2008 MERCEDES-BENZ CL-Class navigation system

220 Control systemsCOMAND navigation system (entering a destination)
Deleting individual characters:
Select) in the bottom line and
pressn.

Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.

Canceling an entry: Select “Back” in
the bottom line and press n.
or

Press back button L in the center
console (
page 84).
As soon as COMAND can clearly attribute
the characters entered to a destination,
the input characters 4 disappear.
You see the destination memory list with-
out input characters. Here you can confirm
the current entry or make another selec-
tion.
You can also manually switch to the desti-
nation memory list without input charac-
ters at any time.

Switching manually to the destina-
tion memory list without input char-
acters: Slide qm.
or

Select ? in the second line from the
bottom and press n.
Destination memory list without input
characters

Selecting a destination: Slide qmr or
rotate ymz.

Canceling selection: Press back but-
ton L in the center console
(page 84).
or

Select “Back” and press n.

Confirming selection: Press n.

Starting route calculation:
Select “Start”, see also (
page 218).
i
The “Back” menu item is only present if this
list was called up from the list with input charac-
ters.


221 Control systems
COMAND navigation system (entering a destination)
Entering a destination from the list of last destinations
Select “Navi”
“Destination”

“From Last Destinations”.
The list of last destinations appears.
The most recent destination is at the
top of the list.

Select desired destination.

Starting route calculation:
Select “Start”, see also (
page 218).
Entering a destination from the map
Calling up the map
In the address input menu, select
“Map” (
page 198).
You will see the map with a crosshair.
The map is set to the address set in the
address input menu.
or

Select “Navi”
“Destination”

“Via Map”.
You will see the map with a crosshair.1Crosshair
2Details of the crosshair position
3Map scale
i
Depending on the factory settings of the ve-
hicle, it may not be possible to enter a destina-
tion while the vehicle exceeds a preset speed. As
soon as the vehicles speed drops to below the
preset speed, the function is available again.
You can enter a destination via the map if the dig-
ital map does not contain the address of the des-
tination, but the destination must be within the
area of the digital map.
i
Display 2 may be the name of a road, for
example, provided the digital map contains the
necessary data.
If no data is available, display 2 shows:


the coordinates if the geo-coordinate display
is switched on (
page 195)


no display if the geo-coordinate display is
switched off (
page 195)

222 Control systemsCOMAND navigation system (entering a destination)Moving the map and selecting the des-
tination
Moving map: Slide qmr, omp or
wmx.

Adjusting map scale: Rotate ymz.
Rotating clockwise enlarges the map,
rotating counterclockwise reduces it.

Selecting a destination: Press n.
If the crosshair is located off the edge
of the digital map, a route cannot be
calculated to this destination and you
will see the message “The destination is
located off the map.”.

Select “OK”.

Move the map and select a destination
again.
If the destination is within the limits of
the digital map, COMAND attempts to
attribute the destination to the map,
which can take approximately
2 seconds.
If the destination can be attributed, you
will see the address of the destination.
If not, you will see the display “Destina-
tion from map”.

Starting route calculation:
Select “Start”, see also (
page 218).
Entering a stopoveri
When route guidance is active, you can en-
ter a stopover. Stopovers can be predefined des-
tinations from the following predefined
categories:


“Mercedes-Benz Center”


“Hospital”


“Gas station”


“Parking lot”


“Restaurant”
However, you can also enter destinations other
than the predefined ones.
i
You can use the stopover function to influ-
ence the route guidance calculation to the main
destination. When you have reached your stop-
over, COMAND automatically calculates the
route to the main destination.

223 Control systems
COMAND navigation system (entering a destination)
Entering predefined destinations
Select “Navi”
“Destination”

“Stopover”.
If a stopover has already been entered,
you can change it.
Changing: Select “Change Stop-
over”.
You can now select a category.

Selecting a category:
Select category, e.g. “Gas station”.
COMAND first looks for destinations
within the immediate vicinity of the ve-
hicle and near the vehicle’s route. If
there are no destinations available
there, COMAND searches for destina-
tions in an area around the vehicle po-
sition.
If COMAND does not find any destina-
tions, you will see a message to this ef-
fect.

Select “OK”.
You can now select a different cat-
egory.
If COMAND finds destinations, you will
see a list of the destinations and details
of how far away they are in the
right-hand side of the display. The in-
formation about how far away the des-
tinations are can take a few seconds to
be displayed.
The left-hand part of the display shows
the destinations on the map. The desti-
nation marked in the list is highlighted
in the map.

Selecting a destination: Select the
desired destination from list.
The address of the destination ap-
pears.

Starting route calculation:
Select “Start”, see also (
page 218).Entering another destination as a
stopover

Select “Navi”
“Destination”

“Stopover”.

Entering: Select “Other”.
You can select between the following
menu items:

“Address Entry”


“From Memory”


“From Last Destinations”


“From POIs”

Select a menu item.

224 Control systemsCOMAND navigation system (entering a destination)Subsequent destination entries may differ,
depending on your selection:

“Address Entry” selection:
Enter a destination by address
(page 198).


