is not updated.
Take DVD out of slot.
If you select “Yes”, the existing map
data is saved again.Updating the map data
While the update is running, you will see a
message to this effect and a progress bar.
The progress bars fills up from left to right
during the update.
1Progress bar
You can either cancel the update or allow
it to run to the end without canceling.

Canceling an update on the DVD
changer: Press corresponding maga-
zine tray button 2 (
page 189).
The DVD will be ejected in both cases.

Take DVD out of slot.

199 Control systems
COMAND navigation (introduction)

Adjusting: Select “Navi”
“Navi”

“Map Display”.
The map display list appears. A dot R
indicates the current setting.

Select “Standard symbols”, “Personal
symbols” or “No symbols”.
If you select “Personal symbols”, the
list of POIs appears.
Switching POI symbol display on
or off: Select the desired POI.
The corresponding symbol displays
are switched on or off, depending
on the previous status. A check-
mark indicates which status is ac-
tive. You can switch on the symbol
displays for more than one POI.

Exiting menu: Slide omp or press
back button L in the center console
(page 88).
Arrival time and distance
You can set whether the estimated arrival
time and the distance to the destination
should be displayed in the map.

Displaying: Select “Navi”
“Navi”

“Map Display”.
The map display list appears. A dot R
indicates the current setting.

Select “Arrival Time/Distance”.
Depending on the previous status the
display showing the arrival time and
distance is switched on or off.Current street
You can set whether the current street you
are driving on should be displayed in the
map.

Displaying: Select “Navi”
“Navi”

“Map Display”.
The map display list appears. A dot R
indicates the current setting.

Select “Current Street”.
Depending on the previous status the
display showing the current street is
switched on or off.
i
The list shows all symbols that are contained
in the digital map across all states (USA) and/or
provinces (CDN). Not all POIs in all states (USA)
or in all provinces (CDN) are available, however.
Certain POI symbols may not be displayed on the
map, even if the symbol display is switched on.

201 Control systems
COMAND navigation (introduction)
Setting route type
You can set the following route types:

“Fast Route”: COMAND calculates a
route with the shortest possible (mini-
mized) driving time.


“Short Route”: COMAND calculates a
route with the shortest possible (mini-
mized) distance taking distance and
driving time into account.

Select “Navi”
“Navi”
“Mode”.
The mode list appears. A square  indi-
cates the current setting.

Select route type: “Fast Route” or
“Short Route”.

Exit menu: Slide omp or press back
button L in the center console
(page 88).Setting route mode

Select “Navi”
“Navi”
“Mode”.
The mode list appears.

Switching mode on or off:
Select desired modes.
Depending on the previous status, the
mode is switched on or off. A check-
mark indicates that the mode is
switched on. It is possible to switch on
more than one mode.

Exiting menu: Slide omp or press
back button L in the center console
(page 88).
COMAND will verify whether it can in-
corporate the modes if you select them
with route guidance active.
If it can, COMAND calculates a new
route while incorporating the modes
selected.
If it cannot, you will see and hear a cor-
responding message.

Select “OK”.
COMAND calculates a new route.
Only those modes which can be in-
corporated are used.
i
If you change the route type setting during
active route guidance, COMAND calculates a
new route. If you change the setting when route
guidance is inactive, COMAND uses the new set-
ting for the next route guidance.
i
This function allows you to set the following
options for route guidance:


“Minimize Highways”


“Minimize Toll Roads”


“Minimize Tunnels”


“Minimize Ferries/Motorail”

209 Control systems
COMAND navigation system (entering a destination)
List of cities with input characters
When this list appears, the input charac-
ters 4 are automatically activated.
1Top list entry based on the input data
up to that point
2Characters entered by the user
3Characters automatically added by the
system
4Input characters
5Currently non-selectable characters
6Currently selectable character
7List of cities
8Currently selected characterThe top list entry 1 at first shows either
the city in which the vehicle is currently lo-
cated or the city which best corresponds
to the input data as it has been entered up
to that point.
As soon as you enter a character from in-
put characters 4, the top list entry 1
shows the city that best corresponds to
the input data as it has been entered up to
that point.
At the same time, COMAND automatically
supplements characters 2 entered by the
user with appropriate characters 3.

Selecting characters: Slide omp or
rotate ymz.

Confirming character selection:
Press n.

Deleting individual characters:
Select) in the bottom line and
pressn.

Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.

Canceling an entry: Select “Back” in
the bottom line and press n.
or

Press back button L in the center
console (
page 88).
i
In the list of input characters 4, you can
only select currently selectable characters.
Which characters are included depends on the
sequence in which you have entered your desti-
nation and the data version of the digital map.
i
The current city is shown if:


you have accepted the current state (USA) or
province (CDN) when entering the state
(USA) or province (CDN)


and if you select city entry immediately after-
ward

212 Control systemsCOMAND navigation system (entering a destination)The top list entry 1 first shows the street
first alphabetically and best corresponds
to the input data as it has been entered up
to that point.
As soon as you enter a character from in-
put characters 6, the top list entry 1
shows the street which best corresponds
to the input data as it has been entered up
to that point.
At the same time, COMAND automatically
supplements characters 2 entered by the
user with appropriate characters 3.
Selecting characters: Slide omp or
rotate ymz.

Confirming character selection:
Press n.

Deleting individual characters:
Select) in the bottom line and
pressn.

Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.

Canceling an entry: Select “Back” in
the bottom line and press n.
or

Press back button L in the center
console (
page 88).
As soon as COMAND can clearly attribute
the characters entered to a street, the in-
put characters 6 disappear. You see the
street list without the input characters.
Here you can confirm the current entry or
make another selection.
During character entry, you can also man-
ually switch to the street list without input
characters at any time.

Switching manually to the street list
without input characters: Slide qm.
or

Select ? in the second line from the
bottom and press n.Street list without input characters
1Symbol for more selection options

Selecting a street: Slide qmr or
rotateymz.
or

Enter a street number with the tele-
phone keypad using the R- 9
buttons (
page 90).
i
In the list of input characters 6, you can
only select currently selectable characters.
Which characters are included depends on the
sequence in which you have entered your desti-
nation and the data version of the digital map.
i
Example: Pressing 2 jumps to the 2nd Ave-
nue.