“From Memory” selection:
Enter a destination from the desti-
nation memory (
page 219).


“From Last Destinations” selection:
Enter a destination from the list of
last destinations (
page 221).


“From POIs” selection:
Enter a special destination
(page 225).

Starting route calculation: After
entering a destination, select “Start”
(page 218).Changing a stopover
If a stopover has already been entered, you
can change it.

Select “Navi”
“Destination”

“Stopover”
“Change Stopover”.

Enter another destination as a stop-
over.Deleting the stopover
If a stopover has already been entered, you
can delete it.

Select “Navi”
“Destination”

“Stopover”
“Delete Stopover”.
COMAND deletes the stopover and cal-
culates the route to the main destina-
tion.

225 Control systems
COMAND navigation system (Point of interest entry)
COMAND navigation system (Point of interest entry)
Entering a POI in the surrounding area
In the map view while the menu system
is displayed, select (
page 191) “Des-
tination”
“From POIs”
“Current
Position”.

Continue with designating the POI cat-
egory (
page 226).
Entering a POI in the surroundings of a
given city
Option 1
In the map view while the menu system
is displayed, select (
page 191) “Des-
tination”
“From POIs”
“Other
City”.

If necessary, enter state (USA)
(page 199) or province (CDN)
(page 199).

Entering city: Select “City”.
The city input menu appears.

Then proceed as described in the “En-
tering a city” section (
page 204).

After entering the city, continue with
designating the POI category
(page 226).
Option 2

Enter an address in the address input
menu (
page 198).

Select “POI”.

Continue with designating the POI cat-
egory (
page 226).
Entering a POI in a different region
In the map view while the menu system
is displayed, select “Destination”

“From POIs”
“Global POI”
(page 191).
The category list appears. The state
(USA) or province (CDN) currently se-
lected is shown in the first list entry.
i
This function gives you quick access to POIs
which are of national interest in the state (USA)
or province (CDN) you have selected. The follow-
ing categories may be available:


“AIRPORT”


“BORDER CROSSING”


“HIGHWAY ACCESS”
Not all categories are available in all states (USA)
or provinces (CDN).


226 Control systemsCOMAND navigation system (Point of interest entry)
Selecting another state (USA) or
province (CDN): Select the first list
entry.
A list of states/provinces appears.

Select desired state (USA) or province
(CDN).
If there are no POIs for the selected
state (USA) or province (CDN), you will
see a corresponding message.
Closing message: Select “OK”.
You can again select a state (prov-
ince).
If there are POIs, you will see the cate-
gory list again.

Proceed as described in the “Selecting
a category” paragraph in the “Main cat-
egory list without input characters”
section (
page 228).
Designating a POI category
The categories and POIs available depend
on the distance from the vehicle position
you have set for the POI.

POI in the surrounding area:
categories sorted alphabetically and
POIs sort ed by d is tanc e withi n a rad iu s
of about 12 mi around the vehicle posi-
tion are available. You can extend the
search radius using the list options
(page 231).


POI within a given city:
If you have only entered the state (USA)
or province (CDN) and the city, alpha-
betically sorted categories and alpha-
betically sorted POIs within the city are
available.If you have entered more than the state
(USA) or province (CDN) and the city,
alphabetically sorted categories and
POIs sorted by distance within a radius
of about 12 mi around the address en-
tered are available. You can extend the
search radius and the category selec-
tion using the list options
(
page 231).


POIs in a different region:
Alphabetically sorted categories and
alphabetically sorted POIs are avail-
able.
Entering a category
Depending on the number of available cat-
egories, the main category list appears for
category entry either with or without input
characters (
page 228).


227 Control systems
COMAND navigation system (Point of interest entry)
Main category list with input characters
When this list appears, the input charac-
ters 5 are automatically activated.
1Top list entry based on the input data
up to that point
2Characters entered by the user
3Characters automatically added by the
system
4Symbol for available POIs or other
available subcategories
5Input characters
6Currently non-selectable characters
7Currently selectable character
8Currently selected character
9Main category listWhile the characters are being selected as
described below, the top list entry 1 al-
ways shows the category which best corre-
sponds to the input data as it has been
entered up to that point.
At the same time, COMAND automatically
supplements characters 2 entered by the
user with appropriate characters 3.

Selecting characters: Slide omp or
rotate ymz.

Confirming character selection:
Press n.

Deleting individual characters:
Select) in the bottom line and
pressn.

Deleting an entire entry: Select) in
the bottom line and press n until the
entire entry is deleted.

Canceling an entry: Select “Back” in
the bottom line and press n.
or

Press back button L in the center
console (
page 84).
As soon as COMAND can clearly attribute
the characters entered to a category, the
input characters 5 disappear.
You see the list of main categories without
the input characters. Here you can confirm
the current entry or make another selec-
tion.
You can also manually switch to the main
category list without input characters at
any time.

Switching manually to the main cat-
egory list without input characters:
Slide qm.
or

Select ? in the second line from the
bottom and press n.
i
In the list of input characters 5, you can
only select currently selectable characters.
Which characters are included depends on the
sequence in which you have entered your desti-
nation and the data version of the digital map.
